- Page 1 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS IMPORTANT INFORMATION FOR THE INSTALLER AND THE OWNER...
-
Page 2: Table Of Contents
LIBRA FREESTANDING INSTALLATION INSTRUCTIONS TABLE OF CONTENT IMPORTANT SAFETY INSTRUCTIONS ........................4 PARTS & TOOLS ..............................6 SITE PREPARATION .............................8 INSTALLATION WITH ACCESS UNDER THE FLOOR ....................10 PLUMBING ............................10 INSTALLATION ............................12 INSTALLATION WITHOUT ACCESS UNDER THE FLOOR ..................13 PLUMBING ............................13 INSTALLATION ............................15 REMOTE MOUNTING OF TURBINE ........................15... - Page 3 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS LIBRA FREESTANDING www.bainultra.com Some products, specifications, and services mentioned in this manual are described in pending patent applications or are protected by patents.
-
Page 4: Important Safety Instructions
LIBRA FREESTANDING IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS PERTAINING TO RISKS OF FIRE, ELECTROCUTION OR PERSONAL INJURY READ AND FOLLOW ALL INSTRUCTIONS • SAVE THESE INSTRUCTIONS THIS DOCUMENT SUPERCEDES THE INSTALLATION INSTRUCTION IN THE OWNER’S MANUAL. WARNING • Risk of hyperthermia; people using medication and/or having an adverse medical history should consult a physician before using a Hydro-thermo massage ®... - Page 5 • Once plumbing is fully installed and before beginning any other work, fill the ThermoMasseur with water to ® overflow level and wait 30 minutes. Check all plumbing hook-ups and bath for leaks. BainUltra is not responsible ® for any water damage caused by improper installation (see Warranty section in the Owner’ s Manual).
-
Page 6: Parts & Tools
LIBRA FREESTANDING INSTALLATION INSTRUCTIONS PARTS & TOOLS REQUIRED PVC DRAIN STANDARD PARTS - PLUMBING DESCRIPTION Plated drain clicker Strainer Rubber seal Tee PVC Drain shoe OPTIONAL PARTS - PLUMBING PVC & BRASS DRAIN DESCRIPTION Tee brass drain shoe 8 in. brass tailpiece... - Page 7 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS PARTS & TOOLS REQUIRED STANDARD PARTS - FLOOR ANCHOR & ACCESSORIES DESCRIPTION Threaded anchor #10 X 1-1/2” Countersunk head screw STANDARD PARTS – THERMOMASSEUR ® DESCRIPTION Turbine MiaPlus Control ® 15’ control cable PARTS & TOOLS...
-
Page 8: Site Preparation
ThermoMasseur ® which includes information such as necessary dimensions of site before installation. If you do not already have the technical specifications, download it from the BainUltra ® Website at: bainultra.com or call us at: 1 800 463-2187. 1 800 463.2187 Monday to Thursday from 8 a.m. - Page 9 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS SITE PREPARATION TURBINE - REMOTE INSTALLATION 1. A 1 ½ inch ID pipe has to run from the tub, back to the turbine location. This pipe can be PVC Tigerflex (spa hose) or rigid PVC or ABS 2.
-
Page 10: Installation With Access Under The Floor
LIBRA NOTE : Please refer to the Cutting Template provided with your Libra bath. However, if it is missing, please contact us at 1-800-463-2187 to order it. Available on our website at BainUltra.com. PLUMBING HELPFUL TIP: • Carefully place the tub on its side, on a blanket or a corrugated cardboard. - Page 11 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS INSTALLATION WITH ACCESS UNDER THE FLOOR PVC DRAIN PVC Connector PVC Drain PVC & BRASS DRAIN Overflow pipe NOTE: If necessary, cut the overflow pipe to the desired length, and glue it to the PVC connector and to the drain.
- Page 12 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS INSTALLATION WITH ACCESS UNDER THE FLOOR BATH INSTALLATION HELPFUL TIPS: • Carefully place the tub on its side, on a blanket or a corrugated cardboard. • To easily manipulate the bathtub in a safe way during installation, we recommend using moving straps.
