Introduction

The S1-200's highly flexible four channel design features the unique patented DPR (Dynamic Power Reduction) and the patented ISF (Infinite Shape Feature) controls and although it has a comprehensive control set, it is still simple and intuitive to use. Please read through this handbook carefully to ensure you get the maximum benefit from your new Blackstar product.
If you like what you hear and want to find out more about the Blackstar range of products please visit our website at www.blackstaramps.com.

Features

The S1-200 sees the distillation of decades of guitar amplifier design experience into the ultimate 200W valve head. Every control has been honed for maximum sonic benefit through hundreds of hours of listening.

The S1-200 Clean Channel sets the precedent for no-compromise design, by featuring the unique Bright / Warm switch. This modestly named control actually reconfigures the preamplifier voicing and power amplifier damping to reproduce either ringing Class A performance in the Bright mode, or crunchy Class AB tones in the Warm setting.

Careful attention was paid to the levels of overdrive available when designing the S1-200 Crunch Channel. We thought it important to cover the widest range of crunch gain levels from just on the edge clean break-up, to crushing modern rhythm tones. To this end the Crunch / Super Crunch switch alters both gain levels and tonal shaping for maximum crunch flexibility.

The overdrive channels are characterised by a tone which is high in gain, but lacks any of the detached top-end often found in many similar designs. This is a result of unique preamplifier and power amplifier shaping techniques, which also benefit the player in the way the overdrives clean up beautifully as the guitar volume is reduced. Even at the most extreme settings, the overdrive channels remain natural sounding.

The patented ISF control is unique to Blackstar Amplification and represents a major step forward in tone shaping flexibility. The ISF control shifts the response of the three control tone stack between, at one end a US response, and at the other a UK response. Importantly, an infinite number of alternative tone choices lies in between that would be otherwise unavailable.

Completing the tonal feature set is another unique patented Blackstar innovation — the patented DPR (Dynamic Power Reduction) system. DPR reduces the power of the output stage from full power (200W) down to 10% (20W) and any power output in between. This means that the full tonal depth of the KT88 power amplifier can be enjoyed at any volume, making the S1-200 ideal for recording, smaller gigs and even home practice use. Working in conjunction with the power amplifier voltages, this method of power reduction suffers none of the loss in tone of other power reduction systems.

The tonal flexibility of the S1-200 is augmented by full MIDl implementation of the main channel switching functions. Used in conjunction with outboard gear such as multi-effects units, MIDI allows a whole new level of creative performance to be explored.

Front Panel

1. Input
   Plug your guitar in here. Always use a good quality screened guitar lead.

Clean Channel

2. Clean Indicator
   When the green LED is on the Clean Channel is selected.
3. Clean Select
   Press this switch to select the Clean Channel.
4. Clean Gain
   The Clean Gain control adjusts the amount of the Clean Channel's overdrive or distortion. Low settings, counter clockwise, will deliver a clean sound. As the Clean Gain control is increased clockwise the sound will begin to break up, delivering a subtle overdrive.
5. Bright / Warm Switch
   The Bright / Warm Switch reconfigures both preamplifier and power amplifier circuits to deliver Class A or Class AB style tones.

The table below describes the operation of the two modes:

6. Clean Volume
   This controls the volume of the Clean Channel. Turning it clockwise increases the volume.

Crunch Channel

7. Crunch Indicator
   When the yellow LED is on the Crunch Channel is selected.
8. Crunch Select
   Press this switch to select the Crunch Channel
9. Crunch Gain
   The Crunch Gain control adjusts the amount of the Crunch Channel's overdrive or distortion. Low settings, counter clockwise, will deliver a clean sound on the edge of break-up. As the Crunch Gain control is increased clockwise the sound will become more overdriven, moving through beautiful crunch tones.
10. Super Crunch Switch
    The Super Crunch switch allows the selection between a lower gain crunch with a looser bass response (Super Crunch-out) and a higher gain crunch setting (Super Crunch-in), which has a tighter bottom end for modern rhythm playing.
11. Crunch Volume
    This controls the volume of the Crunch Channel. Turning it clockwise increases the volume.

