- Page 1 TWO BANDS EQUALIZER USER GUIDE for 500 Series enclosures - 1 - MCAudioLab SE1 EQ module - user manual issue 1.0...
- Page 2 It’s a dual-band EQ with low and high bands and of course a level control for fine adjustments of the output level. The SE1 is a single-channel 500 series module with an all-discrete Class A circuitry and the MCAudioLab 816 discrete op-amp.
- Page 3 Switch off the 500-series enclosure and remove mains power. Carefully insert the SE1 module into the empty slot in the 500-series enclosure and ensure the rear edge connector on module and the edge connector of the 500-series enclosure mates correctly.
- Page 4 MCAudioLab own the copyright of all informa�on and drawings contained in this user guide which is not to be copied or reproduced by any means or disclosed in part or whole to any third party without wri�en permission.
