INSTRUCTION FOR USE
MD
MOVER EL-EP-DR: 11992182
Mover EL-EP-DR is a mobile device designed to help a patient with a disability to be
moved by a caregiver over short distances and to facilitate moving the patient from
one sitting area to another. Mover EL-EP-DR is intended to provide support when the
patient is raised to a stand-up position from the bed, toilet, chair or the wheelchair.
The product is intended for patients who are able to stand, but not necessarily walk.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOVER EL-EP-DR and is the answer not in the manual?

Questions and answers

Related Manuals for Koval MOVER EL-EP-DR

Summary of Contents for Koval MOVER EL-EP-DR

  • Page 1 INSTRUCTION FOR USE MOVER EL-EP-DR: 11992182 Mover EL-EP-DR is a mobile device designed to help a patient with a disability to be moved by a caregiver over short distances and to facilitate moving the patient from one sitting area to another. Mover EL-EP-DR is intended to provide support when the patient is raised to a stand-up position from the bed, toilet, chair or the wheelchair.
  • Page 2 WARNING To avoid injuries always read this Instruction for Use and accompanied documents before using the product. Read Instruction for Use.

  • Page 3: Table Of Contents

    Sling ..........................10 Brakes ..........................10 The Control Box and Battery Use ..................11 Transfers with the Mover EL-EP-DR ..................14 From a Chair, Wheelchair, Bed or Toilet ................14 To a Chair, Wheelchair, Bed or Toilet ................15 Cleaning and Disinfection Instructions ................. 16 Care and Regular Yearly Checkups ..................

  • Page 4: Foreword

    Foreword Thank you for choosing Koval equipment. Your Mover EL-EP-DR belongs to a family of high-quality products intended to be used in the medical facilities, hospitals, nursing homes, rehabilitation units and other types of healthcare settings. Do not hesitate to contact us in case of queries about the operation or maintenance of your Koval equipment.
  • Page 5 For spare parts contact Koval or your local Koval representative. The Koval contact information is included on the last page of this IFU. Definitions in this IFU: WARNING Safety warning.

  • Page 6: Intended Use

    This product should be used according to the intended purpose and these safety instructions. Everyone using this equipment should read and understand these instructions, which are included in this Instruction for Use (IFU). In case of doubts feel free to contact Koval or your Koval representative at any time.

  • Page 7: Safety Instructions

    Safety Instructions WARNING To prevent client falls or caregiver injuries make sure that there are two caregivers present during the transfer of a client if this is necessary according to the client state. WARNING To prevent the device from tipping do not raise or lower other equipment, such as a bed, shower trolley, lift, or a bedside table, close to it and pay attention to the stationary object when lowering or lifting.

  • Page 8: Assembly Of Mover El-Ep-Dr

    Cut the straps securing the cardboard box to the pallet. Unpack the Mover EL-EP-DR. Remove all protective foil and foam from casters, seat upholstery and handles. The Mover EL-EP-DR is now ready for use – no further installation is required. Preparation Before First Use (10 Steps) Visually inspect the Mover EL-EP-DR for transport damages.

  • Page 9: Mover El-Ep-Dr Driving Directions

    To prevent cross-contamination always follow the disinfection instructions from this IFU. Make sure that the battery is charged. Mover EL-EP-DR driving directions The driving direction during transport, as well as the left and right side are illustrated below (sides are marked pursuant to patient position).

  • Page 10: Parts Designation

    18 Sling Product Description / Functions Mover EL-EP-DR is a mobile (wheeled), non-self-propelled device designed to help a caregiver to safely move a patient with a disability (e.g., geriatric, injured, with disabilities) across short distances, and to facilitate transferring the patient from one sitting area to another (e.g., from a chair, wheelchair to a toilet, bed and back).

  • Page 11: Raising/Lowering The Patient

    Four swivel double-wheel casters with 75 mm of diameter for improved maneuverability. The rear casters are furnished with a brake. Mover EL-EP-DR ensures fast, stable and safe transfer of the patient. Mover EL-EP-DR has electrically powered raising/lowering system, for easier patient handling.

  • Page 12: Adjusting The Flexible Base Width

    Adjusting the flexible base width The width of the flexible base of the Mover EL-EP-DR can be adjusted via a handset. Use the bottom controls for adjusting the flexible base width via an electric actuator. Rotating the padded seats Rotate one part of the two-part seat in either direction from the open position to position underneath the patient.

  • Page 13: Sling

    Double wheel swivel casters Ø75 mm with a brake. Apply the break of each caster individually. WARNING To avoid injuries always lock the brake when Mover EL-EP-DR is stationary. WARNING To avoid injuries, ensure that the casters are locked when transferring the patient.

  • Page 14: The Control Box And Battery Use

    The Control Box and Battery Use The complete system consists of a control box and a battery enclosed in a single elegant module. The Mover EL-EP-DP batteries must be charged at least 24 hours before first use or, if possible, longer to ensure proper functioning and prolong the lifetime of a battery.
  • Page 15 WARNING Make sure that the mains voltage corresponds to the voltage on the rating plate of the battery charger. WARNING Always remove the charging cable before use. WARNING Check the charging cable every week. WARNING The battery can only be charged directly via the Mover EL-EP-DP when there is no one using it.
  • Page 16 Emergency Stop Button If, for any reason, the Mover EL-EP-DP cannot be controlled via the handset buttons, stop the movement of the Mover EL-EP-DP by pressing the emergency stop button (see Figure 1). In this case, contact qualified personnel for help. If you press the red emergency stop button on the control box, all the battery powered functions will be switched off.

