Remote monitoring with app for Android/iOS
Quick operating instructions
stabo mul�fon security V
HD video monitoring system
Art. no. 51136 & 51137
For up to 4 cameras
Important
Read all opera�ng instruc�ons carefully and completely before using the device. Keep these opera�ng instruc�ons in
a safe place as they contain important informa�on on how to use the device.
stabo is environmentally friendly
In order to contribute to saving trees and reducing paper waste, the detailed opera�ng instruc�ons with care and
warning instruc�ons as well as warranty informa�on can only be found online:
h�ps://stabo.de/links/bda/mul�fon-security-v
Note: When aligning and opera�ng the camera, please ensure that you do not bring any neighbouring or public
areas into view!
Note: Due to the fact that the product and the so�ware are con�nually updated, there may be a discrepancy
between the opera�ng instruc�ons and the app interface. All instruc�ons are dependent on the actual user
interface.
In the box
7" HD colour monitor LCD, antennas
Plug-in power supply unit (12V DC/ 2.0A)
Weatherproof outdoor camera (IP66), antenna
Plug-in power supply unit (12V DC/ 1.0A) with 3 m cable
USB mouse with cable
RJ45 network cable
Brief opera�ng instruc�ons (German/English)
Assembly material
Before using the devices, check for external damage. If there is external damage, do not use the product, but contact
your specialist retailer immediately.
1
Advertisement
Related Manuals for stabo multifon security V
Summary of Contents for stabo multifon security V
- Page 1 Remote monitoring with app for Android/iOS Quick operating instructions stabo mul�fon security V HD video monitoring system Art. no. 51136 & 51137 For up to 4 cameras Important Read all opera�ng instruc�ons carefully and completely before using the device. Keep these opera�ng instruc�ons in a safe place as they contain important informa�on on how to use the device.
- Page 2 The camera at a glance 1 Antenna To ensure the op�mum range, the antenna should be posi�oned ver�cally. 2 Loudspeaker For 2-way audio. 3 2x white high-power LEDs The two LEDs enable coloured night vision. 4 Lens Keep the lens clean and free from obstruc�ons to get a clear and sharp image. 5 2x high-power infrared LEDs The two IR LEDs allow a black and white image to be generated in poor ligh�ng condi�ons.
- Page 3 The monitor at a glance 1 Antennas To ensure the op�mum range, the antenna should be posi�oned ver�cally. 2 Microphone For 2-way audio 3 Micro SD card slot (storage capacity max.128GB) For storing recordings 4 Hard disk compartment with cover (storage capacity max.6TB) For storing recordings 5 HDMI connec�on A monitor or a TV set with HDMI input can be connected to this output.
- Page 4 Note: A hard drive or micro SD card is required for storing recordings (manual, mo�on detec�on or schedule). Installa�on of a hard disk (2.5” SATA hard drive, max. 6TB) Note: The height of the hard disk must not exceed 7 mm. Note: Disconnect the monitor from the mains before installing the hard drive.
- Page 5 Monitor Place the monitor on a non-�l�ng, level surface and adjust the screen according to the viewing angle. Place the two antennas in a ver�cal posi�on. Connect the USB mouse to the USB connec�on If you want to access the system via smartphone, you can connect the monitor and your home network using a LAN cable.
- Page 6 Weight 334 g Simplified EU Declara�on of Conformity stabo Elektronik GmbH hereby declares that the radio system type stabo Mul�fon Security V complies with Direc�ve 2014/53/EU. The full text of the EU Declara�on of Conformity is available at the following internet address:...
-
Page 7: Manufacturer's Warranty
Manufacturer’s warranty As the manufacturer of this stabo mul�fon security V device, we, stabo Elektronik GmbH, Münchewiese 16, 31137 Hildesheim/Germany grant an independent warranty to the consumer on all items purchased from us in accordance with the following warranty condi�ons. We expressly point out that this does not restrict your statutory rights to the rec�fica�on of material defects. - Page 8 So don’t send your new device back straight away; STOP make use of the telephone advice service provided by the stabo service team. Our technicians are very familiar with the devices and will be happy to assist you with prac�cal �ps and competent advice.
