- Page 1 Assembly Instructions Palma Low Lounge Fire Pit Table 0193393-3310/5510 IMPORTANT PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE. THIS IS IMPORTANT INFORMATION REGARDING THE USE AND CARE OF YOUR GARDEN FURNITURE. ASSEMBLY PERSONS TIME REQUIRED Feb 2022...
-
Page 2: Important Safety Information
Important Safety Information Danger Warning If you smell gas: Improper installation, adjustment Shut off gas to the alteration, service or maintenance appliance. can cause injury or property damage. Extinguish any open flame. Read the installation, operating and If odour continues, maintenance instructions thoroughly contact your gas canister before installing or servicing this... - Page 3 Important Safety Information Before you assemble or operate this unit, please carefully read this entire manual. Failure to do to may result in a fire, explosion, injury or death. • DO NOT fill tank over 80 percent full. • THIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used outdoors, •...
- Page 4 Important Safety Information • Keep all electrical cords and fuel supply hose • Children should never operate this unit. away from heated surfaces. Children must be supervised while near this unit. • Combustible material should not be within 72 inches of the top of the unit, or within 48 •...
- Page 5 Important Safety Information removed for servicing the appliance IF APPLICABLE: shall be replaced prior to operating the • Allow heating item to cool completely appliance. before placing on lid. • Installation and repair should be done by • DO NOT use heating item while lid is a qualified service person.
-
Page 6: Parts List
8. Please do not use substitute parts. Use only additional or replacement parts supplied by Kettler. 9. In the unlikely event that this product has missing or damaged parts, please visit our website... - Page 7 Parts List Item Description Burner Lid Burner (Pre-assembled) Burner (Pre-assembled) Fire Bowl (Pre-assembled) Electronic Ignitor (Pre-assembled) Control Knob (Pre-assembled) Lava Rocks 1 Box Battery (AA) Glass Fixing Brackets Side Glass (longer) End Glass (shorter)
- Page 8 Assembly Check that the control knob (F) for the gas supply system is turned to the OFF position before starting any assembly. Assemble the Glass Screen Please note that the assembly position of glass must be the same as the diagram Assemble the glass (K) and glass (below right).
- Page 9 Assembly Place the gas bottle (not included) into the gas bottle storage unit Turn the cylinder valve on the tank clockwise to close the propane tank. Attach the preassembled regulator from the table top (B) to the cylinder valve by turning the regulator coupling nut clockwise.
- Page 10 Assembly Unscrew the rubber cap on the electronic igniter (E) by unscrewing and slide battery (H) into the battery slot. Make sure the positive side of the battery faces outwards. Screw the electronic igniter cap (E) over the battery tightly. Caution To ensure proper function, the guard (B) on this Hand place the lava...
-
Page 11: Operation
Operation Before performing a leak test, be sure that no sparks can occur and you are in a spacious outdoor area. Connect the propane gas tank to the regulator and turn the valve on the unit to the “off” position. Brush a soap and water mixture on all connections. Turn the gas supply on; if bubbles occur on any connection there may be a leak. -
Page 12: Troubleshooting
Check which direction the battery is Igniter battery is incorrectly inserted inserted Heating Igniter pin is broken Contact Kettler for a replacement part unit won’t Reconnect wire to the igniter box light Electrode wire is loose or disconnected located inside the table behind the... -
Page 13: Maintenance And Care Instructions
• Kettler cushions are not suitable for dry cleaning and are not machine washable. Sponge clean only. We recommend the use of the Kettler fabric care kit to clean and protect your cushions. This is available to purchase form the Kettler website. - Page 14 Attention Please be aware that painted/varnished surfaces can be damaged by sunscreens and oil based products. If the surface of your Kettler leisure furniture comes into contact with sunscreens, the surface is to be cleaned without delay as described above.
-
Page 16: For Your Safety
• Damaged components may endanger your safety or shorten the life of the product. Replace all damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop •...
