- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 108241(B1&B2) Dining Table COASTERFURNITURE.COM PAGE 1 OF 6 REVISION 0 : 01/05/2024...
-
Page 2: Assembly Tips
108241 (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. -
Page 3: Hardware Identification
108241 (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. - Page 4 108241 (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 ATTENTION! TO REMOVE PART #E FROM PART #A, RETAIN ALL BOLTS, LOCK WASHERS AND FLAT WASHERS IN THIS STEP AND USE ALL HARDWARE IN STEP 5. BOLT (M6 x 50mm) LOCK WASHER (M6) FLAT WASHER (M6)
- Page 5 108241 (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 4 STEP 5 ATTENTION! PLEASE USE ALL BOLTS, LOCK WASHERS AND FLATS WASHERS IN STEP 2. LOCK WASHER (M6) FLAT WASHER (M6) PAGE 5 OF 6 COASTERFURNITURE.COM...
- Page 6 108241 (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 6 STEP 7 STEP 8 COMPLETE PAGE 6 OF 6 COASTERFURNITURE.COM...
- Page 7 108241 (B1&B2) ITEM: 17.75" 47.25" 47.25" 40.00" 30.00" 27.00" 24.50" 20.00" 1.00" 20.00" 63.25" 29.50" 72.50" Note: Dimension tolerance ±5% COASTERFURNITURE.COM...
