- Page 1 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 ARC-45 45GPMMAX INSTALLATION AND OWNERS MANUAL WARNING BEFORE BEGINNING INSTALLATION OF THIS APSCO PRODUCT READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS...
- Page 2 APSCO facilitates drop shipments at FIGURE 2: TYPICAL INSTALLATION no extra charge. RETURNS – Unused, standard products may be returned to APSCO for full credit within 30 days of FIGURE 3: MOTOR ASSEMBLY ARC-45 purchase. A 20% restocking fee is charged thereafter.
- Page 3 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FLOW CONTROL VALVE INSTALLATION 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
-
Page 4: Features Included
Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FEATURES INCLUDED • Stainless Steel Construction • The basic size of our cooler is 20”X21”X9.5”, making it the most compact cooler in its class. • 4.25 Gallon Hydraulic Reservoir • Weight: 120 lbs dry, making it the lightest hydraulic cooler in its class •... - Page 5 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 1: ARC-45 DIMENSIONS 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
-
Page 6: Positioning And Mounting
Install filter cap. Slowly engage PTO with engine at idle speed. (See FIG. 6) The ARC-45 requires at least 2” air gap on the fan Check for hydraulic leaks and repair as needed. -
Page 7: System Maintenance
This is a good setting if all of your other system components are rated to at least 3000psi. Failure to set the relief valve 200psi higher than system pressure or any other system relief valve will result in excess buildup of heat. If you need to adjust the APSCO pressure relief valve it can be accessed by removing the relief valve access cover and manually adjusting with an Allen wrench. - Page 8 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 2: TYPICAL INSTALLATION 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 9 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 3: MOTOR ASSEMBLY ARC-45 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 10 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 4: ARC-45 INTERNAL COMPONENTS EXPLODED VIEW FIGURE 4A 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 11 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 4B 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 12 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 4C 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 13 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 5: ARC-45 EXTERNAL SHELL EXPLODED VIEW FIGURE 5A 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 14 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 5B 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 15 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 5C 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 16 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 5D FIGURE 5D 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 17 48 FT-LB 7656 FLOW REGULATOR 8-2 CAVITY 20 FT-LB 8133 TANK WELDMENT ARC-45 8328 ARC-45 MOTOR, FAN ASSEMBLY 7660 SIGHT LEVEL PLUG 1" BSPP 8 FT-LB 8110 O-RING 2-231 2 7/8 OD 2 5/8 ID 1733 O-RING 2-212 1 1/8 OD 7/8 ID...
- Page 18 CAP SCREW HH 1/4-20 X 1 1/4 6 FT-LB 3786 NUT 1/4-20 NC SS HEX NYLOCK 6 FT-LB 8138 RIGHT PANEL, ARC-45 8326 SIDE PANEL ASSEM ARC-45 8146 ACCESS PANEL, ARC-45 7709 1/4-20 X 5/8" SS TORX T30 BUTTON HD 6 FT-LB 8140 TOP PANEL, ARC-45...
- Page 19 It is recommended to do any repair work on a clean surface in a dust free environment. Once the ARC-45 is out of its case you will be able to remove and replace any of the components. If the repair requires you to remove the tank mount bracket (Item 34) mark the position of the bolts on the bracket so you can reinstall in the same position.
- Page 20 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 TABLE 2: TROUBLESHOOTING GUIDE Problem Cause Corrective Action • Low system pressure • The system pressure must be higher than Fan not spinning 900 psi for the fan to spin at full speed. • Low oil level in tank Slower fan speeds in an unloaded •...
- Page 21 Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 FIGURE 6: DRILL DIMENSIONS (NOT TO SCALE) 4221 S 68 E Ave., Tulsa, OK 74145 Sales: (918) 622-5600 ● Fax: (918) 622-5469 Email: sales@apscopower.com...
- Page 22 Buyer and are estimates of approximate dates of Acceptance as aforesaid shall be deemed full performance of APSCO’s delivery, not a guaranty of a particular day of delivery. APSCO shall not obligation hereunder. be liable for failure or delay in shipping goods if such failure or delay is due to an act of God, War, Labor difficulties, Accident, inability to 7.
- Page 23 DUMP REFUSE & WASTE Product Catalog: ARC-45-IOM Revision Date: 09.12.2022 APSCO, Inc. Voice: +1.918.622.5600 4221 S 68 E Ave., Suite A, Fax: +918.622.5469 Tulsa, OK 74145 sales@apscopower.com www.apscopower.com Distributed by In order to provide you the highest quality, full featured products, we reserve the right to change our specifications and designs at any time.
