MINIAIR QUICK GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the MINIAIR and is the answer not in the manual?

Questions and answers

Related Manuals for CSL MINIAIR

Summary of Contents for CSL MINIAIR

  • Page 1 MINIAIR QUICK GUIDE...

  • Page 2: Technical Specifications

    MiniAir Quick Guide Technical Specifications Figure 1 Wire Explanation 1 = 12v DC Power Supply 2 = Ground 3 = A - to panel’s Digi-Modem 4 = B - to panel’s Digi-Modem 5 = To Armed Status Output 6 = To Keyswitch Zone...
  • Page 3 1 Digital Input, 1 Digital Output, Analogue (Dial Capture) CIE Interconnections RCT Protocols Fast Format, SIA & Contact ID User Serviceable Parts There are no serviceable parts within the MiniAir Environmental Class II Suitable for use in alarm systems complying to:...
  • Page 4 MiniAir Quick Guide Step 1 - Wiring 1 - Power panel down 2 - Wire as per diagram in the Technical Specifications 3 - Connect aerial 4 - LED will show connection status...
  • Page 5 4 - Enter any PSTN receiver telephone number (ie 01) 5 - Enter any 4 Digit chip/account number (ie 1234) WHEN USING FAST FORMAT, THE MINIAIR INSTALLER APP AND MY HOME ALARM APP ARE PREDEFINED WITH A STANDARD FAST FORMAT CHANNEL CONFIGURATION.

  • Page 6: Step 3 - Bell Output

    2 - Wire the bell trigger to the MiniAir input (IN – white cable) 3 - Download the MiniAir Installer App for Android/iOS 4 - Please contact CSL to obtain log in credentials to the MiniAir Installer App & select device by serial number/ICCID 5 - Enter Settings the select Advanced Settings 6 - Depending on your panel configuration set Input pins as: General Alarm N.O./N.C.
  • Page 7 MiniAir Quick Guide Step 4 - End User App 1 - Download the My Home Alarm App for Android/iOS 2 - Login with credentials provided 3 - When logging in for first time change username and password. Then enter recovery email address 4 - Within the App, select menu button and then settings option 5 - Select notifications and adapt as per the on screen instructions...
  • Page 8 – refer to manufacturer’s guide 4 - Wire the programmable output to IN (white wire) on the MiniAir Please note: A relay may be required when configuring a panel with a latching keyswitch Secondly, configure the App:...
  • Page 9 MiniAir Quick Guide Warnings & Troubleshooting If you have issues receiving events try the following settings of the panel: Disable “Telephone line monitoring” Disable “Wait for dial tone” option Use “A” instead of “0” in the account number If there is more than one partition, enter an account number for each partition. For...
