- Page 1 AV-P2 Output Module User Guide P/N 9310 1019 0001F Rev. 1.00 Download from Www.Somanuals.com. All Manuals Search And Download.
- Page 2 Aviom, Inc. Trademarks Aviom, A-Net, the A-Net icon, Pro16, and Pro64 are trademarks of Aviom, Inc. All other trademarks are the property of their respective owners. © 2007 Aviom, Inc. All rights reserved. Information subject to change without notice.
- Page 3 Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to the product not expressly approved by Aviom, Inc. could void the user’s FCC authority to operate the equipment. Download from Www.Somanuals.com. All Manuals Search And Download.
-
Page 4: Warranty Information
Address: serial number has been damaged, modified, or removed. If a defect is discovered, first write or call Aviom, Inc. to obtain a Return Authorization number. No service will be performed on any product returned Phone: without prior authorization. -
Page 5: Table Of Contents
Table of Contents A-Net Expansion ....23 32-Channel Examples ....24 32 Channels Send by Zero Channels Return . - Page 6 Download from Www.Somanuals.com. All Manuals Search And Download.
-
Page 7: Welcome
Welcome Thank you for purchasing the Aviom Pro16™ AV-P2 Output Module. This User Guide is designed to familiarize you with the features of your new Pro16 product and to have you up and running in no time. Features The AV-P2 Output Module is designed to output a 2-channel mono or stereo signal from a Pro16 system. -
Page 8: Front Panel Components
Front Panel Components Rear Panel Components Download from Www.Somanuals.com. All Manuals Search And Download. -
Page 9: Compatibility
Compatibility The AV-P2 Output Module can be used with the following Aviom Pro16 products: • AN-16/i Input Module • AN-16/i-M Mic Input Module • AV-M8 Mic Input Module • Aviom16/o-Y1 A-Net card for use with Yamaha® consoles • D-16c A-Net card for use with DiGiCo® consoles •... -
Page 10: Pro16 Series Systems
Personal Mixer. Many configurations are possible by using additional input modules and/or Personal Mixers and output modules. About A-Net Aviom’s A-Net® is a high-speed data transmission protocol. It is capable of sending and receiving uncompressed, high-quality audio using readily available Category 5 cables. A-Net technology is a proprietary system developed by Aviom. -
Page 11: Cables Used With A-Net Devices
A-Net components Cat-5e Cable Lengths Category 5e cables used with your Aviom products can be up to 500 feet (approximately 150 meters) in length. The maximum cable length specification applies to the cable connected between the Pro16 input module and the first A-Net device (AV-P2, AN-16/o Output Module, This diagram shows a Pro16 input module connected to compatible Personal Mixer, etc.), as well as for cable runs between each additional... -
Page 12: Extending Cable Lengths
Always use all the mounting screws when reversing the flanges on the AV-P2. The exterior of your Aviom products should be cleaned with a dry, soft, lint-free cloth. For tougher dirt, you can use a cloth slightly dampened Always allow adequate ventilation for devices mounted in equipment with water or with a mild detergent. -
Page 13: Panel Descriptions
This section explains the basic layout of the front and rear panels of your the settings of the Pro16 network’s input module’s Stereo Link switches. new Aviom product. The diagrams on the previous pages can be used as a quick visual guide to the location of the components of the AV-P2 : The left and right audio channels have separate output level mentioned in this section. -
Page 14: Av-P2 Rear Panel
This type of power supply can be used worldwide with a wide range of AC wall current output voltages (100-240VAC). When The A-Net In port receives digital data in Aviom’s proprietary A-Net traveling, you do not need to replace the power supply in countries format. -
Page 15: Connecting Audio
Connecting Audio The audio outputs on the AV-P2 Output Module can be connected to balanced or unbalanced devices via the Euroblock jacks. Wiring a Euroblock The Euroblock plug, showing the screws that hold the individual wires in place (left-to-right), hot (+), cold (-), and ground Euroblock connectors provide an easy, solder-free way of making audio connections between the AV-P2 and other audio components. -
