Sennheiser E 865 Datasheet

Microphones |

General Description

The e 865 is a fully professional super-cardioid vocal microphone utilising
the very best in condenser microphone technology to achieve new stand-
ards of quality and sound. The microphone capsule incorporates special
blast/pop protection plate to shield the diaphragm from excessive sound
pressure levels.

Features

Rugged metal body
Extended dynamic response with pronounced presence and vocal 'punch'
Excellent feedback rejection
Very good rejection of handling noise
Very high sound pressure handling capability
Delivery includes: 1 e 865
1 microphone clip
1 pouch
Back-Electret Condenser Microphone

Technical Data

Pick-up pattern ...........................................................super-cardioid
Frequency response ................................................. 40 – 20,000 Hz
Sensitivity (free field, no load, 1 kHz).............................. 3 mV/Pa
Nominal impedance ................................................................. 200 Ω
Min. terminating impedance ..................................................... 1 kΩ
Equivalent noise level
A-weighted (DIN IEC 651)........................................................ 29 dB
CCIR-weighted (CCIR 468-3).................................................... 40 dB
Max. SPL (1 kHz)...............................................150 dB (THD = 6 %)
Dimensions ................................................................ Ø 47 x 193 mm
Weight ........................................................................................ 311 g

Profile

Super-cardioid professional vocal condenser microphone,
frequency response 40 Hz – 20 kHz, sensitivity (free field,
no load) 3 mV/Pa at 1 kHz, nominal impedance 200 Ω, min.
terminating impedance 1 kΩ, dimensions Ø 47 x 193 mm,
weight 311 g.
Cat. No. 004846
