- Page 1 ELECTRIC SIT-STAND DESK Instruction Manual D-THO-4824SS HJ-Customer-Service@outlook.com (909)637-7665 | (909)637-7593 EST 9:00AM--17:00PM...
- Page 2 Beam Left Leg Right Leg Drive Rod Side Plate Leg Base Board Board Board Square Board Desk Connection Hook Rectangular Board Power Supply Hand Controller Wire Plate Drawer Desk Connection Plate Cable Hole Cover Wooden Pin Cable Clip Silicone Sheet Hidden Screws...
- Page 3 Screws Screws Screws Screws Screws 2.5mm Screws Board Screws Wrench Wrench Screwdriver is required during the installation please prepare it in advance. Step 1 Align the holes of Left Leg (2) and Drive Rod (4), using Wrench (M-H) to secure both with Screw (M-A).
- Page 4 Step 2 Insert Drive Rod (4) into the hole of Right Leg (3). If it cannot be inserted tilt Right Leg (3) slightly until they’re matched. Step 3 As shown, use Wrench (M-I), install Beam (1) to the Legs (2&3) with Screws (M-B)*6.
- Page 5 Step 4 Step 5...
- Page 6 Step 6 Step 7...
- Page 7 Step 8...
- Page 8 Step 9 Step 10...
- Page 9 Step 11 Step 12...
- Page 10 Step 13 Step 14...
- Page 11 Step 15 Step 16...
- Page 12 Step 17 Step 18...
- Page 13 Step 19 Step 20...
- Page 14 Step 21...
- Page 15 Step 22...
-
Page 16: Using The Controller
Using the Controller Raise the Desk Press the button to raise the desk continuously until it reaches the highest position or the button is released. Lower the Desk Press the button to lower the desk continuously until it reaches the lowest position or the button is released. -
Page 17: Child Lock
Settings Reset Press and hold the button until 'rst' is displayed. Continue holding until the desk goes down to its lowest level and comes back up slightly. Release the button, and reset is complete. If the button is released during the reset procedure, reset will stop. The desk won't work until reset is done correctly. - Page 18 Protection Mode Error Codes Standby Overvoltage Protection: Standby voltage too high. Power o the desk, check the connection between power and the controller, and power on again. If error code persists, please contact technical support. Power Supply Overvoltage Protection: Input voltage too high. If the correct AC adapter is being used, power o the desk, check the connection between power and the controller, and power on again.
- Page 19 Overloading Protection: Max load exceeded. Error code will persist for 20 seconds (DO NOT operate). Take the things o the desk and confirm there is no mechanical damage before trying again. Motor Phase Error Protection: Power o , check the cable connection between the motor and the controller, and power back on again.
- Page 20 Technical Support (909)637-7665 | (909)637-7593 Other Info HJ-Customer-Service@outlook.com Thank you for choosing this product. We strive to provide you with the best quality products and service in the industry. Should you have any issues, please don't hesitate to contact us. https://hlinstallationvideos.s3.amazonaws.com/D-THO-SS-Electric+Sit-stand+Desk.mp4...
