- Page 1 English User’s Manual XSA 1000 XSA 1000 BLACK...
- Page 2 Congratulations, you just have purchased a product with Intelbras quality and safety. The XSA 1000 / XSA 1000 BLACK universal support was structured to fit perfectly in most presence sensors available in the market and other equipments with compatible features, and also have a wide direction angle, support to wiring passage and UV protection for installing in outdoor environments.
- Page 3 Caution and safety » LGPD – Data processing by Intelbras: Intelbras does not access, transfer, capture or perform any type of processing of personal data from this product. » Follow all instructions in the manual for assembling and installing the product;...
-
Page 4: Table Of Contents
Summary 1. Technical specifications 2. Produto 3. Characteristics 4. Installation Term of Warranty... -
Page 5: Technical Specifications
1. Technical specifications General features Material Plastic with UV protection Weight 44 g Load capacity 1.5 kg Installation environment Internal external Dimensions (W × H × D) 99 × 58 × 64 mm Horizontal movement angle 160° Vertical movement angle 160° 2. Produto Components Axle... -
Page 6: Characteristics
3. Characteristics » Built in material with UV protection; » Easy Installation; » Wide application scenario; » Compatible with most compatible presence sensors on the market and other equipment that fits your applications. 4. Installation » Fix the axis (part 1) to the product, using the screws; ... - Page 7 » Position the ring (piece 3) in the assembly above with the opening at the beginning of the shaft (piece 1). Rotate the ring to fit the shaft; » Position the product so that the markings are aligned; Marcações Markings ...
- Page 8 Wall installation » If the sensor is installed on a flat surface, use the four innermost holes on the base for fixing. If the sensor is used on a 90° corner, use the four outermost holes on the base; Wall mounted Mounted in the corner of the wall Passage for the...
- Page 9 Cable routing The XSA 1000 support has an opening for cable passage, if necessary. Follow the steps below for correct use. 1. Guide the cable through the designated passage; 2. Secure the cable using the two internal locks; 3. Route the cable through the hole located in the center of the base, towards the inside of the sensor that will be fixed.
-
Page 10: Term Of Warranty
Term of Warranty It is expressed that this contractual warranty is granted according to the following conditions: Customer name: Customer’s signature: Tax Invoice No. Date of Purchase: Model: Serial No.: Retailer 1. All parts, pieces and components of this product are warranted against any manufacturing defects, which may arise within a period of 1 (one) year - being 90 (ninety) days of legal warranty and 9 (nine) months subject to con- tractual warranty - from the date when the Customer purchased the product,... - Page 11 Customer to regularly make secure backup of the product data. 7. Intelbras is not liable for the installation of this product, as well as eventu- al attempts of fraud and/or sabotage in their products. Keep software and applications up to date, and if necessary, the required network protections against intrusions (hackers).
- Page 12 Support via e-mail: suporte@intelbras.com.br Customer Service / Where to buy? / Who installs it?: 0800 7042767 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia BR 459, km 124, 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37540-000 CNPJ 82.901.000/0016-03 –...
