Operating Instructions
LED TV
Model No.
TX-75GX920B
For more detailed instructions, please refer to [eHELP]
(Built-in Operating Instructions).
●
How to use [eHELP]
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and retain them
for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0319-0
(image: TX-75GX920B)
(p. 20)
English
TQB0E2845U
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic TX-75GX920B
Summary of Contents for Panasonic TX-75GX920B
- Page 1 ● How to use [eHELP] (p. 20) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ··············································· 4 Accessories ························································ 8 Installing the TV ··················································· 8 Installing the wall-hanging bracket ··························10 Connections ·······················································10 Identifying Controls ··············································17 First time Auto Setup ············································19 Watching TV·······················································20 How to Use eHELP ··············································20 FAQs ································································22 Maintenance ······················································23 Specifications ·····················································24... -
Page 3: Important Notice
(excerpted from our privacy policy). We do this to protect our customers and the integrity of our Service as well as to protect the rights or property of Panasonic. If you wish to know more about the processing of your information in this context, please refer to the full text of our privacy policy displayed at [eHELP] (Search by Purpose >... -
Page 4: Safety Precautions
THE MOULDED MAINS PLUG of the copyright or other such rights in that content. FOR YOUR SAFETY, PLEASE READ THE Panasonic has no authority to and does not grant FOLLOWING TEXT CAREFULLY. you that permission and explicitly disclaims any right,... - Page 5 Do not use an unapproved pedestal / mounting ● Disconnect the mains plug when cleaning the TV. equipment. Be sure to ask your local Panasonic ● dealer to perform the setup or installation of approved Do not touch the mains plug with wet wall-hanging brackets.
- Page 6 To avoid malfunctions or slow physically damaged. If this occurs, contact your response caused by radio wave interference when nearest Panasonic dealer immediately. using the built-in wireless LAN, keep the TV away ● During setup, make sure that all screws are securely from other devices that use 2.4 GHz and...
- Page 7 Moving the TV LED TV Declaration of Conformity (DoC) Caution “Hereby, Panasonic Corporation declares that this TV is Before moving the TV, disconnect all cables. in compliance with the essential requirements and other ● At least two people are required to move the TV to relevant provisions of the Directive 2014/53/EU.”...
-
Page 8: Accessories
Accessories Installing the TV Standard accessories Assembling / Removing the pedestal Pedestal Remote Control (p. 17) ● N2QAYB001179 Assembly screw (4) M4 × 14 Pedestal Cover (p. 8) Cable clamp (p. 15) Preparations Cable tie (4) ● Do not hold the screen panel part. (p. - Page 9 Assembling the pedestal ● Insert the pedestal firmly, otherwise it may come off when setting up the TV. ● Do not assemble the pedestal by any method other than those specified below. Removing the pedestal Be sure to remove the pedestal in the following procedures when you use the wall-hanging bracket or repack the TV.
-
Page 10: Installing The Wall-Hanging Bracket
External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the Please contact your local Panasonic dealer to purchase mains socket before attaching or disconnecting any the recommended wall-hanging bracket. cables. - Page 11 Terminals Basic connections ■ Mains lead AC 220-240 V 50 / 60 Hz Mains lead ■ Aerial RF cable Terrestrial aerial ● For DVB, Analogue Satellite connection ● For Satellite ■ Dual Tuner 1 Model name plate 2 CI slot (p.
- Page 12 AV devices Network ■ A broadband network environment is required to be able DVD Recorder / Blu-ray Recorder, etc. to use internet services. ● If you do not have any broadband network services, please consult your retailer for assistance. ● Prepare the internet environment for wired connection or wireless connection.
- Page 13 ■ ■ [HDMI Auto Setting] (Setup Menu) Camcorder / Game equipment Reproduces the image more precisely with the (VIDEO equipment) expanded colour gamut when connecting the 4K compatible equipment. Select the mode depending on the equipment. [Mode1]: (Viewing) For better compatibility. Set to [Mode1] when the image or sound in HDMI input is not played properly.
- Page 14 ■ Common Interface ● Turn the TV off with Mains Power On / Off switch whenever inserting or removing the CI module. ● If a smart card and a CI module come as a set, first insert the CI module, then insert the smart card into the CI module.
- Page 15 ■ Fixing the cables using the cable tie Cable arrangement Fix the cables using the cable clamp, cable tie, etc. and then attach the cable cover / terminal cover to the TV. ■ Fixing the Mains lead using the cable clamp Attach the cable tie Insert the cable tie in a hole Hole...
- Page 16 ■ Attaching the cable cover / terminal cover ● Be careful not to nip the cables between the TV and the cable cover / terminal cover. ● When using USB 2 port, USB 3 port, HDMI3 terminal or HDMI4 terminal, you cannot attach the cable cover. Keep the removed cable cover for future use.
-
Page 17: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. 8 [Option Menu] Remote Control ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ● Used for the selection, navigation and operation of various functions. - Page 18 ■ Installing / Removing batteries Indicator / Control panel ● When pressing 4, 5, 6 buttons, the control panel guide appears on the right side of the screen for Pull open 3 seconds to highlight which button has been pressed. Hook Close Note the correct...
-
Page 19: First Time Auto Setup
First time Auto Setup Auto Setup is now complete and the TV is ready for viewing. If tuning has failed check the Satellite cable, RF cable, When the TV is turned on for the first time, it will and the network connection, and then follow the on- automatically search for available TV channels and give screen instructions. -
Page 20: Watching
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... - Page 21 ● To scroll the description (if more than 1 page) While the description is highlighted ● To open the reference screen ( ● To display the menu related to the description (only for some descriptions) (red) ● To check the features of this TV Search by Purpose >...
-
Page 22: Faqs
About the inquiry ● The fuse in the mains plug may have blown. Replace ● Please contact your local Panasonic dealer for it with one of an identical rating. (p. 4) assistance. If you make an inquiry from a place where this TV... -
Page 23: Maintenance
Maintenance First, remove the mains plug from the mains socket. Display panel, Cabinet, Pedestal Regular care: Gently wipe the surface of the display panel, cabinet, or pedestal by using a soft cloth to remove dirt or fingerprints. For stubborn dirt: (1) First clean the dust from the surface. -
Page 24: Specifications
USB (USB 3.0)] Model No. USB 2 / 3: DC 5 V, Max. 500 mA [Hi-Speed TX-75GX920B USB (USB 2.0)] Dimensions (W × H × D) DIGITAL AUDIO output 1 680 mm × 1 046 mm × 413 mm (With Pedestal) PCM / Dolby Audio, Fibre optic 1 680 mm ×... - Page 25 Operating conditions Temperature 0 °C - 35 °C Humidity 20 % - 80 % RH (non-condensing) Built-in wireless LAN Standard compliance and Frequency range* IEEE802.11a/n/ac 5.180 GHz - 5.320 GHz, 5.500 GHz - 5.580 GHz, 5.660 GHz - 5.700 GHz IEEE802.11b/g/n 2.412 GHz - 2.472 GHz Security...
- Page 28 • Or go on line through our Internet Accessory ordering application at www.pas-europe.com. • Most major credit and debit cards accepted. • All enquiries transactions and distribution facilities are provided directly by Panasonic UK. • It couldn’t be simpler! • Also available through our Internet is direct shopping for a wide range of finished products. Take a browse on our website for further details.
