  • Page 1 Speech 100 M Conference System...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 12.03.2024, ID: 438815 (V3)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Installation..............................11 Connections and controls........................14 Operating controls on the device....................18 Operating on a PC........................... 24 Technical specifications........................36 Plug and connection assignment....................
  • Page 4 Speech 100 M Conference System...

  • Page 5: General Information

    Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.

  • Page 7: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended for use as a digital conference system. The device is designed for pro‐ fessional use only and is not suitable for use in households. This device is meant for indoor use only.
  • Page 8 Safety instructions DANGER! Danger to life due to electric current! A short circuit could lead to a fire hazard and risk of death. Always use proper ready-made insulated triple-core mains cable with a safety plug. Do not modify the mains cable or the plug. In case of isolation damage, disconnect immediately the power supply and arrange repair.
  • Page 9 Safety instructions NOTICE! Damage to the device due to high voltages! The device can be damaged if it is operated with the incorrect voltage or if high voltage peaks occur. In the worst case, excess vol‐ tages can also cause a risk of injury and fires. Make sure that the voltage specification on the device matches the local power grid before plugging in the device.

  • Page 10: Features

    Speech 100 M (item no. 438815), the presidential station the t.bone Speech 100 C (item no. 438819) as well as the delegate station the t.bone Speech 100 D (item no. 438820). At www.thomann.de, you can download software for the conference system that allows you to control the conference conveniently from your PC.

  • Page 11: Installation

    Installation Installation NOTICE! Danger of short circuit due to use of unbalanced XLR cables! The device has a phantom voltage input. Using unbalanced cables with the phantom power may damage the device. Use only balanced cables. Before switching on phantom power, always make sure that no unbalanced wired cables are connected.
  • Page 12 Installation The conference system is a plug-and-play system designed for use in small and medium-sized conferences and events. The call stations are connected to each other as well as to the control centre via system cables. The system cables handle the transmission of the digital voice and status information as well as the power supply of the call stations.
  • Page 13 2 lines with each up to 16 call stations can be connected to the control centre. If control via software is desired (available for free at www.thomann.de), the connection to a PC is made via the PC connection over an Ethernet switch. The network connection defaults to DHCP.

  • Page 14: Connections And Controls

    Connections and controls Connections and controls Front panel ö & SPEECH 100 M Speech 100 M Conference System...
  • Page 15 Connections and controls 1 USB interface. Saving conference recordings to a USB storage device. Play back conference recordings or background music from a USB storage device. 2 [Discuss Mode / Voting (Push & Hold 3S)] | Press button for approx. 3 seconds: Voting mode. Short push of the button: Discussion mode 3 Display.
  • Page 16 Connections and controls 11 [PRE / EQ (Push & Hold 3S)] | Press button for approx. 3 seconds: Calls up the EQ settings. Short push of the button: Starts playback of the previously made recording. 12 [Feedback Killer] | Enabling and disabling feedback suppression. Rear panel ö...
  • Page 17 Connections and controls 1 [LAN] | Connection socket for LAN network cable 2 [Alarm in] | Terminal for external alarm system 3 [MIC Input] | Microphone input, XLR panel socket for microphone connection with phantom power (interpreter input) 4 [Output] | Main output (Main Out) for connecting amplifiers or active speakers 5 [Input] | Input for connecting external input devices with line level for alarm mode 6 [Rec Output] | Audio output for connecting external recording devices 7 [Conference] / [MIC Input] | Sockets for connecting call station units...

  • Page 18: Operating Controls On The Device

    Operating controls on the device Operating controls on the device Setting a password You can lock the control centre of the conference system with a password. To unlock the system, press any button on the control panel. Then enter the password. Press [MONITOR] for about 3 seconds.
  • Page 19 Operating controls on the device To exit the equalizer settings table, press [REC / Exit]. You can make the following settings in the table: Type Freq Gain dB Bypass Bypass Zero Zero Zero 19.7 20160 But6 Zero Zero Zero Bes6 Zero Zero Zero...
  • Page 20 Operating controls on the device Type Freq Gain dB Bypass Bes30 Zero Zero Zero But36 Zero Zero Zero Bes36 Zero Zero Zero Lin36 Zero Zero Zero But42 Zero Zero Zero Bypass Zero Zero Zero 19.7 20160 But6 Zero Zero Zero Bes6 Zero Zero...
  • Page 21 Operating controls on the device Type Freq Gain dB Bypass But30 Zero Zero Zero Bes30 Zero Zero Zero But36 Zero Zero Zero Bes36 Zero Zero Zero Lin36 Zero Zero Zero But42 Zero Zero Zero EQ1…EQ8 Peak ON / OFF 19.7 20160 -12 dB +12 dB...
  • Page 22 Operating controls on the device Setting discussion mode You can set 5 different discussion modes. 1, 3, 6, 9 or all call station microphones can be acti‐ vated at the same time. Press [Discuss Mode / Voting (Push & Hold 3S)] briefly. ð...
  • Page 23 Operating controls on the device To exit the voting mode, press [REC / Exit]. Enabling or disabling feedback The feedback suppression prevents possible noise (whistling) through the microphone. suppression Press [Feedback Killer] to engage the feedback suppression. ð [Feedback Killer] lights up blue. ‘FBC’ is displayed in the upper right corner of the dis‐ play.