Page 16: Setting Output Levels
Setting Output Levels Strip the insulating jacket of the cable back about .75 inch (18 mm) to reveal the individual hot and ground Output levels on the AV-P2 are set with the DIP switches on the front wires within. panel. Individual settings are possible for the left and right audio Remove a small amount of each individual wire’s channels. -
Page 17: Dip Switch Settings Table
-35.9 The output level table is also printed on the top of the AV-P2 case for quick reference. S-S, ARTWORK, PRO16 AV-P2 COVER BOTTOM P/N 9225 1066 1001, REV. B SCALE 1:1 Download from Www.Somanuals.com. All Manuals Search And Download. -
Page 18: A-Net Connections
A-Net Connections When creating a Pro16 A-Net system, the simplest connection method uses what is called a daisy chain. That is, each A-Net device is connected in series. The first device in the chain receives its A-Net signal from the AV-M8 Mic Input Module’s A-Net Out port. Each successive A-Net compatible device gets its A-Net connection from the A-Net Out port of the device preceding it in the daisy chain. -
Page 19: Extending A-Net Cable Runs
Aviom equipment. Both single and multi- “splits,” to a system, simply connect an A-Net Out to the A-Net In on mode fiber devices can be used. Refer to the Aviom website for a list of Pro16 output modules or Personal Mixers. The following diagram shows approved devices. -
Page 20: 32-Channel Systems
32-Channel Systems 16 Channels In Pro16 Input Aviom’s Pro16 audio networking products work in blocks of 16 channels. A-Net, up to 500 feet, Audio networks of 32 channels can be configured as: 150 meters • 32 channels send by zero channels return (32 x 0 ) AN-16/o ...to teleconferencing... -
Page 21: 32-Channel Examples
will be connected to an A-Net Out port. Audio channels 1-16 • The A-Net Out ports on the Pro16 output modules Channels 1-16 In Channels 1-16 Out should be empty when only four Pro16 Series units are Pro16 Input Pro16 Output being used to create a network. -
Page 22: 16 Channels Send By 16 Channels Return
Channels 17-32 in Channels 17-32 out Channels 1-16 AV-M8 ADAT ® EXPANSION CH 9-16 EXPANSION AV-M8 ADAT ® EXPANSION CH 9-16 Channels 1-16 in Channels 1-16 out EXPANSION Note that A-Net In is connected to A-Net Out on both pairs of modules Channels 17-32 in this 32 x 0 system. -
Page 23: Expanding A Network With An A-Net Distributor
A-Net Out port. This flexible routing scheme allows you your application. to send audio to a variety of different locations and to include Aviom’s Pro16 Monitor Mixing System for mic applications. Expanding a Network with an A-Net Distributor... -
Page 24: Specifications
2 mm, locking, center pin hot Dimensions 7.45” (189.2 mm) wide x 7” (177.8 mm) deep; 1U high Weight 3.4 lbs (1.54 kilo) All Aviom products are designed and manufactured in the USA. Download from Www.Somanuals.com. All Manuals Search And Download. -
Page 25: Block Diagram
Block Diagram Download from Www.Somanuals.com. All Manuals Search And Download. - Page 26 Aviom Warranty Registration Please take a moment to fill in this warranty registration form. Return it to Aviom via mail or fax. All information will be kept confidential. Model Number Serial Number Model Number Serial Number Model Number Serial Number...
- Page 27 Index Monitor Mixing System 28 daisy-chain 19 DC Power Connector 12 mono 10 mounting flanges 9 DiGiCo 4, 24 Digital Split 21 Mute Switch 2, 10 Dimensions 31 Symbols ASI A-Net System Interface 4 DIP switches 17 Audio Networks 21 output level 10 +48 Volt 2 Network 5...
- Page 28 signal repeater 20 Specifications 30 Split 21 stereo 10 Stereo Link 11 Stereo Pair LED 2, 11 stranded vs. solid Cat-5 6 System Bridge 4, 7, 23 Unbalanced Source wiring Euroblocks 15 Unshielded Twisted Pair 6 UPS 8 UTP 6 UTP cable 25 Wiring a Euroblock 14 Y1 21, 22...
- Page 29 Free Manuals Download Website h p://myh66.com h p://usermanuals.us h p://www.somanuals.com h p://www.4manuals.cc h p://www.manual-lib.com h p://www.404manual.com h p://www.luxmanual.com h p://aubethermostatmanual.com Golf course search by state h p://golfingnear.com Email search by domain h p://emailbydomain.com Auto manuals search h p://auto.somanuals.com TV manuals search h p://tv.somanuals.com...
