TLP Pro 300M and TLS 300M Series • Setup Guide
IMPORTANT NOTE:
Go to www.extron.com
Overview
The TLP Pro 300M is a wall-mounted, 3.5 inch capacitive touchscreen with a resolution of 320x480 (HVGA) and 18-bit color depth.
It can be mounted, in landscape or portrait orientation, to drywall or a standard 1-gang US electrical box.
The TLS 300M has identical features but uses Room Agent™ software to coordinate room scheduling.
This guide provides instructions for experienced installers to mount and set up these touchpanels. For complete instructions, see
the TLP Pro 300 and TLS 300 User Guide at www.extron.com.
Setup Checklist
Get Ready
•
Download and install the latest version of the following software:
• Toolbelt — Provides device discovery, device information, and configuration of network settings, system utilities, and user
management for TouchLink Pro devices.
TLP Pro Touchpanels
• GUI Designer — For designing layouts for Extron TouchLink
• Global Configurator
and touchpanel.
• ControlScript
TLS Touchpanels
•
Room Agent — Free room booking software for configuring the panels for room scheduling.
NOTE:
All five software programs are available from www.extron.com.
•
Obtain the following network information from your network administrator:
•
DHCP status (on or off). If DHCP is off, you must also obtain:
• IP address
•
Username — This can be either admin or user.
• Password — The factory configured passwords for all accounts on this device have been set to the device serial number.
Passwords can be changed during configuration. Passwords are case sensitive.
NOTE: If the device is reset to default settings, the passwords are reset to the default password, which is extron
(for either admin or user).
•
Make a note of the touchpanel MAC address. This can be found on a label attached to the back of the touchpanel.
Mount and Cable All Devices
•
Mount the units. There are several mounting options for TouchLink Pro touchpanels (see
•
Connect the touchpanel to a Power over Ethernet injector (not provided). Extron recommends the PI 115 power injector, which
must be purchased separately.
for the complete user guide, installation instructions, and specifications.
Professional or Global Configurator Plus — For setting up and configuring the control processor
®
Deployment Utility — For programming Extron control systems.
®
• Subnet mask
Pro touchpanels and third party touch interfaces.
®
• Gateway
Mounting on page 2).
