Light Efficient Design Solera SL-SAL-50W Installation And User Manual

SL-SAL-50W SOLAR AREA LIGHT
PRIOR TO INSTALLATION, PLEASE READ THE ENTIRE INSTALLATION INSTRUCTIONS
These instructions only apply to the SL-SAL-50W INCLUDING OG, HYB, G1 OR G2.
WARNINGS
THIS LIGHT SHOULD BE INSTALLED BY A QUALIFIED PROFESSIONAL.
INSTALLER RESPONSIBLE TO ENSURE SAFE INSTALLATION, PROPER MAINTENANCE AND SAFETY CHECKS.
NOT FOR EMERGENCY LIGHTING.
NOT FOR USE IN ENVIRONMENTS WHERE EXPLOSIVE OR CORROSIVE GASES ARE PRESENT.
NO USER SERVICABLE PARTS INSIDE FIXTURE. DO NOT DIS-ASSEMBLE OR MODIFY THE FIXTURE IN ANY WAY.
NOTES
THIS SOLAR FIXTURE COMES WITH A 5 YEAR WARRANTY AGAINST MANUFACTURING DEFECTS.
THIS WARRANTY DOES NOT COVER PHYSICAL DAMAGE, WEAR AND TEAR OR IMPROPER OPERATION.
WARRANTY DOES NOT COVER NORMAL BATTERY PERFORMANCE LOSS OVER TIME.
SOLAR FIXTURE PERFORMANCE IS HEAVILY INFLUENCED BY THE ENVIRONMENT. SUNLIGHT LEVEL, EXTREME
TEMPERATURES, SNOW, DIRT, AND PROGRAM SLECTION WILL AFFECT PERFORMANCE.
FOR INSTALLATIONS WHERE LIGHTING IS REQUIRED AT ALL TIMES, THE SL-SAL-HYB HYBRID SOLAR AREA LIGHT
SHOULD BE USED AND CONNECTED TO A RELIABLE POWER SOURCE.
INSTALLATION REQUIREMENTS
MODEL
SL-SAL-OG-50W
SL-SAL-HYB-50W
CONTENTS
• CARTON 1: SL-SAL LIGHT FIXTURE
• LIGHT FIXTURE
• INSTRUCTIONS
• TOOLS AND HARDWARE
PRE- INSTALLATION INSTRUCTIONS
Pre-Installation Notes:
1) The lights come programmed to operate with a standard program. At sunset, the lights
will come on for 2 hours at 80% constant output. After 2 hours, the lights will transition to
sensor mode with 80% high and 20% low settings, 1 minute dwell time.
2) Confirm contents listed above.
3) Select a site that gets direct sunlight and is not blocked by trees, buildings, structures etc.
4) Confirm that no light sources will shine on the solar panel during the night-time hours.
The solar panel functions like a photo-cell. If there is light on the solar panel, the LED
lights will not come on.
5) The light needs 1-2 days to get on the proper charge/discharge cycle. Do not expect the
best performance the first nights that the light is in operation.
6) Confirm that the pole is strong enough to support EPA and weight listed above.
lf any extreme, or abnormal conditions exist, please take these into account.
6) Review Solar Best Practice Guidelines on the Solera-Solar.com web site under Marketing
Materials.
INSTALLATION
INSTALL ON 2 3/8 INCH TENON.
VERTICAL TENON PREFERRED.
CONFIRM THAT POLE OR STRUCTURE WILL SUPPORT
WEIGHT OF 86 LBS AND EPA OF 6.61 Square Feet.
FOR HYBRID OPERATION, 120-277VAC, 50/60Hz IS
REQUIRED (FOR SL-SAL-HYB ONLY). MAXIMUM POWER
DRAW IS 0.63 A.
• CARTON 2: SL-SAL-50W-2PANELKIT – SOLAR PANEL KIT
• SOLAR PANELS (2)
• MOUNTING BRACKET KIT
• Y-CABLE
• EXTENSION CABLE
• TOOLS AND HARDWARE
INSTALLATION AND USERS GUIDE
BASE TEMPERATURE
RANGE
2 3/8" SLIP FITTER Operating
Temperature:
-40F to 140F
Battery Charge
Temperature:
-4F to 140F
04/03/2023