-
Page 13: Installation
NOTE : Please refer to the Cutting Template provided with your LIBRA bath. However, if it is missing, please contact us at 1-800-463-2187 to order it. Available on our website at BainUltra.com. PLUMBING - ISLAND TUB DRAIN (ITD) INSTALLATION HELPFUL TIP: •... -
Page 14: Plumbing
LIBRA FREESTANDING INSTALLATION INSTRUCTIONS INSTALLATION WITHOUT ACCESS UNDER THE FLOOR PLUMBING NOTE • Refer to supplied instructions for Island Tub Drain (ITD) installation. • The floor finishing material can go over the red center piece of the ITD. The red center piece connects to the brass tailpiece. -
Page 15: Installation
LIBRA FREESTANDING INSTALLATION INSTRUCTIONS INSTALLATION WITHOUT ACCESS UNDER THE FLOOR BATH INSTALLATION HELPFUL TIPS: Measure & Align • Carefully place the tub on Anchor Holes (2x) its side, on a blanket or a corrugated cardboard. • To easily manipulate the bathtub in a safe way... - Page 16 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS INSTALLATION WITHOUT ACCESS UNDER THE FLOOR REMOTE ACCESS OF COMPONENTS WARNING IF THE CONNECTIONS OF THE AIR CONDUIT AND THE ELECTRICAL SUPPLY OF THE THERAPEUTIC OPTIONS MUST BE DONE AT FLOOR LEVEL, YOU MUST CUT AN OPENING ON ONE OF THE WALLS CLOSEST TO TURBINE AND CONTROLS.
-
Page 17: Remote Mounting Of Turbine
LIBRA FREESTANDING INSTALLATION INSTRUCTIONS REMOTE MOUNTING OF TURBINE TURBINE & GEYSAIR INSTALLATION (FOR THERMOMASSEUR ® GEYSAIR HOSE AND FLOW REGULATOR 1-1/2 I.D. PVC AIR INTAKE PIPE («TIGERFLEX ® » FLEXIBLE PVC) FLOW REGULATOR 1-1/2 I.D. ABS, PVC PIPE (RIGID or «TIGERFLEX») &... - Page 18 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS REMOTE MOUNTING OF TURBINE REMOTE MOUNTING OF TURBINE Bottom of door When located in an enclosed location. Floor 1” WARNING • Choose a location for the turbine with the shortest possible distance from the Thermomasseur ®...
-
Page 19: Electrical Connection (Thermomasseur)
REMOTE MOUNTING OF TURBINE - ELECTRICAL CONNECTIONS (THERMOMASSEUR ® • See page 23 for electrical diagram GEYSAIR BACK FLOW PREVENTER EXTENSION CORD (For extra extension cord length, contact BainUltra to order) GEYSAIR CONNECTION TO GFCI Outlet Junction box United States Canada WARNING • For Geysair ®... -
Page 20: Electronic Controls
LOCATION: Determine the most convenient location, on the wall close to tub. WARNING • Libra freestanding bath cannot be drilled for control installation. DRILLING OF WALL: Refer to the Cutting Template on page 24 for the location and diameter of the holes. -
Page 21: Electrical Section
• Geysair component cannot be remote mounted. Must never be unplugged. * BU-Touch is a virtual control application that activates all the options of the ThermoMasseur Air jets bath from your mobile device. Please refer to BU-TOUCH Quick Start Guide: www.bainultra.com/butouch-guide www.bainultra.com... -
Page 22: Electrical Connections For Remote Mounting Of Therapies (Baths Without Air Jets)
DOT Chromatherapy (LED) WARNING • Libra freestanding bath cannot be drilled for faucet installation. Faucets must be freestanding or wall-mounted models. 1 800 463.2187 Monday to Thursday from 8 a.m. to 6 p.m. (EST) . Friday from 8 a.m. to 5 p.m. (EST) - Page 23 LIBRA FREESTANDING INSTALLATION INSTRUCTIONS ELECTRICAL SECTION ELECTRICAL DIAGRAM – 20A THERMOMASSEUR and 15A THERAPY ® 15A CIRCUIT 20A CIRCUIT 15A CIRCUIT NEUTRAL N L LOAD NEUTRAL N L LOAD NEUTRAL N L LOAD GROUND GROUND GROUND FAULT CIRCUIT FAULT CIRCUIT...
-
Page 24: Cutting Template Of Miaplus Control
LIBRA FREESTANDING INSTALLATION INSTRUCTIONS PIÈCES ET OUTILS NÉCESSAIRES CUTTING TEMPLATE OF MIAPLUS CONTROL ® FOR WALL INSTALLATION 1 800 463.2187 Monday to Thursday from 8 a.m. to 6 p.m. (EST) . Friday from 8 a.m. to 5 p.m. (EST) Printed in Canada. Copyright © August 2021 Bains Ultra Inc. All rights reserved. 45200682...
