SP002
Hatch Top
Playhouse
Instructions for assembly, maintenance and safe use.
WARNING!
-THIS PRODUCT IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS. CONTAINS SMALL PARTS (CHOKING HAZARDS)
-EQUIPMENT CAN BECOME SLIPPY WHEN WET/ICY/DIRTY, EXTRA CARE MUST BE TAKEN IF USED IN THESE CONDITIONS
-ONLY FOR DOMESTIC USE. FOR OUTDOOR USE
-PRODUCT MUST BE ASSEMBLED BY AN ADULT(S) BEFORE USE
-ADULT SUPERVISION IS REQUIRED
-CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED
-REMOVE ALL PACKAGING BEFORE USE
-RETAIN MANUAL FOR FUTURE REFERENCE
-MAX USER WEIGHT: 50KG
REBO
Rebo International GmbH, Bahrenfelder Chaussee 49, 22761 Hamburg, Germany
www.outdoortoys.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the polar play SP002 and is the answer not in the manual?

Questions and answers

Related Manuals for rebo polar play SP002

Summary of Contents for rebo polar play SP002

  • Page 1 -PRODUCT MUST BE ASSEMBLED BY AN ADULT(S) BEFORE USE -ADULT SUPERVISION IS REQUIRED -CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED -REMOVE ALL PACKAGING BEFORE USE -RETAIN MANUAL FOR FUTURE REFERENCE -MAX USER WEIGHT: 50KG REBO Rebo International GmbH, Bahrenfelder Chaussee 49, 22761 Hamburg, Germany www.outdoortoys.com...
  • Page 2 ADVISORY SECTION TO ENSURE THE SAFETY OF YOURSELF, THE INSTALLER AND CHILDREN, IT IS IMPORTANT THAT THE INSTRUCTION MANUAL IS READ FULLY AND UNDERSTOOD BEFORE COMMENCING INSTALLATION AND PLAY! SAFETY CONSIDERATIONS • This product contains small parts, and is therefore not suitable for children under 36 months (3 years) •...
  • Page 3 WARNHINWEIS ZUR GEWÄHRLEISTUNG IHRER EIGENEN SICHERHEIT UND DER SICHERHEIT DES MONTEURS UND IHRER KINDER IST ES WICHTIG, VOR MONTAGE- UND SPIELBEGINN DIE BEDIENUNGSANLEITUNG VOLLSTÄNDIG DURCHZULESEN UND ZU VERSTEHEN! SICHERHEITSHINWEISE • Dieses Produkt enthält Kleinteile und ist deshalb nicht für Kinder unter 36 Monaten (3 Jahren) geeignet. •...
  • Page 4 ADVIESGEDEELTE OM DE VEILIGHEID VAN UZELF, DE INSTALLATEUR EN KINDEREN TE GARANDEREN, IS HET BELANGRIJK DAT DE HANDLEIDING VOLLEDIG WORDT GELEZEN EN BEGREPEN ALVORENS TE BEGINNEN MET INSTALLEREN EN SPELEN! VEILIGHEIDSPUNTEN • Dit product bevat kleine onderdelen en is daarom niet geschikt voor kinderen jonger dan 36 maanden (3 jaar) •...
  • Page 5 RECOMMANDATION POUR ASSURER LA SECURITE DE VOS ENFANTS, DE LA PERSONNE CHARGEE DE L’INSTALLATION ET DE VOUS-MÊME, LE MANUEL D’EMPLOI DOIT ÊTRE LU INTEGRALEMENT ET COMPRIS AVANT DE COMMENCER L’INSTALLATION ET L’UTILISATION! SECURITE • Ce produit contient des petites pièces et n’est donc pas adapté aux enfants de moins de 36 mois (3 ans) •...
