Remove and set aside the Catapult Bowl (I) and the
Cord (L). Sand both sides of the carrier board first with
150 grit and then 220 grit sandpaper.
Glue the second Upright (B) to the Gantry Brace (C).
Glue two Corner Braces (E) to the other Side Frame
(A). Glue the second Side Frame (A) to the Upright (B)
and the Cross Brace (G).
M I N I C ATA P U LT
Glue two Corner Braces (E) and the Cross Brace (G) to
a Side Frame (A). Glue the Gantry Brace (C) to an
Upright (B) as shown. Glue the upright to the Side
Frame (A)
Glue the End Frames (F) to the Corner Braces (E), and
the Crash Bar Halves (D) to the top of the Gantry
Brace (C).
