Summary of Contents for ROKLAND MESHTASTIC T-Beam Supreme Case
- Page 1 T-Beam Supreme Case Assembly Guide Requires: Phillips Screwdriver (J0) Hex Screwdriver (#3)
- Page 2 Step 1: Disconnect LoRa & GPS IPEX connectors...
- Page 3 Step 2: Gently un-adhere the GPS antenna from the battery casing...
- Page 4 Step 3: Using a Phillips screwdriver remove all 6 Phillips screws...
- Page 5 Step 4: Remove the T-Beam S3 Core...
- Page 6 Step 5: Gently fold the screen upward and remove the adhesive holding the GPS antenna and SMA pigtail in place...
- Page 7 Step 6: Re-route the SMA pigtail behind the screen ribbon, but above the screens connector to the base board. The GPS antenna will follow its original path.
- Page 8 Step 7: Gently fold the screen back into place and route the IPEX connectors into their intended slots. The wires should not be pinched down and should have some wiggle room.
- Page 9 Step 9: Secure the screen to the Step 8: Double check for base board with one of the pinch/pressure point on the SMA smaller Phillips screws and GPS wires.
- Page 10 Step 10: Re-connect the T-Beam Step 11: Re-connect the LoRa S3 Core back to the base board and GPS IPEX connectors and secure it using one of the smaller Phillips screws...
- Page 11 Step 12: Insert the button extension into their intended slots on the case frame.
- Page 12 Step 13: Route the SMA connector into case frame and slide the GPS antenna into its slot, then slide the base board into the case frame starting on the side nearest to the SMA connector. Gently push the side with the Type-C port down into place.
- Page 13 Step 14: Secure the SMA connector pigtail...
- Page 14 Step 15: Secure the base board to the frame on the side nearest to the Type-C port with the two M2 nuts and two M2x16mm Phillips screws that are provided with the case...
- Page 15 *Caution- if you plan on using adhesives such as super glue as extra support for the acrylic window it can cloud it. Step 16: Insert the acrylic window into the front cover and push it into place. Then place the front cover on the frame.
- Page 16 Step 17: Attach the SMA antenna and insert the 18650 battery into its slot. Double check the polarity aligns correctly on the battery.
- Page 17 Place nut Hold nut in place Hold nut in place with finger then with finger then insert screw insert screw Step 18: Attach the back cover to the frame using the M3 screws and nuts. Make sure the slot for the GPS Screw in screw Screw in screw properly aligns.