  • Page 24: Operating On A Pc

    Operating on a PC Operating on a PC Connecting devices Click to locate the conference system on the LAN and connect to your PC. If the device is not found for a while, the search is stopped. Try using again to connect the devices.
  • Page 25 Operating on a PC Overview ö & Speech 100 M Conference System...
  • Page 26 Operating on a PC 1 [Device] / [Voting] | Toggles the view. By default, the [Device] overview is selected. Voting can be performed under [Voting]. 2 [CONNECT] / [DISCONNECT] | When the conference system is connected to the PC, [DISCONNECT] appears to discon‐ nect, the display panel lights up green and the current firmware version is displayed.
  • Page 27 Operating on a PC Stations settings Under , double-click the station icon in the right window area to change the sta‐ tion name. You can set three options for each station: : Mute microphone : Microphone on : Microphone switched off Speech 100 M Conference System...
  • Page 28 Operating on a PC The station of the conference chairman is displayed in red. The delegate stations are displayed in white. Speech 100 M Conference System...
  • Page 29 Operating on a PC Setting the equalizer Under you can make settings for the entire system in the right window area. Speech 100 M Conference System...
  • Page 30 Operating on a PC Discussion mode Click to open the panel. In this section, select the number of microphones to be set. to switch off all stations except the chairman's station. Click again to cancel the shutdown. Click , and then click one of the delegate stations to the right except the chair‐ man's station to turn it off.
  • Page 31 Operating on a PC Adjusting the volume Click to open the panel. Adjust the volume in this area. Use the left control to set the speaker volume. Use the right control to set the microphone volume. Speech 100 M Conference System...
  • Page 32 Operating on a PC Playing / recording MP3 files Click to open the panel. When a mobile storage device is attached to the host, the host will recognize the device and play MP3 files stored on it. When you click the record button , playback stops and recording starts. If the storage medium is not detected, the power supply may be insufficient.
  • Page 33 Operating on a PC Setting an individual station Select one of the stations in the device list. ð On the right, 2 compression and equalizer panels are displayed. You can make and save the respective settings and load presets. Speech 100 M Conference System...
  • Page 34 Operating on a PC Voting mode Click and switch to Voting view. to set how long the voting should last. to start the voting process. Speech 100 M Conference System...
  • Page 35 Operating on a PC to end the voting process. The right window area shows the progress of the voting process. Voting is only possible when the conference system is connected. During voting, you can not switch to setting mode. There can be no voting when all delegate stations are turned off. When the conference system is disconnected from the PC, the voting can not be ended and the view is switched.

  • Page 36: Technical Specifications

    Technical specifications Technical specifications Input connections Power supply C14 rubber panel plug Microphone input XLR panel socket, balanced Frequency response 200 Hz 6 kHz at 0 dBu ±1.5 dB Speech-optimised Total harmonic distortion < 0.01% at 0 dBu 1 kHz (THD) Signal-to-noise ratio 97 dB...
  • Page 37 Technical specifications Max. input level +10 dBu Frequency response 200 Hz 6 kHz at 0 dBu ±1.5 dB Speech-optimised Total harmonic distortion < 0.01% at 0 dBu 1 kHz (THD) Output connections Stereo Out Cinch sockets Max. output level +10 dBu Stereo Rec Out 2 ×...
  • Page 38 Technical specifications Treble (high pass or high shelf) Digital signal processing Digital signal processor 32 bit A/D-D/A converter 32 bit Power consumption 350 W Supply voltage 100 - 240 V 50/60 Hz Fuse for 110 V 5 mm × 20 mm, 6.3 A, 250 V, slow blow for 230 V 5 mm ×...
  • Page 39 Technical specifications Block diagram Speech 100 M Conference System...

  • Page 40: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 41 Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) Speech 100 M Conference System...

  • Page 42: Cleaning

    Cleaning Cleaning Housing Use only pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. Speech 100 M Conference System...

  • Page 43: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 44 Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it.
  • Page 45 Notes Speech 100 M Conference System...
  • Page 46 Notes Speech 100 M Conference System...
  • Page 48 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
