- Page 1 RolloTron DECT belt winder pure Item no. 10302345 Installation and operating manual Translation of the german original manual UM B102-2...
-
Page 2: Table Of Contents
9.6 Deleting all settings - loading factory settings.... 30 1. This manual....................3 2. Hazard symbols ..................4 10. Removing the RolloTron DECT belt winder pure ....31 3. Safety instructions ................5 11. Removing the belt in the event of device failure ....33 3.1 Intended use ................6... -
Page 3: This Manual
This manual is part of the product. Please store it in an ● easily accessible place. When passing the RolloTron DECT belt winder pure on to a ● third party, this manual must be passed on as well. Damage resulting from non-compliance with this ●... -
Page 4: Hazard Symbols
2. Hazard symbols Danger of fatal electric shock Symbols and depictions used Depiction Description Danger area / dangerous situation Steps to be taken Levels of danger and signal words Itemisation ● DANGER! or a) List This hazard will result in serious injury or death if not avoided. Please read the respective manual. -
Page 5: Safety Instructions
If the running time limit is triggered, then the ● Incorrect use can lead to injuries RolloTron DECT belt winder pure must be left for at or damage. Observe least 12 minutes to cool down. During this period, the following safety instructions: the red indicator light flashes rapidly. -
Page 6: Intended Use
3.1 Intended use Only use the RolloTron DECT belt winder pure for opening and Operating conditions closing roller shutters with a permissible belt. A 230 V / 50 Hz power supply, together with a site-provided ● Mechanical locks of any kind are not suitable for disconnecting device (fuse, MCB), must be available at the automated operation with this device. -
Page 7: Required Expert Knowledge Of The Installer
If the drive jams in the UP (▲ ) direction (e.g. due to ice), the ▲ products. RolloTron DECT belt winder pure is switched off, see page 12. DECT base station (FRITZ!Box) End points Central control unit for DECT products. All devices in a DECT An end point is set in each direction that the roller shutter network must be logged on. -
Page 8: Included In Delivery
4. Included in delivery Connecting cable with Assembly screws Euro plug (4 x 55 mm) Traction relief Quick User Guide Reel compartment cover Check the contents of the RolloTron DECT belt winder Cover plate Disengaging bracket packaging to make sure that pure (in housing) they are complete and intact. -
Page 9: General View
5. General view Front cover Fastening holes Reel compartment Deflection roller cover Belt inlet Up button Type plate Down button Reel Indicator light Fastening hook End point button DECT button Traction relief Disengaging Favourite bracket position Cable duct Connecting terminals Cover plate Fastening holes... -
Page 10: Operating Buttons And Indicator Light
5.1 Operating buttons and indicator light Pos. Symbol Description Up/Stop button + Down/Stop button The roller shutter travels up / down or stops Indicator light / status display (red / green) End point button Set both end points Favourite position Set any position where the roller shutter stops when it is being lowered. -
Page 11: Product Description / Intended Use
6. Product description / intended use The RolloTron DECT belt winder pure is an electric roller shutter belt winder designed for use inside. The unit is installed as a flush-mounted device. The power supply is provided via the enclosed connecting cable with a mains plug. -
Page 12: Features
If the roller shutter hits an obstacle when it is being lowered, the RolloTron DECT belt winder pure is switched off. Then it is Manual operation on site or via the no longer possible to operate the device in the same direction ●... -
Page 13: Technical Specifications
7. Technical specifications Power supply Operating conditions 4 minutes Supply voltage: 230 V ~ / 50 Hz Transient operation (KB): (maximum running time) Nominal power: 70 W Protection class: Consumption: Standby: < 0.5 W IP20 (only for use in dry Protection type: rooms) Mechanical power... -
Page 14: Dimensions
7.1 Dimensions All dimensions in mm... -
Page 15: Permissible Roller Shutter Belts
7.2 Permissible roller shutter belts The RolloTron DECT belt winder pure may be dam- Permissible roller shutter belts aged if excessively long belts are used. Only use belts of the permissible lengths. RolloTron DECT belt winder pure Belt width: Belt thickness Maximum belt length The specifications are intended for guidance only 1.0 mm... -
Page 16: Installation
8. Installation Incorrect installation can lead to property You will require the following tools damage. Strong forces are exerted during operation of the Screwdriver ● ● system which require secure installation on a firm Scissors ● base. Carpenter's gauge or ●... -
Page 17: Preparation For Installation
8.1 Preparation for installation Removing the old belt winder Shortening and cutting the belt Fully close the roller shutter. Then remove the belt winder and completely unwind the belt. Recommendation CAUTION! Fit a deflection roller to the belt The pre-tensioned springs on the old belt winder box if the roller shutters are stiff. -
Page 18: Electrical Connection
8.2 Electrical connection The electrical connection can be made either with the connect- ing cable supplied or via a hard-wired cable on site. DANGER! There is a risk of fatal electric shock when touching electri- cal components. Carry out all installation and connection work in an isolated ●... - Page 19 WARNING! WARNING! A damaged connecting cable may cause a short circuit. The connecting cable may not be pinched when subsequently screwing on the RolloTron DECT belt winder pure as this could lead to damage.
