- Page 1 K X S E R I E S Oven Operation Guide APPLICABLE MODEL: KXP36-SS, KXP36-GL, KXD36, KXP30-SS, KXP30-GL, KXD30, KXP48-SS, KXP48-GL, KXD48, KXP60-SS, KXP60-GL...
-
Page 3: Table Of Contents
INDEX Product Specifications Display Instructions Function Instructions Power on Standby State 2.1. Clock Setting Start up State 3.1. Heating Mode Setting 3.2. Temperature Setting Heating State End State Lamp Setting Fan Setting Door Detection Fault Conditions K X S E R I E S Oven Operation Guide... -
Page 4: Product Specifications
PRODUCT SPECIFICATIONS Display type White Display light Button number Control method Knob Button Touch Button type Temperature performance T120 Input voltage 240V 240V/120V Working voltage Rated frequency 60Hz... -
Page 5: Display Instructions
DISPLAY INSTRUCTIONS... -
Page 6: Function Instructions
FUNCTION INSTRUCTIONS POWER ON After the product is powered on, there will be a "power on sound". The screen will display the product Logo and clock 12:00 (blinking), and the Finger Button will appear white. Next, enter the Clock Setting in the Standby State. -
Page 7: Clock Setting
FUNCTION INSTRUCTIONS 2.1. CLOCK SETTING After entering the Clock Setting, the clock blinks, indicating that the current clock can be adjusted, and the clock can be adjusted by turning the knob. The clock is set to 12 hours. 2. After adjusting the clock, click the Finger Button or do not operate for 5 seconds to exit the Clock Setting and return to the normal display in the Standby State. -
Page 8: Heating Mode Setting
FUNCTION INSTRUCTIONS 3.1. HEATING MODE SETTING This product provides two heating modes, namely bottom element heating and grill heating. 2. Click the Bottom baking Button to set the heating mode to bottom element heating. At this time, the Bottom baking Button remains fully lit, and the Grill heating Button turns dark;... -
Page 9: Heating State
FUNCTION INSTRUCTIONS HEATING STATE After entering the heating state, the time in the middle of the screen begins to accumulate. The maximum heating time is 2h, and the Finger Button in bright red. If the user selects the overheating mode in the Start up State, the selected heating mode is fully bright, and the unselected heating mode buttons are dimmed. -
Page 10: End State
FUNCTION INSTRUCTIONS 5. END STATE After entering the End State, the Finger Button is fully white, and the screen displays "End" on the left. 2. In the End State, click the Finger Button to enter the Start up State. 3. ln the End State, long press the Finger Button for 2s to return to the Standby State. -
Page 11: Fan Setting
FUNCTION INSTRUCTIONS FAN SETTING You can use the Fan Button to enable or disable the fan in any state except the Standby State and Fault Conditions. 2. After the Fan Button is started, the Fan Button is all on. After the fan is turned off, the Fan Button is dimmed. -
Page 12: Fault Conditions
FUNCTION INSTRUCTIONS FAULT CONDITIONS The oven malfunctions in the following cases. After a fault occurs, the oven will sound 20 fault sounds, and the corresponding fault code will be displayed in the center of the screen. 2. ln case of some failures, click the Finger Button to return to Start up State. - Page 13 TROUBLESHOOTING FAULT ERROR FAULT WETHER OVEN CAN CONDITION CODE REASON RESTORE TO START UP STATE NTC open circuit Open circuit or open NTC is detected NTC short circuit NTC short circuit is detected Abnormal Abnormal communication is detected communication Abnormal crystal Abnormal crystal oscillator detected Restore to original state oscillator...
- Page 14 WE TRANSFORM A SIMPLE KITCHEN INTO A PRO ONE. THIS IS WHY WE CARE ABOUT MAKING VERY HIGH PERFORMANCE RANGES AND HOODS, TO MAKE YOU FEEL LIKE A PRO AND STYLISH COOKER. DESIGN: LONDON DC - WWW.LONDON-DC.COM FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM...
