Electric AVENUE Watti Pro Lite Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
UNIVERSAL PEDESTAL
INSTALLATION GUIDE
DESIGNED FOR USE WITH

Advertisement

loading
Need help?

Need help?

Do you have a question about the Watti Pro Lite and is the answer not in the manual?

Questions and answers

Related Manuals for Electric AVENUE Watti Pro Lite

Summary of Contents for Electric AVENUE Watti Pro Lite

  • Page 1 UNIVERSAL PEDESTAL INSTALLATION GUIDE DESIGNED FOR USE WITH...
  • Page 2 Images in this manual are for illustration purposes only and may differ from the delivered product. © 2023 Electric Avenue Manufacturing Inc. All rights reserved. This document is protected by the copyright laws of Canada, the United States and other countries.
  • Page 3 Installing a Single Charger............ Installing Back-to-Back Chargers........Installing Side-by-Side Chargers........Electrical Wiring................ Mounting the Top and Cable Management System Installing the Cable Management System..... Positioning the Cable Clamp..........Mounting the EV Parking Sign............. NEED ASSISTANCE? Electric Avenue Technical Support: 1-888-353-2283 support@goelectricave.com...

  • Page 4: Important Safety Information

    Disconnect electrical power prior to installing the charging station. WARNING: Electric Avenue is not responsible for any damages that may occur resulting from custom installations that are not described in this document or for any failure to adhere to installation recommendations.

  • Page 5: Need Assistance

    DO NOT attempt to remove, open, disassemble, repair, tamper with, or modify the pedestal. DO NOT attempt to mount the EV charger other than directed in this manual. DO NOT put heavy objects on the pedestal. NEED ASSISTANCE? Electric Avenue Technical Support: 1-888-353-2283 support@goelectricave.com...
  • Page 6 Gather the following tools (not included) before installing your pedestal: Wire stripper 5. Pencil or marker Socket wrench 6. Drill Voltmeter or digital multi-meter 7. Conduit Cutting Tool Torque Wrench 8. Stepping stool NEED ASSISTANCE? Electric Avenue Technical Support: 1-888-353-2283 support@goelectricave.com...
  • Page 7 GETTING STARTED PEDESTAL COMPONENTS CAUTION: Do not install the pedestal and charging station near dangerous areas such as water pipes, gas pipes, and steam pipes to ensure safe use. Pedestal Components: 1. Pedestal Base Plate 2. Pedestal Base 3. Pedestal Top 4.
  • Page 8 GETTING STARTED CONFIGURATION OPTIONS STRUCTURAL COMPONENTS UNIVERSAL PEDESTAL BASE PART #: JNT-SSP/03B Universal Pedestal Base UNIVERSAL PEDESTAL TOP PART #: JNT-SSPC/03B A. Pedestal Base + Base Plate B. Single Mounting Bracket (x2) C. Side-by-Side Mounting Bracket D. Pedestal Top Universal Pedestal Base with Pedestal Top E.
  • Page 9 GETTING STARTED ASSEMBLED PEDESTAL DIMENSIONS 10.5 cm (4.15 in) 60.26 cm (23.72 in) 2.9 cm (1.13 in) 13.1 cm (5.16 in) 56 cm (22.05 in) 18.5 cm (7.28 in) 10 cm (3.9 in) 17.8 cm (7 in) 127.3 mm (5.01 in) 180 mm (7.09 in)
  • Page 10 GETTING STARTED BOX CONTENTS UNIVERSAL PEDESTAL BASE (BOX 1) BACK-TO- SIDE-BY- SINGLE BACK SIDE DESCRIPTION IMAGE QTY. QTY. QTY. Pedestal Base Pedestal Base Plate Base Cover M5*14mm Countersunk Head Torx Screw M8*18mm Pan Head Torx Screw M8 Spring Washer M8 Flat Washer M8 External Tooth Lock Star Washer M8*100mm Expansion Screw...
  • Page 11 GETTING STARTED BOX CONTENTS UNIVERSAL PEDESTAL BASE (BOX 1) CONTINUED BACK-TO- SIDE-BY- SINGLE BACK SIDE DESCRIPTION IMAGE QTY. QTY. QTY. Cable Gland Open Plate Cable Gland Closed Plate Side-by-Side Mounting Bracket 45° strain relief connector² Single/Back-to-Back Mounting Bracket Pedestal Installation & User Manual EV CHARGER USER &...
  • Page 12 GETTING STARTED BOX CONTENTS UNIVERSAL PEDESTAL TOP (BOX 2) CONTINUED BACK-TO- SIDE-BY- SINGLE BACK SIDE DESCRIPTION IMAGE QTY. QTY. QTY. M6 Flat Washer Pedestal Top Adapter M5*12mm Pan Head Torx Screw UNIVERSAL PEDESTAL TOP CABLE MAGEMENT SYSTEM (BOX 3) BACK-TO- SIDE-BY- SINGLE BACK...
  • Page 13 MOUNTING THE BASE PREPARING THE CONCRETE BASE CAUTION: Do not install the pedestal and charging station near dangerous areas such as water pipes, gas pipes, and steam pipes to ensure safe use. CAUTION: The concrete pad must be prepared in accordance with all local regulatory requirements.
  • Page 14 MOUNTING THE BASE PREPARING THE CONCRETE BASE CAUTION: Do not install the pedestal and charging station near dangerous areas such as water pipes, gas pipes, and steam pipes to ensure safe use. CAUTION: The concrete pad must be prepared in accordance with all local regulatory requirements.
  • Page 15 MOUNTING THE BASE INSTALLING THE BASE PLATE STEP 1 Lay the pedestal base plate on the concrete pad, ensuring the input power cable is located precisely underneath the opening of the base plate. Mark (4) drilling locations on the concrete foundation using the holes in the pedestal base plate as reference.
  • Page 16 MOUNTING THE BASE INSTALLING THE PEDESTAL BASE STEP 1 Lift the pedestal base over the base plate and feed the incoming cable through the opening. Secure the pedestal base to the base plate using (4) M6*18 mm pan head torx screws with (4) M6 spring washers and (4) M6 flat washers.
  • Page 17 MOUNTING THE CHARGING STATION INSTALLING A SINGLE CHARGER (For configurations #1 and #4 on pg. 6) STEP 1 Detach the bracket from the sides of the charger by loosening and removing the (2) screws. Set aside the screws for use in subsequent steps. STEP 2 Secure the single mounting bracket to the front side of the pedestal using (4) M8*18mm screws and...
  • Page 18 MOUNTING THE CHARGING STATION INSTALLING A SINGLE CHARGER (For configurations #1 and #4 on pg. 6) STEP 5 Use the 279 mm length marking on the pedestal base box as a guide to measure and mark a 279 mm length on the conduit supplied with the charger.
  • Page 19 MOUNTING THE CHARGING STATION INSTALLING BACK-TO-BACK CHARGERS (For configurations #2 and #5 on pg. 6) STEP 1 Detach the bracket from the sides of the charger by loosening and removing the (2) screws. Set aside the screws for use in subsequent steps. Repeat on both chargers.
  • Page 20 MOUNTING THE CHARGING STATION INSTALLING BACK-TO-BACK CHARGERS (For configurations #2 and #5 on pg. 6) STEP 5 Use the 279 mm length marking on the pedestal base box as a guide to measure and mark a 279mm length on the conduit supplied with the charger.
  • Page 21 MOUNTING THE CHARGING STATION INSTALLING SIDE-BY-SIDE CHARGERS (For configurations #3 and #6 on pg. 6) STEP 1 Detach the bracket from the sides charger by loosening and removing the (2) screws. Set aside the screws for use in subsequent steps. Repeat on both chargers.
  • Page 22 MOUNTING THE CHARGING STATION INSTALLING SIDE-BY-SIDE CHARGERS (For configurations #3 and #6 on pg. 6) STEP 5 Disassemble the 45° and 90° strain relief connectors. Pass the 45° connector sealing ring and metal locknut through the wiring window, up towards the left side cable opening. From the outside of the pedestal, pass the 45°...
  • Page 23 MOUNTING THE CHARGING STATION INSTALLING SIDE-BY-SIDE CHARGERS (For configurations 3 and 6 on pg. 6) STEP 8 Use the 310 mm length marking on the pedestal box as a guide to measure and mark a 310 mm length on the other supplied conduit. STEP 9 Using an appropriate cutting tool, neatly trim both conduits to the marked lengths.
  • Page 24 MOUNTING THE CHARGING STATION ELECTRICAL WIRING STEP 1 Thread the input power cables from the bottom of the pedestal base up towards the wiring window to meet the power leads from the charger(s). STEP 2 Terminate the charger leads to the incoming power. Ensure all connections are adequately grounded, taking into account the pedestal grounding wire.

