Light Efficient Design Remphos Outdoor Series Installation Manual

Outdoor Series
RP-SAL-8W-50K-SF-GY-G1, RP-SAL-30W-50K-SF-GY-G1
MODEL
RP-SAL-8W-50K-SF-GY-G1
RP-SAL-30W-50K-SF-GY-G1
Installation:
1. Take out the fixture and the tools from the package.
2. Remove the small plastic on the bottom of the remote and press the power
button on the remote.
3. Cover up the solar panel (you can use the package to cover up the solar
panel entirely or flip the fixture, so the solar panel is facing the ground) and
check if the light module turns on once power is pressed on the remote. When
the light is on a green light will be displayed either flashing or still depending
on its charge state. If the fixture does not turn on, please place it under
sunlight, as the battery may need to charge. For the light to charge, it
needs to be ON. Please wait a few minutes with the light under the sun
and then press the power button on the remote. Make sure the red light
is blinking which indicates that it is on and charging properly.
4. Use the remote control to power up and set up the necessary mode. The light
module will flash twice when receive the signal from remote control (The default
setting is motion sensor mode 40%-100%). Please refer to page 2 for the different
mode options. Pay special attention to your local sunshine and refer to the Best
Practices Solar Guide for additional understanding. The document can be found here
under the documents section and inside the box:
5. Using the dedicated tool to assemble the light body and the mounting accessories,
adjust the light fixture and LED module to the suitable angle.
6. Install the light to the round pole, square pole or wall, tighten the screws and the
nuts when fixed
INSTALLATION MANUAL
WATT NET WEIGHT
LUMEN
8W 1600LM
30W 6000LM
https://www.led-llc.com/sal
Use the remote control to
11.61 lbs.
Use the remote control to
29.76 lbs.
DIMMING
adjust
adjust
