- Page 1 Operating Instructions P1KL013 Retro-Reflex Sensor universal Subject to change without notice Available as PDF file only Version 2.0 www.wenglor.com...
-
Page 2: Table Of Contents
Table of Contents 1 General ................................... 1.1 Information Concerning these Instructions ........................1.2 Explanation of Symbols ............................... 1.3 Limitation of Liability ................................1.4 Copyrights ....................................2 For Your Safety ................................2.1 Use for Intended Purpose ..............................2.2 Use for Other than the Intended Purpose........................2.3 Personnel Qualifications.............................. -
Page 3: General
• The product is subject to further technical development, and thus the information contained in these operating instructions may also be subject to change. The current version can be found at www.wenglor.com in the product’s separate download area. INFORMATION The operating instructions must be read carefully before using the product and must be kept on hand for later reference. -
Page 4: Limitation Of Liability
• wenglor assumes no liability for printing errors or other inaccuracies contained in these operating in- structions unless wenglor was verifiably aware of such errors at the point in time at which the operat- ing instructions were prepared. -
Page 5: Copyrights
• All rights are reserved by wenglor. • Commercial reproduction or any other commercial use of the provided content and information, in particular graphics and images, is not permitted without previous written consent from wenglor. 1 ‒ General | P1KL013 ‒ Retro-Reflex Sensor universal... -
Page 6: For Your Safety
• The product is not suitable for use in potentially explosive atmospheres. • The product may be used only with accessories supplied or approved by wenglor, or in combination with approved products. A list of approved accessories and combination products can be found at www.wenglor.com on the product detail page. -
Page 7: Personnel Qualifications
In the event of possible changes, the current version of the operating instructions can be found at www.wenglor.com in the product’s separate download area. Read the operating instructions carefully before using the product. Protect the sensor against contamination and mechanical influences. -
Page 8: Technical Data
Technical Data General Data Technical Data Optical Data Range 5000 mm Reference Reflector/Reflector Foil RQ100BA Switching Hysteresis < 10 % Light Source Red Light Polarization Filter Service Life (T = +25 °C) 100000 h Max. Ambient Light 10000 Lux Light Spot Diameter see section Light Spot Diameter [} 9] Smallest Recognizable Part see section Smallest Recognizable Part [} 9]... -
Page 9: Light Spot Diameter
3.1.1 Light Spot Diameter Working Distance 0,2 m Light Spot Diameter 30 mm 180 mm 400 mm 3.1.2 Smallest Recognizable Part Distance, Sensor to Reflector 2,5 m Smallest Recognizable Part 10 mm 20 mm 30 mm 3.1.3 Switching Distance Achievable switching distance depends on the utilized reflector. The nominal switching distance is achieved with the reference reflector specified in the technical data. -
Page 10: Housing Dimensions
68 = supply voltage indicator Complementary Products wenglor offers you the right connection and mounting technology as well as other accessories for your product. You can find this at www.wenglor.com on the product details page at the bottom. 3 ‒ Technical Data | P1KL013 ‒ Retro-Reflex Sensor universal... -
Page 11: Scope Of Delivery
Scope of Delivery • Sensor • Safety precaution • BEF-SET-01 mounting set 3 ‒ Technical Data | P1KL013 ‒ Retro-Reflex Sensor universal... -
Page 12: Transport And Storage
Transport and Storage Transport Upon receipt of shipment, the goods must be inspected for damage in transit. In the case of damage, conditionally accept the package and notify the manufacturer of the damage. Then return the device, mak- ing reference to damage in transit. Storage The following points must be taken into consideration with regard to storage: •... -
Page 13: Installation And Electrical Connection
Installation and Electrical Connection Installation • Protect the product from contamination during installation. • Observe all applicable electrical and mechanical regulations, standards and safety rules. • Protect the product against mechanical influences. • Make sure that the sensor is mounted in a mechanically secure fashion. •... -
Page 14: Diagnosis
Legend Encoder A/A (TTL) Platinum measuring resistor Encoder B/B (TTL) Supply Voltage + not connected Encoder A Supply Voltage 0 V Test Input Encoder B Supply Voltage (AC Voltage) Test Input inverted Digital output MIN Switching Output (NO) Trigger Input Digital output MAX Switching Output (NC) - Page 15 1. Shut down the machine. 2. Analyze and eliminate the cause of error with the aid of the diagnostics information. 3. If the error cannot be eliminated, please contact wenglor’s support department. 4. Do not operate in case of indeterminate malfunctioning.
-
Page 16: Settings
To this end, the sensor is connected to a suitable IO-Link master (see product detail page/complementary products). The interface protocol and the IODD can be found at www.wenglor.com in the download area for the respective product. For information on installing and connecting the wTeach2 software and its structure, as well as information on the general functions, see the wTeach2 operating instructions. -
Page 17: Maintenance Instructions
Maintenance Instructions NOTICE This wenglor sensor is maintenance-free. Cleaning and inspection of the plug connections at regular intervals are advisable. Do not clean the sensor with solvents or cleaning agents that could damage the product. The product must be protected against contamination during initial start-up. -
Page 18: Proper Disposal
Proper Disposal wenglor sensoric GmbH does not accept the return of unusable or irreparable products. Respectively valid national waste disposal regulations apply to product disposal. 8 ‒ Proper Disposal | P1KL013 ‒ Retro-Reflex Sensor universal... -
Page 19: Declarations Of Conformity
Declarations of Conformity Declarations of conformity can be found on our website at www.wenglor.com in the product’s separate download area. 9 ‒ Declarations of Conformity | P1KL013 ‒ Retro-Reflex Sensor universal...
