unios ION S IONSSS08 Quick Start Manual

Surge Protection
For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this luminaire. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This luminaire will not be used as a
'Working light' during construction. This will result in the warranty of the luminaire to be void. For warranty duration,
please refer to the data sheet.
Cleaning
Always clean carefully using a soft cloth and a ph-neutral,
alcohol-free, non-abrasive cleaning cloth. Clean & Maintain
the finish twice a year to avoid rust, oxidation or limescale
deposits. If this entire surface is not cleaned correctly, the
finish may become uneven.
Do not use abrasive pads, discs, sandpaper and/or high
pressure hose/gun to clean the luminaire.
ION S Track Light
Installation Instructions
unios.com/ionstrackims
Edition 20.3.24 | Product design and technical data may be subject to change
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment)
ION S Recessed Spotlight
Installation Instructions
unios.com/ionsrecessedims
Page 4 of 4
unios.com/ions
ION S
Base Small
Codes
IONSSS08
Input Voltage
220–240V ~ 50/60Hz
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
55
B
Sizing Variations
Product Code
IONSSS08
IONSMS18
IONSLS32
Edition 20.3.24 | Product design and technical data may be subject to change
Medium Large
IONSMS18 IONSLS32
Material Operating Temp Install Person/s
Aluminium <25°C 1x
Parts & Accessories
1x
D
2mm Hex Allen Key
Included
Product Assembly
Standard
C
Body
Primary
Optic
A
Trim
Secondary
Optic
Baffle
A B C D
50 125 170 80
65 148 199 80
85 160 211 100
All measurements are in millimetres.
Page 1 of 4
unios.com/ions
SURFACE MOUNTED SPOTLIGHT
IP20
Power
8-32 Watts
2x
M4 30mm Screws
Included
Framer
Body
Framer
Lens
Wallwasher
Body
Primary
Optic
Wallwasher
Trim