  • Page 17: Transfers With The Mover El-Ep-Dr

    2 Open up both parts of the two-part seat by manually pulling them to the side and upwards. 3 Adjust the flexible base of the Mover EL-EP-DR, with handset if needed, and approach the patient. (See Fig. 1.) Fig. 1...

  • Page 18: To A Chair, Wheelchair, Bed Or Toilet

    To a Chair, Wheelchair, Bed or Toilet (8 steps) 1 Approach the chair and adjust the flexible base of the Mover EL-EP-DR, if needed. 2 Bring the patient over to the chair and apply the brakes. 3 Raise the patient and rotate the two parts of the seat up.

  • Page 19: Cleaning And Disinfection Instructions

    Cleaning and Disinfection Instructions The Mover EL-EP-DR is recommended to be cleaned and/or disinfected regularly between each use, if necessary, or daily, as a minimum. If the Mover EL-EP-DR is soiled or in case of suspected contamination, follow the recommended cleaning and/or disinfection procedures below before using the equipment.
  • Page 20 2 Mix the disinfectant according to the instructions on the product label or according to the mixing ratio in the IFU. 3 Apply the disinfectant on the Mover EL-EP-DR. 4 Allow for disinfection time according to the instructions on the product label.

  • Page 21: Care And Regular Yearly Checkups

    Care and Regular Yearly Checkups The Mover EL-EP-DR is subject to normal wear and tear; therefore, the following actions should be performed as specified to make sure that the product retains its original manufacturing specification. Koval or your local Koval representative shall carry out a regular yearly checkup by prior agreement.
  • Page 22 • Verify that there are no cracks or tears. In the event of damage replace damaged parts to avoid cross contamination. (See Parts Designation section) Yearly Checkups by Qualified Personnel Only Mover EL-EP-DR must be checked once a year in accordance with the Maintenance and Repair Manual. WARNING...

  • Page 23: Mover El-Ep-Dr Storage And Transport

    CAUTION: Failure to lock the casters in the braking position can cause the Mover EL-EP-DR to move automatically. Mover Operating Conditions The operating temperature must range from +5°C to +40°C. Humidity must range from 20% to 80% and atmospheric pressure must range from 700 to 1060hPa.

  • Page 24: Electric System (Technical Specification)

    Electric system (Technical specification) Control box • Protection class: IPX4 • Approx. 40 cycles per charge • Mounting without a bracket • Soft start • Emergency stop button • Buzzer sounds if battery capacity is low (2–10 cycles left) • Front cover with: green LED for handset activation, yellow LED for charging, button for electrical lowering in case of emergency •...

  • Page 25: Actuator (Raising/Lowering Adjustment)

    • Storage temperature: - 10°C to + 50°C • Approvals: IEC60601-1:2005 3rd edition, ANSI/AAMI ES60601-1:2005 3rd edition, and CAN/CSA-22.2 No 60601-1:2008. • HB30 is designed and tested according to IPX6 (washable) pursuant to EN60601-2-52 cl. 201.11.6.6.101 (Machine washable medical beds) Actuator (raising/lowering adjustment) •...

  • Page 26: Wiring Diagram

    Emission LINAK Actuator Systems are CISPR 11, Group 1, Class B products, and comply with IEC 61000-3-2, Class A and IEC 61000-3-3. WARNING Use of accessories, transducers and cables other than those specified or provided by the manufacturer of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and result in improper operation.

  • Page 27: End Of Life Disposal

    Control box IP X4 Ingress Protection The protection against contact and ingress of objects is not specified for this product Protect from splashing water regardless of the direction they come from. Water splashing against the enclosure from any direction shall have no harmful effect, utilizing either: a) an oscillating fixture, or b) a spray nozzle with no shield.

  • Page 28: Dimensions

    Dimensions...

  • Page 29: Troubleshooting

    Troubleshooting Troubleshooting for Mover EL-EP-DR NOTE: If the product does not work as intended, immediately contact Koval or your local Koval representative for support. PROBLEM ACTION 1 Activate the emergency stop button. The electric raising/lowering system raises or lowers after the handset buttons are 2 Remove the patient from Mover EL-EP- DR and contact qualified personnel.
  • Page 30 2 Verify that all casters rotate and swivel EL-EP-DR during transport. freely. 3 If the problem still persists, immediately stop using the Mover EL-EP-DR and contact qualified personnel. Rotating padded seats are difficult to open Check for debris or hair in the seat pivot.

  • Page 31: Labels

    Labels Label explanation Manufacturer Catalogue number, Catalogue number Serial number, Batch Identification code, Model name, Serial number Data label Manufacturing date, Manufacturer, Safe Batch code working load. Labels on Manufacturer, product Medical Device electrical data. components European Conformity Warning Warning about Mark label improper use...

  • Page 32: Label Placement

    Temperature range Humidity range Atmospheric pressure range Label placement Product label:...

  • Page 33: Approvals And List Of Standards

    Approvals and List of Standards Product complies with the European Regulation (EU) 2017/745 of the European Parliament and of the Council of 5 April 2017 on medical devices: - Classified as Class I medical devices as set out in Annex VIII of Regulation (EU) 2017/745 - Complies with the provisions of Regulation (EU) 2017/745 “Medical Devices”...

  • Page 34: Maintenance Record Sheet

    © Koval 2023. Pursuant to our policy of continuous improvements we reserve the right to modify our design without prior notice. The content of this publication may not be reproduced in whole or in part without Koval’s prior consent. REV 04: 03/2023...