Clean and Crunch Channel EQ

12. Bass
    The Bass control adjusts the amount of low-end frequencies in your tone. This amp has an advanced tone shaping circuit which allows the tone to be tight and cutting, counter clockwise, to warm and thumping, clockwise.
13. Middle
    The Middle control adjusts the amount of middle frequencies in your tone. The middle frequencies are particularly important in setting the amount of 'body' your tone has. With the Middle control set to its minimum position (fully counter clockwise) the sound will be aggressive and scooped, a tone ideal for aggressive rhythm playing.
    As the Middle control is increased (clockwise) the amount of 'body' is increased, which is more suitable for sustained lead guitar tones.
14. Treble
    The Treble control allows exact adjustment of the treble frequencies within the sound. At low settings (counter clockwise) the sound will be warm and darker in character. As the Treble control is increased (clockwise) the sound will become brighter. At the maximum settings the sound will be aggressive and cutting
15. ISF (Infinite Shape Feature)
    The patented ISF control works in conjunction with the Bass, Middle and Treble controls. It allows you to choose the exact tonal signature you prefer. Fully counter clockwise has a more American characteristic with a tight bottom-end and more aggressive middle, and fully clockwise has a British characteristic which is more 'woody' and less aggressive.
    Unlike conventional 'contour' controls and parametric equalisation systems, the Bass, Middle and Treble controls remain interactive with each other just like in a traditional guitar amplifier tone stack. This leads to a very familiar, musical response.


Overdrive 1 Channel

16. Overdrive 1 Channel Indicator
    When the orange LED is on, the Overdrive 1 Channel is selected.
17. Overdrive 1 Select
    Press this switch to select the Overdrive 1 Channel.
18. Overdrive 1 Gain
    The Overdrive 1 Gain control adjusts the amount of the Overdrive 1 Channel's overdrive or distortion. Low settings, counter clockwise, will deliver a clean sound on the edge of break-up. As the Gain control is increased clockwise the sound will become more overdriven, moving through crunch tones until, at its maximum position, a full distorted tone is arrived at.
19. Overdrive 1 Volume
    This controls the volume of the Overdrive 1 Channel. Turning it clockwise increases the volume.

Overdrive 2 Channel

20. Overdrive 2 Indicator
    When the red LED is on, the Overdrive 2 Channel is selected.
21. Overdrive 2 Select
    Press this switch to select the Overdrive 2 Channel.
22. Overdrive 2 Gain
    The Overdrive 2 Gain control adjusts the amount of the Overdrive 2 Channel's overdrive or distortion. Low settings, counter clockwise, will deliver a clean sound on the edge of break-up. As the Gain control is increased clockwise the sound will become more overdriven moving through crunch tones until, at its maximum position, there is a full distorted lead tone.
23. Overdrive 2 Volume
    This controls the volume of the Overdrive 2 Channel. Turning it clockwise increases the volume.

Overdrive 1 and Overdrive 2 Channel EQ

24. Bass
    The Bass control adjusts the amount of low-end frequencies in your tone. This amp has an advanced tone shaping circuit which allows the tone to be tight and cutting, counter clockwise, to warm and thumping, clockwise.
25. Middle
    The Middle control adjusts the amount of middle frequencies in your tone. The middle frequencies are particularly important in setting the amount of 'body' your tone has.
    With the Middle control set to its minimum position (fully counter clockwise) the sound will be aggressive and scooped, a tone ideal for aggressive rhythm playing. As the Middle control is increased (clockwise) the amount of 'body' is increased, which is more suitable for sustained lead guitar tones.
26. Treble
    The Treble control allows exact adjustment of the treble frequencies within the sound. At low settings (counter clockwise) the sound will be warm and darker in character.
    As the Treble control is increased (clockwise) the sound will become brighter. At the maximum settings the sound will be aggressive and cutting.
27. ISF (Infinite Shape Feature)
    The patented ISF control works in conjunction with the Bass, Middle and Treble controls. It allows you to choose the exact tonal signature you prefer. Fully counter clockwise has a more American characteristic with a tight bottom-end and more aggressive middle, and fully clockwise has a British characteristic which is more 'woody' and less aggressive.
    Unlike conventional 'contour' controls and parametric equalisation systems, the Bass, Middle and Treble controls remain interactive with each other just like in a traditional guitar amplifier tone stack. This leads to a very familiar, musical response.


Master

28. Resonance
    The Resonance control sets the overall bass response of the S1-200. At lower settings the cleans will be tight and funky and overdrives will be focussed in their bass response. At increased settings the clean sounds will be become full and warm, whilst the crunch and overdrive tones will be more bass heavy and resonant.
29. Presence
    The Presence control sets the overall treble response of the S1-200. Percussive high-end can be accentuated on clean sounds and the amount of aggressive treble controlled with crunch and overdrive settings.
30. Volume
    This controls the overall volume of your amplifier. Turning it clockwise increases the volume.
31. DPR (Dynamic Power Reduction)
    The patented DPR control allows the output power of the S1-200 to be reduced anywhere from 200W (100%) down to 20W (10%) of the rated power.
    DPR works by controlling the power supply voltages to the KT88 output valves and also the level of drive signal into the power amplifier stage. Importantly, there are no components placed in between the output valves, the output transformer and the loudspeaker —a relationship which is essential in the delivery of valve tone.
    In addition to reducing the output power of the S1-200, the DPR system actually controls the amount of power amplifier compression too. Power amplifier compression is a key ingredient in the characteristics of low powered valve amplifier tone and gives a very playable 'feel' to the S1-200 at reduced power settings.
    We would recommend experimenting with the channel Gain and Volume, Master Volume and DPR Control to achieve various combinations of preamplifier and power amplifier distortion / compression.
    Note: Generally speaking the more DPR is applied (i.e. power is reduced) the more dynamic compression and power amp clipping will be experienced at any given volume.


