Summary of Contents for Guardall QX18

  • Page 1 QX System Installation Manual Issue C...
  • Page 2: Table Of Contents

    ATTERY TANDBY EOL R ......................11 ESISTOR ONNECTIONS DIAGNOSTICS .............................12 ............................12 CCURACY ........................12 UPPLY EASUREMENTS LED..........................12 OMMS QX18/18I CONTROL UNIT........................13 QX34/34ICONTROL UNIT........................14 8 INPUT CONCENTRATOR.........................15 SMART CONCENTRATOR........................16 OUTPUT MODULE..........................17 ........................17 UTPUT ONNECTIONS DATA COMMS MODULE........................18 ...........................18 DDRESS ELECTION ..............................18 INKS LED I ..........................18...
  • Page 3: Statutory Requirements

    QX System Installation Manual – Issue C STATUTORY REQUIREMENTS Hereby Guardall, declares that the QX18i and the QX34i are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. If you have any doubts concerning the suitability, connection or uses of this apparatus then consult a suitably qualified person before continuing.
  • Page 4: Ce Declaration

    Guardall manuals, can be downloaded from the Guardall web site at, www.guardall.co.uk The documentation section of the Guardall web site is password protected, and you may have to apply for access using the on-line form provided on the site.
  • Page 5: Getting Started

    00:00 Sat 02 Jan The keypad will then display the time/date and company name. Guardall If the displayed message is as shown, or no bleep is heard, then the PX KP Type-n keypad is not responding so check the bus connections.
  • Page 6: Mains

    Where there is doubt as to the phase of this wiring , the device, when operated, will disconnect both poles simultaneously Mains Supply Item QX18/18i QX34/34i External power source 230VAC +/-10%, 50Hz 230VAC +/-10%, 50Hz...
  • Page 7: Order Codes

    QX System Installation Manual – Issue C Order Codes Order Code Description W74427 QX18i Control panel (English) W74489 QX18 Control panel (English) W76005 QX34i Control panel (English) W74494 QX34 Control panel (English) W73736 Diagnostic Concentrator (Plastic) W73807 LCD Keypad 2 Line standard...
  • Page 8: System Components

    1. A QX control unit, which processes all the alarm information from the detection points. Outputs are provided to operate sounders, strobe and communication devices. Configuration information is stored in EEPROM. The PX engineer manual details the features of the QX control panels. Feature QX18/QX18i QX34/QX34i Max. Circuits Max Concentrators Circuit Doubling Max.
  • Page 9 QX34i - 8 TX outputs 1.7km (unscreened cable) XiB Bus Sounder Strobe Output Mimic Data Concentrator SmartDial Audio Module Module Comms QX18/34 Module RS232 Tamper GuardStation / Printer RS232 or Serial QX18 - 5 TX outputs QX34 - 8 TX outputs...
  • Page 10: Technical Specification

    QX System Installation Manual – Issue C Technical Specification Technical Specification Environmental Parameter Range Temperature range -10 to 50 °C Humidity 10% to 90% relative humidity Technical Specification Cable Type The system has a 4-wire bus for all peripherals. The recommended cable type is 7-strand/0.2mm diameter un-screened cable, which has a resistance of 90 ohms/km and a core to core capacitance of 85nF/km.
  • Page 11: Current Consumption

    750 mA 750 mA 22 hours 155 mA 595 mA Technical Specification EOL Resistor Connections Type 1 EOL Network (Guardall) Type 2 EOL Network The EOL resistors are fitted in the detector as shown. This Alarm wiring arrangement applies to Tamper Alarm all EOL inputs in the system.
  • Page 12: Diagnostics

    QX System Installation Manual – Issue C Diagnostics Diagnostics Accuracy The diagnostic measurement error is typically less than 1%, with a maximum error 2.5%. This accuracy can only be achieved by programming the correct value of the 5V-reference voltage (option 69 on the main menu).
  • Page 13: Qx18/18I Control Unit

    QX System Installation Manual – Issue C QX18/18i Control Unit PSTN Green LED: PTT Line OK If an 8 ohm loudspeaker is Dialler used an 8R2 1/2W resistor must be connected in series Red LED: Dialer in use * Only used by 3rd party...
  • Page 14: Qx34/34Icontrol Unit

    QX System Installation Manual – Issue C QX34/34iControl Unit PSTN Green LED: PTT Line OK If an 8 ohm loudspeaker is Dialler used an 8R2 1/2W resistor must be connected in series Red LED: Dialer in use * Only used by 3rd party communicator Output 8 Output 7...
  • Page 15: Input Concentrator

    QX System Installation Manual – Issue C 8 Input Concentrator Address DIL Switch 6 5 4 3 2 1 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 1 1 Cct 1 Smart PSU Interface...
  • Page 16: Smart Concentrator

    QX System Installation Manual – Issue C Smart Concentrator The Smart Concentrator 0V connection must be connected to the PX panel. Do not connect the Smart Concentrator 12V to the PX panel. Via FS 2 XiB Bus Cct 8 Cct 7 Cct 6 Cct 5 Via FS 1...
  • Page 17: Output Module

    QX System Installation Manual – Issue C Output Module The 10k pull up is reduced to approximately 500R if a relay is fitted to Not used the same output channel. 820R Not used Output 8 Output 4 tamper contact Output 7 Output 3 Output 6 Output 2...
  • Page 18: Data Comms Module

    QX System Installation Manual – Issue C Data Comms Module Data Comms Module Address Selection The data comms module address can be set to 1 or 2 only. If a serial module is connected to the system then the serial module and data comms module addresses must be unique. Data Comms Module Links Link...
  • Page 19 QX System Installation Manual – Issue C Function Notes Engineer Keypad XiB bus to/from panel Ethernet 10 base T network Used for PC to panel communication over a network Port connection. or directly through a cross cable. Serial Port Standard Serial Port Used to provide GSR serial connections and print functions.
  • Page 20: Keypad

    QX System Installation Manual – Issue C Keypad To set the keypad address, open the case so Buzzer that the case tamper switch is activated. Then hold the help button (?) until the address prompt is displayed (approximately 4 seconds). Enter the chosen address using the numeric Proximity Reader keys.
  • Page 21: Proximity Reader

    QX System Installation Manual – Issue C Proximity Reader Proximity KeyPad Proximity Reader To Drive an LED directly from a keypad connect either the brown wire (Green LED) or the green wire (Red LED) to the OP terminal of the keypad. The keypad output can be programmed for set, entry/ exit or any other output function.
  • Page 24 Guardall Limited Lochend Industrial Estate Newbridge Edinburgh EH28 8PL Tel: 0131-333-2900 FAX: 0131-333-4919 www.guardall.co.uk Technical Hotline: 0131-333-3802 Part Number: 320870-0C...
