Garmin FUSION SM Series Installation Instructions Manual

SM Series Speakers Installation Instructions
Important Safety Information
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
This device must be installed according to these instructions.
Disconnect the vessel's power supply before beginning to install this device.
Continuous exposure to sound pressure levels over 100 dBA may cause permanent hearing loss. The volume is
typically too loud if you cannot hear people speaking around you. Limit the amount of time you listen at high
volume. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked.
Always wear safety goggles, ear protection, and a dust mask when drilling, cutting, or sanding.
When drilling or cutting, always check what is on the opposite side of the surface.
It is strongly recommended that you have your audio system installed by a professional installer to ensure
optimum performance.
You must read all installation instructions before beginning the installation. If you experience difficulty during
the installation, go to support.garmin.com
After installing an audio system, you should run the connected speakers and subwoofers at low to medium
volumes for the first few hours of use. This helps to improve the overall sound by gradually loosening up the
moving components of new speakers and subwoofers, such as the cone, spider, and surround.
Tools Needed
• Electric drill
• Drill bit (size varies based on surface material)
• Appropriate saw or utility knife to cut surface material
• Phillips screwdriver
• Wire strippers
• 16 AWG (1.3 through 1.5 mm
You can purchase this wire from your FUSION
◦ 010-12899-00: 7.62 m (25 ft.)
◦ 010-12899-10: 15.24 m (50 ft.)
◦ 010-12899-20: 100m (328 ft.)
• Crimping tool
• Electrical tape
• Marine sealant (optional)
NOTE: For customized installations, additional tools and materials may be needed.