Clean DPR Operation
The DPR control is extremely powerful in fine-tuning the exact dynamic compression characteristics of the power amplifier.

Crunch DPR Operation
The DPR control allows you to pin-point exactly how much valve overdrive you want to come from the preamplifier section and how much is coming from the KT88s in the power amplifier section.

Overdrive DPR Operation
The DPR control allows you to add power amplifier compression to your high gain lead and rhythm tones. This is superb for encouraging really fluid lead playing rich in power amplifier sustain and feel.

32. Power Indicator Light
    The power indicator will light when the amplifier is switched on.
33. Standby
    This switch enables the output stage. Always turn this switch on at least 30 seconds after the Power switch (34). During short breaks in playing use just this switch to turn 'off' and 'on' the amplifier's output.
34. Power
    This switch is used to turn the amplifier on and off. You should always turn this switch on before turning on the Standby switch (33).

MIDI Channel Switching

The Series One offers the ability to control channel selection via MIDl Program Change messages and interfacing with most MIDl controllers is a straight forward process. The Series One can be placed in a MIDl chain allowing you to simultaneously select a channel on the amplifier and change the patch on a MIDI effects processor connected to the effects loop. There are 128 available Program Changes, giving you the possibility to access a vast number of tonal combinations.

To set-up MIDl channel switching, simply connect the MIDl controller's MIDl Out socket to the MIDl In socket on the rear of the amplifier. The controller should be set to transmit Program Change messages (this is usually the case). From new, a Series One amplifier is set to OMNI mode and responds to Program Change messages on all MIDl channels. Changing 'patches' on the controller will change the selected channel on the amp. The default settings for each Program Change number are shown in the table below:

Program Change Assignment

To change the default assignments and set the amp up to respond to a different set of Program Changes:

1. The amp must be powered on with either the Standby switch set to on, a jack in the Input socket, or both.
2. Send the appropriate Program Change message to the amp.
3. Press and hold in the appropriate front panel Channel Select switch for 2 seconds.

The corresponding channel will be selected and its LED will flash three times in quick succession to indicate it has been assigned to the last received Program Change. The amplifier will now remember the selection. Repeat the operation until all your Program Changes have the desired amp channel assigned to them.

MIDI Receive Channel Selection

As mentioned previously, the default mode is set to OMNI and the amplifier will respond to MIDl Program Changes on all MIDl channels. You may wish to set the amplifier to respond to Program Changes on just a single MIDl channel. The Series One can be set to respond in this way for any of the first seven MIDI channels as follows:

1. The unit must be in standby (Power (34) on and Standby (33) off), and no lead connected to the Input jack.
2. Simultaneously press and hold the Clean (3) and OD1 (17) Select switches.
3. After 2 seconds the LED for OD2 (20) will begin to flash continuously (2 flashes per second) to indicate that the unit is in MIDl Receive Channel Program Mode.
4. Release the Clean (3) and OD1 (17) Select switches and select the required MIDl channel by using the Channel Select switches as shown in the table below:

The corresponding Channel Select LEDs will illuminate to show the selection and each press of the Channel Select switches will toggle the state of its associated LED.

5. To store the desired selection press the OD2 (21) Select switch. The OD2 (20) Select LED will flash quickly four times when the operation is complete. The unit will then revert to normal operation, and will respond only to Program Changes on the newly selected MIDl Channel.

MIDl Dump Out

You may wish to back up the MIDl channel select settings so you can transfer them to another amplifier, for example. To do this you will need a MIDl Sysex librarian, which is usually a piece of software running on a PC or MAC with a suitable MIDl interface.

