- Page 1 AI Conference Speakerphone User Manual...
-
Page 2: Product Introduction
Product Introduction AIMIC-M12 Pro is a 360° noise-canceling conference microphone speaker designed spec- ifically for enterprise conference rooms by AISPEECH. It is an intelligent conference micr- ophone speaker that combines sound collection, sound amplification, speech transcription, and subtitle simultaneous transmission. The product uses a 12-element omnidirectional... -
Page 3: Accessories List
Product Introduction Accessories List AIMIC-M12 Pro USB cable Power adapter Ethernet cable Dongle User manual... - Page 4 Product Introduction Buttons and indicator lights instructions Speech transcription Bluetooth Press and hold 2 seconds to enable or disable Indicator status： White light on:bluetooth connected White light flashing:bluetooth pairing Light off:bluetooth disabled...
- Page 5 Product Introduction Buttons and indicator lights instructions Vlume down Microphone mute Vlume up Press to reduce volume Press to switch microphone Press to increase volume status Indicator status Red light on：Mute Green lighte on：Unmute...
- Page 6 Product Introduction Light color instructions Status Indicator status Power on Green light on Standby Green light breathing Unmute Green light Mute Red light on Asleep Light off Ungrading Blue light breathing...
-
Page 7: Interface Instructions
Product Introduction Interface instructions Cascade port USB Type-A For POE power supply and cascading For debugging DC power port USB Type-C 12V/2A power suppply For connecting to PC Lockhole Security lock port... -
Page 8: Device Connection
Instruction for use 1.Device connection * USB connection Power on device,connect the device to the computer through the attached USB cable. When you hear the prompt tone, the connection is successful. * Bluetooth connection Power on device，the bluetooth name is “AIMIC-M12-****”(the last four figures of S/N). 1）Bluetooth Dongle connection Insert the Bluetooth Dongle into a PC or conference screen,activate the Bluetooth of M12 Pro,open the Bluetooth settings page of the computer system, select M12 Pro to... - Page 9 Instruction for use 2.Devices cascaded * Cascaded connection（via Ethernet cable） 1）Applicable for cascade usage of two M12 devices. 2）Power on and start the first device using the power adapter. 3）The first device enters standby mode and the light shows green breathing status. 4）Power on the second device using the power adapter, and then connect it to the first device using the Category 6 Ethernet cable.
- Page 10 Instruction for use 2.Devices cascaded * Cascaded connection（via POE switch） 1）Applicable for cascade usage of 2 to 5 M12 devices 2）The first device is connected to the POE switch via a Category 6 Ethernet cable (incl- uded in the package), powered on and activated. 3）The next device is also connected to the POE switch via a Category 6 cable (included in the package), powered on and activated.
- Page 11 Instruction for use 2.Devices cascaded * Master/Slave devices 1）The computer is connected to any device via USB, and the connected device is the "master device", while other cascaded devices are "slave devices". 2）The device status of the "master device" and "slave devices" are synchronized, and the button presses and light effects are also synchronized.
-
Page 12: Basic Parameter
Basic Parameter Product Name AI Conference Speakerphone Product Model AIMIC-M12 Pro Product Dimensions 250mm*119mm*39mm Bluetooth Bluetooth V5.1 Microphone 12 omnidirectional analog MEMS Pickup Radius 5 meters Speakers 8W*2 Cascade mode Ethernet cable Cascading Quantity 2 units~5 units Adapter Power Supply POE Power Supply IEEE 802.3at standard... - Page 13 —Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Brand Owner: AISpeech Technology Co., LTD. Email: aimic_support@aispeech.com...