  • Page 6 SEZIONE AVVISI PER GARANTIRE LA PROPRIA SICUREZZA, LA SICUREZZA DELL’INSTALLATORE E DEI BAMBINI, È IMPORTANTE CHE IL MANUALE DI ISTRUZIONI SIA LETTO E COMPRESO INTERAMENTE PRIMA DI INIZIARE IL MONTAGGIO E L’USO DEL PRODOTTO! CONSIDERAZIONI SULLA SICUREZZA • Il presente prodotto contiene delle piccole parti e quindi non è adatto per bambini di età inferiore ai 36 mesi (3 anni) •...
  • Page 7 ADVERTENCIAS PARA GARANTIZAR SU SEGURIDAD, LA DEL INSTALADOR Y LA DE LOS NIÑOS, ES IMPORTANTE LEER EL MANUAL DE INSTRUCCIONES CON PRECAUCIÓN Y ENTENDERLO COMPLETAMENTE ANTES DE EMPEZAR CON LA INSTALACIÓN Y EL JUEGO. CONSIDERACIONES DE SEGURIDAD • Este producto contiene piezas pequeñas, por lo que no es apto para niños menores de 36 meses (3 años). •...
  • Page 8 Dimensions: 1016 1822 1104 1731 1865 1825 4148 2.5m The safe play area refers to the zone extending 2m around the product on all sides and 2.5m above the product. SP002 : Hatch Top Playhouse...
  • Page 9 Wood Profiles: 1/4 WD09-0112 (32x32) x 112mm x2 WD09-0436 (32x32) x 436mm x2 WD09-0568 (32x32) x 568mm x2 WD09-0660 (32x32) x 660mm x3 WD09-0844 (32x32) x 844mm x4 WD09-0862 (32x32) x 862mm x5 WD09-0928 (32x32) x 928mm x8 WD09-0934 (32x32) x 934mm x2 WD09-1141 (32x32) x 1141mm x2 WD09-1280 (32x32) x 1280mm x2 WD09-1736 (32x32) x 1736mm x2...
  • Page 10 Wood Profiles: 2/4 WD0028 (32x32) x 1736mm x1 WD1551 (32x32) x 981mm x2 WD1554 (32x32) x 1184mm x2 WD1555 (32x32) x 778mm x1 WD1553 (32x32) x 1130mm x1 WD1552 (32x32) x 1424mm x1 WD1524 (32x32) x 455mm x2 WD1522 (32x32) x 756mm x2 WD1562 (32x32) x 778mm x1 WD1523 (32x32) x 809mm x2 WD1570 (32x32) x 999mm x1...
  • Page 11 Wood Profiles: 3/4 WD10-0632 (120x11) x 632mm x5 WD10-0700 (120x11) x 700mm x7 WD10-0994 (120x11) x 994mm x9 WD10-1010 (120x11) x 1010mm x9 WD10-1192 (120x11) x 1192mm x2 WD1558 (105x11) x 700mm x1 WD1556 (108x11) x 1010mm x1 WD1557 (94x11) x 1010mm x1 WD1548 (120x11) x 794mm x1 WD1547 (120x11) x 888mm x1 WD1546 (120x11) x 982mm x1...
  • Page 12 Wood Profiles: 4/4 WD1538 (120x11) x 1263mm x1 WD1549 (120x11) x 1301mm x1 WD1560 (120x11) x 1301mm x1 WD1539 (120x11) x 1328mm x1 WD1540 (120x11) x 1393mm x1 WD1541 (120x11) x 1457mm x1 WD1542 (120x11) x 1522mm x1 WD1543 (120x11) x 1587mm x1 WD1544 (120x11) x 1651mm x1 WD1545 (120x11) x 1096mm x1 WD0027 (120x11) x 632mm x2...

