  • Page 1 AC-STAND-FIXED INTERACTIVE FLAT PANEL STAND/CART USER MANUAL...

  • Page 2: Product Information

    Product Information Product Information The AC-STAND-FIXED is designed to fit interactive flat panel displays up to 86 inches. Please review this guide to learn how to safely use your product. Specifications: Model AC-STAND -FIXED VESA Dimensions 200x200, 400x200, 400x300, 400X400, 600X400, 800X400...
  • Page 3 Product Information Product Information The AC-STAND-FIXED is designed to fit interactive flat panel displays up to 86 inches. Please review this guide to learn how to safely use your product. Mounting Strips Back Plate Middle Shelf Uprights Front View of Stand 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com...
  • Page 4 Directional Caster Wheels Base with Casters Brake/Lock Caster Wheels Right View of Stand panel not included 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...

  • Page 5: Installation Instructions

    Do not use a box cutter. Step-3: Your Stand arrives in 1 box and contains 4 layers for ease of assembly. Layer 1 Layer 2 Layer 3 Layer 4 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...

  • Page 6: Identifying Parts

    Left Mounting Strip Right Mounting Strip Left Upper Pillar Right Upper Pillar Hardware & Tool Middle Shelf Right Upright Left Upright (holes face out) (holes face out) Base with Casters 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...
  • Page 7 Step-3: Slide both left and right Uprights into the Base’s posts. Step-4: Loosely fit the screws connecting the left and right uprights to the base of the stand. Do not fully tighten hardware at this point. 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...
  • Page 8 Step-6: Slide it in place so the notches are toward the long (back) edges of the Uprights. Step-7: Loosely fit the screws on the outside of the left and right uprights to connect the middle shelf. Do not fully tighten hardware at this point. 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...
  • Page 9 Step-9: Fit them into the Uprights so the 4 holes are facing the sides. Step-10: Loosely fit the screws connecting the left and right upper pillars to the uprights. Do not fully tighten hardware at this point. 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...
  • Page 10 Facing the back of the stand, Fit the Backplate onto the Uprights so the post slides are Step-12: facing you. Loosely fit the screws connecting the backplate onto the upper pillars. Do not fully tighten Step-13: hardware at this point. 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...
  • Page 11 Starting from the top, working to the bottom, tighten all hardware with the provided hex Step-14: wrench. The Left and Right Mounting Strips are installed on your flat panel screen using your own Step-15: VESA mounting bolts and hung onto the Backplate. 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...
  • Page 12 “With a simple release of the blue foot pedal, pedal, allowing you to navigate effortless with embrace a world of precision and grace in your unparalleled flexibility. swivel motion, making maneuvering a breeze.” 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...

  • Page 13: Safety Instructions

    For warranty claims, please have the following information ready, then visit : www.powertechnologies.com To create a help ticket. Serial Number: ------------------------------------------------------------------------------------ Charging System Type: ------------------------------------------------------------------------------------ Date Of Purchase: ------------------------------------------------------------------------------------ Reseller Name: ------------------------------------------------------------------------------------ PO Number: ------------------------------------------------------------------------------------ 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...

  • Page 14: Further Information

    Further Information Further Information For further information on this product and others, contact Power Technologies at. Power Technologies 42035 Zevo Dr Temecula, CA 92590+ 888.650.4488 support@powertechnologies.com www.powertechnologies.com 42035 Zevo Drive Temecula, CA 92590 | 888-650-4488 | www.powertechnologies.com PT-AC-STAND-FIXED Manual_Rev2024-04...
