- Page 1 RG-NIS-PA Series Power Modules Hardware Installation and Reference Guide Document Version: V1.0 Date: 2023-11-08 Copyright © 2023 Ruijie Networks...
- Page 2 Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is designed merely as a user guide. Ruijie Networks has tried its best to ensure the accuracy and reliability of the content when compiling this manual, but it does not guarantee that the content of the manual is completely free of errors or omissions, and all the information in this manual does not constitute any explicit or implicit warranties.
- Page 3 Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support The official website of Ruijie Reyee: https://www.ruijienetworks.com/products/reyee Technical Support Website: https://www.ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com...
- Page 4 Note This manual provides the device installation steps, hardware troubleshooting, module technical specifications, and specifications and usage guidelines for cables and connectors. It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts.
-
Page 5: Product Introduction
RG-NIS-PA Hardware Installation and Reference Guide Product Introduction Product Introduction Power Modules 1.1.1 RG-NIS-PA240-48 1. Appearance 2. External Ports (1) RG-NIS-PA240-48 is a DC power module that provides DC power input to switch and supplies 48 V/5 A rated voltage to the system. (2) The front panel has a three-pin power connector at the bottom for connecting a standard 10 A power cord. - Page 6 RG-NIS-PA Hardware Installation and Reference Guide Product Introduction 4. Technical Specifications Module Model RG-NIS-PA240-48 Rated Voltage Range 100–240 V, 50/60 Hz Max. Voltage Range 85–264 V, 47–63 Hz Max. Output Power 240 W Ground-Leakage ≤ 0.5 mA Current –40º C to +70º C (–40° F to +158° F) Operating Temperature –40º...
- Page 7 RG-NIS-PA Hardware Installation and Reference Guide Product Introduction ≥ 105% Io, self-recovery Low temperature ≤ 60 V (hiccup, Overvoltage 48 V self-recovery after an protection exception is eliminated) Overtemperature 230 V AC, rated load 80º C (176° F) protection Caution If it is used on the RG-SWITCH, the temperature and power consumption parameters depend on the power module specifications of the RG-SWITCH.
- Page 8 RG-NIS-PA Hardware Installation and Reference Guide Product Introduction 2. External Ports 1. RG-NIS-PA120-48 is a DC power module that provides DC power input to switch and supplies 48 V/2.5 A rated voltage to the system. 2. The front panel has a three-pin power connector at the bottom for connecting a standard 10 A power cord. 3.
- Page 9 RG-NIS-PA Hardware Installation and Reference Guide Product Introduction 60º C to 70º C 165 V AC to 264 V AC 2.5%/℃ (140° F to input 158° F) Input voltage 85 V AC to 100 V AC 0.67%/V AC derating Hiccup mode: Maintain constant current for 1s Short circuit After the short circuit is eliminated, the power supply is...
-
Page 10: Preparation Before Installation
RG-NIS-PA Hardware Installation and Reference Guide Preparation before Installation Preparation before Installation Safety Suggestions To avoid personal injury and device damage, carefully read the safety suggestions before you install the RG-NIS-PA series. The following safety suggestions may not cover all possible dangers. 2.1.1 General Safety Precautions ... -
Page 11: Installation Site Requirements
RG-NIS-PA Hardware Installation and Reference Guide Preparation before Installation power supplies in the system. For example, if a system is equipped with 16 identical power supplies, the leakage current of each power supply is equal to or less than 3.5 mA, and the total leakage current of the system is 56 mA. - Page 12 RG-NIS-PA Hardware Installation and Reference Guide Preparation before Installation 2.2.3 Anti-interference Requirements The switch is susceptible to external interference by capacitive coupling, inductive coupling, electromagnetic waves, common impedance (grounding) coupling, or conduction over conducting wires including power cords, signal cables, and output cables. Note that: In a TN grounding system, use a three-wire single-phase outlet that has a protective earth (PE) contact to allow the filter circuit in the device to eliminate interference from the power grid.
- Page 13 RG-NIS-PA Hardware Installation and Reference Guide Preparation before Installation 2.2.5 Grounding A good grounding system is the basis for stable and reliable operation of the device, preventing lightning strokes and resisting interference. Carefully check the grounding conditions at the installation site according to the grounding requirements, and perform grounding operations properly as required.
-
Page 14: Installation Tools
RG-NIS-PA Hardware Installation and Reference Guide Preparation before Installation or a completely electrically isolated unit. Conducted interference results from an electromagnetic wire or signal cable connection between the source and the sensitive component, along which cable the interference conducts from one unit to another. Conducted interference often affects the power supply of the device, but can be controlled by a filter. -
Page 15: Product Installation
RG-NIS-PA Hardware Installation and Reference Guide Product Installation Product Installation Ensure that you have read chapter 2 carefully. Verify that the requirements described in chapter 2 have been met. Confirmations Before Installation Before installation, confirm the following points at the installation site: ... -
Page 16: Bundling The Cables
RG-NIS-PA Hardware Installation and Reference Guide Product Installation (2) Connect the power module to the switch, as shown in the following figure. Bundling the Cables Precautions Bundle the power cords and other cables neatly. When bundling fiber-optic cables, ensure that they have natural bends or large bend radius at the connectors. Do not bundle fiber-optic cables and twisted pair cables too tightly, as this may press the cables and affect their service life and transmission performance. -
Page 17: Verifying Installation
RG-NIS-PA Hardware Installation and Reference Guide Product Installation (3) For the power cords, bundle them closely along the bottom of the chassis, in a straight line wherever possible. Verifying Installation Danger Turn off the power to avoid personal injury and damage to components caused by incorrect connection. Verify that the grounding wire is properly connected.