  • Page 13: Table Of Contents

    SP002 Contents... 16mm Wood Screw x24 35mm Wood Screw x362 Canvas x1 C1 SP020 x1 C2 SP020 x1 55mm Wood Screw x68 80mm Wood Screw x52 19mm Flanged Screw x15 Handle x2 Butt Hinge x2 PL0001 x2 P1 PL0015 (1126x385) x1 P2 PL0016 (464x1252) x1 P3 PL0014 (510x1252) x1 P4 PL0019 (394x592) x1...
  • Page 14 IMPORTANT! PRE-DRILL FIX WITH SCREW Fixing Procedure Section View ALL MEASUREMENTS ARE IN MILLIMETRES (mm) UNLESS STATED OTHERWISE 5 Hrs Build Time SP002 : Hatch Top Playhouse...
  • Page 15 Shiplap Fitting Instructions SP002 : Hatch Top Playhouse...
  • Page 16 PANEL SEALING RECOMMENDATION SP002 : Hatch Top Playhouse...
  • Page 17 80mm Wood Screw x4 (x2) (x2) 80mm Wood Screw x2 SP002 : Hatch Top Playhouse...

  • Page 18: 35Mm Wood Screw X362

    35mm Wood Screw x52 1016 (x9) 80mm Wood Screw x4 (x2) (x2) SP002 : Hatch Top Playhouse...

  • Page 19: 55Mm Wood Screw X68

    55mm Wood Screw x4 (x2) (x2) 55mm Wood Screw x4 SP002 : Hatch Top Playhouse...

  • Page 20: 19Mm Flanged Screw X15

    35mm Wood Screw x70 (x7) (x5) (x2) WD0027 WD0027 1016 19mm Flanged Screw x12 Canvas x1 *Canvas may be supplied pre-cut SP002 : Hatch Top Playhouse...
  • Page 21 80mm Wood Screw x5 WD1552 WD1552 WD1555 WD1555 WD1551 WD1551 WD1554 WD1554 55mm Wood Screw x2 80mm Wood Screw x6 55mm 55mm WD1553 80mm 80mm 80mm (x2) SP002 : Hatch Top Playhouse...
  • Page 22 35mm Wood Screw x105 WD1545 WD1550 WD1544 WD1546 WD1543 WD1547 WD1542 WD1548 WD1541 WD1549 WD1540 WD1539 WD1538 WD1537 WD1536 WD1535 1800 19mm Flanged Screw x3 Canvas C2 x1 SP002 : Hatch Top Playhouse...
  • Page 23 80mm Wood Screw x3 WD1561 WD1562 WD1551 WD1554 80mm Wood Screw x2 Offset WD1563 WD1565 (x2) SP002 : Hatch Top Playhouse...
  • Page 24 WD1570 WD1569 55mm Wood Screw x2 Offset 80mm Wood Screw x2 80mm Wood Screw x6 WD0028 SP002 : Hatch Top Playhouse...
  • Page 25 35mm Wood Screw x12 WD1560 WD1559 80mm Wood Screw x6 (x3) (x2) SP002 : Hatch Top Playhouse...
  • Page 26 35mm Wood Screw x41 (x7) 80mm Wood Screw x4 (x2) (x2) SP002 : Hatch Top Playhouse...
  • Page 27 55mm Wood Screw x10 (x2) (x4) (x2) 55mm 80mm 80mm 55mm Wood Screw x2 80mm Wood Screw x4 SP002 : Hatch Top Playhouse...
  • Page 28 55mm Wood Screw x4 WD1525 (x2) WD1526 (x2) Offset 55mm Wood Screw x6 Offset WD1522 WD1524 WD1523 SP002 : Hatch Top Playhouse...
  • Page 29 55mm Wood Screw x4 Offset 35mm Wood Screw x28 (x7) SP002 : Hatch Top Playhouse...
  • Page 30 55mm Wood Screw x6 Offset 35mm Wood Screw x54 WD1557 WD1558 (x2) (x18) WD1556 SP002 : Hatch Top Playhouse...
  • Page 31 OPTIONAL CAUTION! 55mm Wood Screw x3 SP002 : Hatch Top Playhouse...
  • Page 32 55mm Wood Screw x3 55mm Wood Screw x6 SP002 : Hatch Top Playhouse...
  • Page 33 55mm Wood Screw x6 SP002 : Hatch Top Playhouse...
  • Page 34 55mm Wood Screw x6 SP002 : Hatch Top Playhouse...

  • Page 35: Handle X2

    80mm Wood Screw x4 WD1481 (x2) WD1482 (x2) Butt Hinge x2 Handle x2 16mm Wood Screw x12 SP002 : Hatch Top Playhouse...

  • Page 36: Pl0001 X2

    16mm Wood Screw x8 PL0001 x2 16mm Wood Screw x4 SP002 : Hatch Top Playhouse...
  • Page 37 SP011 SP011 SP001 SP041 SP002 : Hatch Top Playhouse...
  • Page 38 OPTIONAL SP002 : Hatch Top Playhouse...
  • Page 39 NOTES SP002 : Hatch Top Playhouse...
  • Page 40 Thank you for purchasing this product. For any assistance or queries, please contact: info@outdoortoys.co.uk or visit us on www.outdoortoys.com Vielen Dank, dass Sie sich für dieses Produkt entschieden haben. Für Hilfestellung und Rückfragen wenden Sie sich bitte an info@outdoortoys.de oder besuchen Sie uns auf www.outdoortoys.de Hartelijk dank voor de aankoop van dit product.
