- Page 1 RAK19007 Water Resistant Case Assembly Guide Requires: Phillips Screwdriver RAK Meshtastic kit mounting hardware...
- Page 2 Step 1: Using the double sided Step 2: Using double sided adhesive mount the Bluetooth antenna in adhesive mount the GPS antenna the most upper right hand corner of the in the slot at the top of the base board tray sidewall...
- Page 3 Step 3: Insert the Step 4: Using the RAK Meshtastic kit button extension into hardware mounting screws, secure the the base board tray RAK19007 to the base board tray...
- Page 4 Step 5: Attach Step 6: Connect the Step 7: Connect the your preferred GPS IPEX connector LoRa and BT IPEX SMA antenna connectors...
- Page 5 Step 8: Connect battery connector Step 9: Slide the base board tray and lay battery on top of base board tray and battery into the case body (secure battery with your preferred method)
- Page 6 Step 10: Insert the Step 11: Secure the faceplate faceplate into the case and base board tray using the body aligning the screw provided M2x16mm screws holes...
- Page 7 Step 12: Complete the assembly by screwing on the case cap...