  • Page 25: Need Assistance

    Tighten all loose connectors to secure the conduit(s) in place. STEP 5 To complete the installation, secure the bracket to the sides of the charger by tightening the (2) original screws. Repeat for all chargers. NEED ASSISTANCE? Electric Avenue Technical Support: 1-888-353-2283 support@goelectricave.com...
  • Page 26 MOUNTING THE TOP & CABLE MANAGEMENT SYSTEM INSTALLING THE CABLE MANAGEMENT SYSTEM STEP 1 Secure the adapter to the base with (4) M6*20mm screws with (4) M6 spring washers and (4) M6 flat washers. STEP 2 Lift the pedestal top over the pedestal base adapter and secure it using (4) M6*18mm screws with (4) M6 spring washers and (4) M6 flat washers...
  • Page 27 MOUNTING THE TOP & CABLE MANAGEMENT SYSTEM POSITIONING THE CABLE CLAMP IF DUAL CABLE MANAGEMENT IS REQUIRED, REPEAT STEP 1 - STEP 7 ON BOTH SIDES. STEP 1 Unscrew and remove the screw and nut to open the cable clamp. Unscrew and remove the (2) outer gland screws to open the inner fittings.
  • Page 28 Slide the cable clamp fitting to the desired section of the cable. Before tightening, test the fit to determine the final length. STEP 7 To complete, secure the cable clamp in the desired location. NEED ASSISTANCE? Electric Avenue Technical Support: 1-888-353-2283 support@goelectricave.com...
  • Page 29 MOUNTING THE EV PARKING SIGN Two (2) EV CHARGING ONLY parking signs included with pedestal top. You can use the pedestal top to display your signs, or easily mount to standard street parking sign poles. STEP 1 Secure the parking sign to the front of the pedestal top using (2) cross machine teeth screws.