-
Page 20: Drawing In And Fastening The Belt
8.3 Drawing in and fastening the belt Moving the fastening hook to the correct position Inserting the belt vertically from the top Belt path in the device Fastening hook Insert the mains plug into the socket. Feed the belt through the device, as shown in the image, and slide it over the fastening hook from above. - Page 21 8.3 Drawing in and fastening the belt Winding the belt a full rotation Insert the mains plug into the socket again. Place the reel compartment cover on the housing. Press the Up button until the belt has fully wound once around the reel.
-
Page 22: Mounting The Rollotron Dect Belt Winder Pure
Mount the RolloTron DECT belt winder pure as straight as possi- ble so that the belt can wind correctly. Slide the RolloTron DECT belt winder pure into the belt box and screw it tight using the screws provided. Then insert the mains plug into the socket. -
Page 23: Settings And Operation
It is imperative that both end points are set, otherwise malfunctions may occur. If the RolloTron DECT belt winder pure is operated without an end point setting, the drive will continue to run for as long as one of the two control buttons is actuated. - Page 24 Setting the wrong upper end point may lead to overload or tensioned by the weight of the roller shutter. damage the RolloTron DECT belt winder pure or the drive. Do not set the upper end point right up to the limit stop.
- Page 25 9.1 Setting the end points Correcting an end point Move the roller shutter to the centre position. Then reset the end point (example showing the upper end point).
-
Page 26: Dect Log-On / Log-Off
FRITZ!Box. 1 minute. During this time, start the DECT log-on to the FRITZ!Box. The “Info” or “DECT” LED flashes. Indicator lights on the RolloTron DECT belt winder pure Flashing red ● Indicator lights on the RolloTron DECT belt winder pure >... -
Page 27: Manual Mode
9.3 Manual mode Manual operation is possible at all times. Opening / closing the roller shutter Opening and closing by pressing and holding the button Briefly press one of the two buttons. The roller shutter travels in The roller shutter travels in the chosen direction to the end the chosen direction and stops at the set end point. -
Page 28: Setting The Favourite Position
9.4 Setting the favourite position If you do not want the RolloTron DECT belt winder pure to close to the lower end point, you can use this function to configure an arbitrary position (e.g. as ventilation position). Moving to and saving the favourite position... -
Page 29: Closing The Roller Shutter When The Favourite Position Is Active
9.5 Closing the roller shutter when the favourite position is active If the roller shutter is above or below the favourite position ... Favourite position End point ... it travels to the set ... it travels to the lower end point favourite position. -
Page 30: Deleting All Settings - Loading Factory Settings
LED flashes. Then the red LED lights up for 5 seconds. The following settings are erased after you release the buttons: End points ● Favourite position ● DECT base station (FRITZ!Box) ● Then the RolloTron DECT belt winder pure is reset to the default factory settings. -
Page 31: Removing The Rollotron Dect Belt Winder Pure
10. Removing the RolloTron DECT belt winder pure Reset the RolloTron DECT belt winder pure to the factory DECT 4 seconds settings. Completely close the roller shutter and continue to press and hold the Down button. Then pull out the belt as far as possible from the top of the RolloTron DECT belt winder pure. - Page 32 10. Removing the RolloTron DECT belt winder pure Open the reel compartment cover and check the position of the fastening hook. If necessary, move the fastening hook into an easily accessi- ble position. CAUTION! There is a risk of injury.
-
Page 33: Removing The Belt In The Event Of Device Failure
11. Removing the belt in the event of device failure In the event that the RolloTron DECT belt winder pure device Disengaging fails and the motor no longer runs, you can use the disengaging bracket bracket provided in order to completely remove the belt from the belt winder without the need for cutting it. -
Page 34: What To Do If
12. What to do if ... ? Fault Possible cause / solution ... the RolloTron DECT belt winder pure does not show Check the power supply including the connecting cable and plug. signs of working? ... the roller shutter no longer stops at the set end points? The end points may be displaced due to elongation of the belt. - Page 35 ... the RolloTron DECT belt winder pure fails to react prop The RolloTron DECT belt winder pure is no longer operational. Erase all settings, see erly either manually or automatically? page 30, and test the RolloTron DECT belt winder pure with the factory settings.
-
Page 36: Maintenance And Care
Check the RolloTron DECT belt winder pure and all of the ● roller shutter components regularly for damage. > > Check that the RolloTron DECT belt winder pure is func- tioning correctly. > > The shutter must not be damaged. -
Page 37: Simplified Eu Declaration Of Conformity
DELTA DORE RADEMACHER GmbH hereby declares The full text of the EU declaration of conformity is included with that the RolloTron DECT belt winder pure com- the product and is kept on file by the manufacturer. plies with the Directives 2006/42/EC (Machinery... - Page 40 DELTA DORE RADEMACHER GmbH Buschkamp 7 46414 Rhede (Germany)