1. The unit must be in standby (Power (34) on and Standby (33) off), with no lead connected to the Input jack and the MIDI Thru on the rear of the amplifier connected to the MIDl In of the recording device.
2. Simultaneously press and hold the Crunch (8) and OD2 (21) Select switches. After 2 seconds the LED for OD1 (16) will flash continuously to indicate that the unit is in MIDI Dump Mode.
3. Prepare the receiving equipment for the transfer. For example, if using a MIDI Sysex librarian this must be put into file receive mode.
4. Start the file transfer by pressing and quickly releasing the OD1 (17) Select switch. During the file transfer the OD1 (16) Select LED will flash quickly. When the flashing stops the transfer operation is complete and the amplifier will revert to normal operation. The file should be saved as a MIDI System Exclusive file.

MIDl Dump In

To load in previously saved Program Change assignments:

1. Connect the MIDI Out of the MIDI recording device to the MIDI In on the rear of the amplifier and use the MIDl Sysex librarian to send the previously stored MIDl System Exclusive file.

The amplifier overwrites the current Program Change assignments with the new ones. If the operation completes successfully all four channel LEDs flash quickly four times. If the dump is unsuccessful or incomplete the four LEDs will flash slowly in an alternating pattern and then the unit will revert to normal operation.
Note: During reception of the System Exclusive file the amplifier will temporarily cease to pass data to the MIDl Thru socket.

Restoring Factory Settings

To return the amplifier to its factory default state:

1. With the amplifier Power off, press and hold in the Crunch (8) and OD2 (21) Select switches.
2. While holding in the switches turn on the amplifier. After 2 seconds all channel select LEDs flash once to confirm the factory defaults have been restored.

Rear Panel

1. Mains Input
   The supplied detachable mains lead is connected here. The lead should only be connected to a power outlet that is compatible with the voltage, power and frequency requirements stated on the rear panel. If in doubt get advice from a qualified technician.
2. Mains Fuse
   The value of the Mains Fuse is specified on the rear panel. Never use a fuse of the incorrect value or attempt to bypass it.
3. H.T. Fuse
   The value of the H.T. Fuse is specified on the rear panel. Never use a fuse of the incorrect value or attempt to bypass it.
4. Output Valves Fuse
   The value of the Output Valves Fuse is specified on the rear panel. Never use a fuse of the incorrect value or attempt to bypass it.
5. Footswitch
   The supplied footswitch is connected here. The footswitch enables you to switch between the Clean, Crunch, Overdrive 1 and Overdrive 2 channels.
6. MIDl Thru
   Any MIDl data received at the MIDl In socket is passed out of the MIDl Thru socket so that other MIDl devices can be placed in a chain. The MIDl Thru socket also serves as a way of dumping Channel Select/Program Change data to a suitable MIDl storage device. Refer to the MIDl Channel Switching section for more details. Always use a good quality MIDI lead.
7. MIDl In
   If channel switching using MIDI is required, connect the MIDI device here. Refer to the MIDl Channel Switching section for more details. Always use a good quality MIDl lead.
8. Impedance Selector
   This control matches the amplifier's impedance to that of the connected speakers. Always ensure that the selected impedance matches that of the speaker cabinets connected. See table below.

A speaker cabinet of less than 4 Ohms, or 2 x 4 Ohm cabinets, should not be used together with this amplifier.

The amplifier must always be completely powered down before adjusting the setting of the Impedance Selector. Failure to do this, or to correctly match the impedance of the amplifier and speakers, will damage the amplifier.

9. Speaker Outputs
   There are two parallel speaker outputs for connecting external speaker cabinets. When connecting speakers always ensure that the Impedance Selector (8) is set correctly.
10. Speaker Emulated Output
    This output emulates the tonal characteristics of a guitar speaker cabinet and provides a natural valve overdrive tone for connection to a recording device or mixing desk. Always use a good quality screened lead. There is both a jack and a balanced XLR output.
    NOTE: To 'silently' record, turn the amp to standby mode. You may also record from this output while in standby mode without a loudspeaker connected, but ensure that no loudspeaker leads are connected to either of the loudspeaker output jack sockets of the amplifier, as this will defeat the load protection circuit and cause damage to the amplifier.
11. Effects Loop Level
    The Effects Loop Level switch sets the effects loop to either +4dBV/-10dBV, which enables you to use it with either professional equipment (+4dBV setting), or with guitar level effects such as effects pedals (-10dBV setting).
12. Effects Loop Return
    Connect the (mono) output of an external effects unit here.
13. Effects Loop Send
    Connect the (mono) input of an external effects unit here.

Technical Specification

Power (RMS): 200 Watts
Valves: 4 x KT88, 4 x ECC83, 1 x ECC82
Weight (kg): 27.2
Dimensions (mm): 705 x 285 x 278.5
Footswitch: FS-3 supplied

Manufacturer: Blackstar Amplification
Model: Series One
