Origin PRO ProA125.1 Quick Start Manual

Origin PRO ProA125.1, ProA125.1D, ProA125.2, ProA125.2D, ProA250.1, ProA250.1D, ProA250.2 & ProA250.2D Amplifiers (2 & 4 Channel)
Carton Contents
• Amplifier unit • Output connector x 2/4
• Mains power cable • Adhesive rubber feet x 4
• Input connector x 4 • Document pack
• GPIO socket connector
Network
Control
Dante
(optional)
Installation Notes
• High or low impedance speaker connection options can be
selected independently for each output channel via the Origin
PRO amplifer Web App.
• Analogue input sensitivity can be adjusted independently for
each channel via the Origin PRO amplifer Web App.
• S/PDIF digital audio I/O routing can be configured via the
Origin PRO amplifer Web App.
• GPIO (General Purpose Input/Output) options can be
configured via the Origin PRO amplifer Web App.
QUICK START GUIDE
Connection Sockets
Configurable Configurable
GPIO S/PDIF Audio I/O
*Product shown as example is Origin PRO
®
4 Channel version amplifier: ProA250.2D)
• Optional Audinate Dante
over IP (AoIP) networks and installations.
• Ensure that rack or other confined installation does not
restrict the airflow required for safe and reliable operation
of the equipment. It is important to ensure that the 40°C
maximum operating temperature for the equipment is not
exceeded.
Origin PRO, 6975 S Decatur Blvd, Las Vegas, NY 89118. www.originpro.com
©2023 Origin PRO. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin PRO.
Audio Inputs
Balanced: Euroblock - Unbalanced: RCA Phono.
Configurable
Speaker Outputs
® interface for integration with audio
Support
• A full user manual that includes
information on installation, mounting
accessories and amplifier operation is
available online. Go to www.originpro.com,
or scan the QR code.
