ARKSEN 002-SBR Owner's Manual

Folding hitch mounted ski / snowboard rack (fits 1.25" or 2" receiver)
Hide thumbs

Advertisement

Quick Links

Download this manual
Folding Hitch Mounted Ski / Snowboard Rack
(Fits 1.25" or 2" Receiver)
OWNER'S MANUAL
WARNING! CAUTION!
Read carefully and understand all ASSEMBLY AND/OR OPERATION
INSTRUCTION before using the product. Failure to follow the safety rules
and other basic safety precautions may result in serious personal injury.
Item# 002-SBR

Advertisement

loading
Need help?

Need help?

Do you have a question about the 002-SBR and is the answer not in the manual?

Questions and answers

tom
January 21, 2025

can i order parts -M8x35 Locking knob?

0

Related Manuals for ARKSEN 002-SBR

Summary of Contents for ARKSEN 002-SBR

  • Page 1 (Fits 1.25" or 2" Receiver) OWNER’S MANUAL WARNING! CAUTION! Read carefully and understand all ASSEMBLY AND/OR OPERATION INSTRUCTION before using the product. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 002-SBR...

  • Page 2: Table Of Contents

    owner’s manual Thank you for purchasing our product. This manual covers operation and maintenance information about the product. Read carefully and understand all instruction before using the product. All information in this publication is based on the latest product information available at the time of approval for printing.

  • Page 3: Warning And Precaution

    Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper SAVE THESE INSTRUCTIONS SPECIFICATION Model Number 002-SBR 6 pairs of skis 4 snowboards Max. Load Capacity 2 snowboards + 3 pairs of skis 99 lb Fit 1.25”...

  • Page 4: Package Content

    owner’s manual PACKAGE CONTENT Mounting Bracket Top Rack Bottom Rack M8 x 35 Locking Knob Bottom Post Top Post M8 x 20 M8 x 80 Locking Knob Bolt M8 Knob...
  • Page 5 owner’s manual PACKAGE CONTENT M8 x 65 Locking Knob Locking Nut Flat Washer Nut cap M12 x 80 Anti-Rattle Locking Knob Locking Nut Flat Washer Hitch Tightener Tie Down Strap Cover Stabilizer Strap Strap M5 Allen M8 Allen Wrench Wrench V-U-2023-09-18...

  • Page 6: Assembly Instruction

    owner’s manual ASSEMBLY INSTRUCTION Required Tools (Not Included) 1 (Installing on a 2" hitch tube) 2” Receiver Install the bracket into the hitch tube on your vehicle. The hitch pin screw must be tightened to avoid rattling.
  • Page 7 owner’s manual ASSEMBLY INSTRUCTION 1 (Installing on a 1.25" hitch tube) 1.25” Receiver *Remove the adapter if installing the bracket into a 1.25” hitch tube. Install the bracket into the hitch tube on your vehicle. The hitch pin screw must be tightened to avoid rattling. V-U-2023-09-18...
  • Page 8 owner’s manual ASSEMBLY INSTRUCTION Lock Unlock Lock the anti-thief system on the folding bracket knob. NOTE: Remove the key before moving or adjusting the rack. Do no not keep the key inserted in the lock. In case of lossing the key, contact your local locksmith.
  • Page 9 owner’s manual ASSEMBLY INSTRUCTION Option 1 2” Receiver Clamp down the bracket to the hitch tube with the anti-rattle hitch tightener. Option 2 1.25” Receiver V-U-2023-09-18...
  • Page 10 owner’s manual ASSEMBLY INSTRUCTION 17 18 Assemble the bottom post onto the bracket.
  • Page 11 owner’s manual ASSEMBLY INSTRUCTION Insert the pin through the bracket to secure the bottom post in place. V-U-2023-09-18...
  • Page 12 owner’s manual ASSEMBLY INSTRUCTION Secure the back of the bottom post with a M8 x 37.5 locking knob. Note：The hitch pin screw must be tightened to avoid rattling.
  • Page 13 owner’s manual ASSEMBLY INSTRUCTION *Beware of the orientation of the top post. Assemble the top post onto the bottom post. V-U-2023-09-18...
  • Page 14 owner’s manual ASSEMBLY INSTRUCTION Insert spacers into the top rack.
  • Page 15 owner’s manual ASSEMBLY INSTRUCTION Lock Unlock Unlock V-U-2023-09-18...
  • Page 16 owner’s manual ASSEMBLY INSTRUCTION Assemble the top rack on the top post.
  • Page 17 owner’s manual ASSEMBLY INSTRUCTION Insert pin through the top rack and the top post. V-U-2023-09-18...
  • Page 18 owner’s manual ASSEMBLY INSTRUCTION Assemble the bottom rack on the bottom post.
  • Page 19 owner’s manual ASSEMBLY INSTRUCTION Insert pin through the bottom rack and the bottom post. V-U-2023-09-18...

  • Page 20: User Instruction

    owner’s manual USER INSTRUCTION (LOADING) Unlock and open the front bar and spaces on the rack, then slide skis or snowboards into the rack one by one.
  • Page 21 owner’s manual USER INSTRUCTION (LOADING) loading. Always distribute the load evenly on the rack. 45 kg V-U-2023-09-18...
  • Page 22 owner’s manual USER INSTRUCTION (LOADING)
  • Page 23 owner’s manual USER INSTRUCTION (LOADING) Use a strap to secure the loads on the rack. You can use extra straps or webbings to secure your loading. V-U-2023-09-18...
  • Page 24 owner’s manual USER INSTRUCTION (LOADING) WARNING! Make sure there is adequate distance of space between the road and the bottom most part of your skis rack and create road harzard.
  • Page 25 owner’s manual ASSEMBLY INSTRUCTION The rack cannot fold properly if installed on the inner most opening on the post. V-U-2023-09-18...
  • Page 26 owner’s manual USER INSTRUCTION (FOLDING) NOTE: Please remember to use stabilizer strap to secure the rack when it folds. Stabilizer Strap Remove the pin on the rack and fold the rack toward the post, then secure the folded rack on the post by re-inserting the pin.
  • Page 27 owner’s manual USER INSTRUCTION (TILTING) Remove the pin and locking knob, then tilt the rack forward for easier vehicle trunk access. ATTENTION! WARNING! • Tilt the rack slowly and make sure there are enough clearance for the vehicle trunk to open. •...

  • Page 28: Care And Maintenance Instruction

    owner’s manual CARE AND MAINTENANCE • Periodically inspect the rack for signs of wear, corrosion, and fatigue. • Do not use the carrier with defective parts, contact the dealer to replace them before using it again. • Remove the product before entering an automatic car wash. •...
