We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com

PRECAUTIONS

General safety instructions

Risk of personal injury
• ATTENTION: during use, the
appliance and its accessible
parts become very hot.
Children must be kept away
from the appliance.
• ATTENTION: during use, the
appliance and its accessible
parts become very hot. Never
touch the heating elements
during use.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
26 - PRECAUTIONS
26
26
29
29
30
30
30
30
30
30
30
31
31
31
31
31
32
32
flames with a fire blanket or
other appropriate cover.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical,
sensory or mental capacity, or
lacking in experience in the use
of electrical appliances,
provided that they are
supervised or instructed by
adults who are responsible for
their safety.
• Children must not play with the
appliance.
• Keep children under the age of
8 at a safe distance unless they
are constantly supervised.
• Keep children under the age of
8 away from the appliance
33
33
33
33
33
34
35
36
37
37
37
38
39
40
41
41
41
42
91477B294/A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFR93M3TVX and is the answer not in the manual?

Questions and answers

Related Manuals for Smeg SFR93M3TVX

Summary of Contents for Smeg SFR93M3TVX

  • Page 1: Table Of Contents

    Accessories Positioning We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions flames with a fire blanket or other appropriate cover.
  • Page 2 when it is in use. personnel in accordance with • Cleaning and maintenance current standards. must not be carried out by • Do not try to repair the unsupervised children. appliance yourself or without • The cooking process must the assistance of a qualified always be monitored.
  • Page 3 oven cavity. interfere with the hot air circulation inside the oven cavity. • Do not use the open door to rest pans or trays on the internal glass pane. • Never use the oven door to • Do not use steam jets to clean lever the appliance into place the appliance.

  • Page 4: For This Appliance

    • Use cables withstanding a switched off and disconnected temperature of at least 90 °C. from the mains power supply or • The tightening torque of the that the mains power has been screws of the terminal supply switched off before replacing wires must be 1.5 - 2 Nm.

  • Page 5: This User Manual

    This user manual Our appliances are packaged in non-polluting and recyclable materials. • This user manual is an integral part of the • Deliver the packing materials to the appliance and must therefore be kept in its appropriate recycling centre. entirety and within the user's reach for the whole working life of the appliance.

  • Page 6: Light Sources

    remaining minutes with the heat which has • The light sources contained in the appliance accumulated inside the oven. are declared suitable for operation at ambient temperature ≥300°C and intended • Reduce any opening of the door to a for use in high temperature applications such minimum to avoid heat dispersal.

  • Page 7: Other Parts

    2 Temperature knob Accessories This knob allows you to select the cooking • Not all accessories are available on some temperature. models. Turn the knob clockwise to the required value, • The accessories intended to come into between the minimum and maximum setting. contact with food are made of materials that comply with the provisions of current 3 Thermostat indicator light...

  • Page 8: Use

    Preliminary operations Tray rack See General safety instructions. • Remove any protective film from the outside or inside of the appliance, including accessories. • Remove any labels (apart from the technical The tray rack has to be inserted into the tray. In data plate) from the accessories and this way fat can be collected separately from shelves.

  • Page 9: Cooking Advice

    List of traditional cooking functions FAN-ASSISTED Intense and uniform cooking. Ideal for Not all functions are available on some biscuits, cakes and multilevel cooking. models. FAN-ASSISTED GRILL STATIC Allows optimal grilling of even the Traditional cooking suitable for the thickest meats. Perfect for large cuts of preparation of one dish at a time.

  • Page 10: Traditional Cooking Information Table

    the dough. To save energy • To check whether the dessert is cooked right • Stop cooking a few minutes before the time through: At the end of the cooking time, put normally used. Cooking will continue for the a toothpick into the highest point of the remaining minutes with the heat which has dessert.

  • Page 11: Information For Supervisory Bodies

    Spare ribs Fan with grill Bacon (0.5 cm thick) 0.8 - 1 Fan with grill Pork fillet (0.5 cm thick) 0.8 - 1 Grill Beef fillet (2 cm thick) 0.8 - 1 Grill (**) Grilling times depend on the thickness of the food and the level of cooking/browning you wish to achieve.

  • Page 12: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Cleaning the appliance 2. Grasp the door on both sides with both hands, lift it forming an angle of around 30° and remove it. See General safety instructions. Cleaning the surfaces To keep the surfaces in good condition, they should be cleaned regularly after use.

  • Page 13: Cleaning The Oven Cavity

    2. Remove the internal glass pane by pulling 5. Use absorbent kitchen roll. In case of the rear part gently upwards, following the stubborn dirt, wash with a damp sponge movement indicated by the arrows 1. and neutral detergent. 6. Reinsert the intermediate glass unit and reposition the inner glass.

  • Page 14: Vapor Clean (On Some Models Only)

    Vapor Clean (on some models only) • The rack/tray support frames. In the event you are using specific See General safety instructions. cleaning products, we recommend running the oven at maximum temperature for 15-20 minutes in order The Vapor Clean function is an assisted to eliminate any residue.

  • Page 15: Extraordinary Maintenance

    elements off and the buzzer will start to Seal maintenance tips sound. The seal should be soft and elastic. • To keep the seal clean, use a non-abrasive Vapor Clean End sponge and wash with lukewarm water. 1. Turn the function knob to 0 to exit from the function.

  • Page 16: Installation

    6. Refit the cover. Ensure the moulded part of 7. Press the cover completely down so that it the glass (A) is facing the door. attaches perfectly to the bulb support. INSTALLATION Electrical connection regulations. For the Australian/New Zealand market: See General safety instructions.

  • Page 17: Positioning

    Cable replacement leaking in. Power voltage Danger of electrocution • Disconnect the mains power supply. 1. Unscrew the screws on the rear casing. Fastening bushings 2. Lift the rear casing slightly and remove it to gain access to the terminal board. 3.
  • Page 18 Mounting into a column (mm) Make sure that the cabinet top/rear section has an opening approx. 35-40 mm deep. 91477B294/A INSTALLATION - 43...
  • Page 19 A min. 900 mm B 860 - 864 cm C 477 - 479 cm D 9 - 11 cm E min. 5 mm F 121 - 1105 cm G min. 560 mm co Cutout for power cord (min. 6 cm jb Electrical connection box 44 - INSTALLATION 91477B294/A...
  • Page 20 Mounting under worktops (mm) If the appliance is to be built-in under a worktop, a wooden bar has to be installed order to use the seal that is glued to the back of the front panel to prevent water or other liquids leaking in. A min.
  • Page 21 Mounting under worktops (mm) (pyrolytic models only) Whenever a hob is installed above the oven, a wooden separator has to be installed at a minimum distance of 20 mm from the top of the oven to prevent overheating when the two appliances are used at the same time.
