- Page 1 GRIZZL E™ ULTIMATE EV CHARGER INSTALLATION MANUAL...
- Page 2 GRIZZL-E ULTIMATE INSTALLATION MANUAL This manual is for the installation of the Grizzl-E Ultimate 80A Level 2 EVSE. This manual includes information on the safety, installation, moving, and storage of the EVSE. This document provides instructions for the listed model numbers and should not be used for any other product.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. IMPORTANT SAFETY INSTRUCTIONS ..............1 1.1 INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR ELECTRIC SHOCK ..1 1.2 USER MAINTENANCE INSTRUCTIONS .............2 1.3 MOVING, TRANSPORTING, AND STORAGE INSTRUCTIONS ......2 2. PRODUCT SPECIFICATIONS ................3 3. INTRODUCTION & UNPACKING ................ 4 3.1 YOUR CHARGER ....................4 3.2 PACKAGE CONTENTS ..................5 4. -
Page 4: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS This document contains instructions and warnings that must be followed when installing the Grizzl-E Ultimate 80A Level 2 Electric Vehicle Supply Equipment (EVSE). Before installing the EVSE, read this document including any WARNING and CAUTION symbols. The Symbols Used Have the Following Meanings WARNING: risk of personal injury WARNING: risk of fire... -
Page 5: User Maintenance Instructions
1.2 USER MAINTENANCE INSTRUCTIONS The Grizzl-E Ultimate 80A Level 2 EVSE does not require routine maintenance. Check before each charging session to ensure that cables and enclosure remain in good working order and no damage exists. The exterior of the charging station is designed to be waterproof and dustproof (UL Type 4 Indoor/Outdoor Rating). -
Page 6: Product Specifications
2. PRODUCT SPECIFICATIONS Description Specifications GRU-077-W-HW-25IJ80-A-GB Model Numbers GRU-077-W-HW-25DJ80-A-GB GRU-077-W-HW-25SN80-A-GB EVSE Level AC Level 2 Max Output 80A; 19.2 kW Maximum Output For use with a 100A Circuit Rating Rating 48A; 11.52 kW Maximum Output – For use with 60A Circuit Rating 40A;... -
Page 7: Introduction & Unpacking
3. INTRODUCTION & UNPACKING 3.1 YOUR CHARGER U L T I M A T E Charger Components 1. Input Hardwire Connection 2. Output Cable J1772 Connector 3. Latch Release Button 4. Indicator Light 5. External Antenna... -
Page 8: Package Contents
3.2 PACKAGE CONTENTS Mounting Kit Socket Cap Robertson Head Screw (x4) Screws (x2) Security Pin(x1) Mounting Bracket (x1) Hardwire Kit Terminal Lugs (x3) Shrink Wrap (x3) Charging Holster E A S Y E V PL G Phillips-head Anchor (x4) Screws (x4) Holster (x1) -
Page 9: Installation Planning And Service Wiring
4. INSTALLATION PLANNING AND SERVICE WIRING: WARNING: Disconnect the power supply to the charging station before installing or adjusting the charging station. Failure to do so may result in physical injury or damage to the power supply system and the charging station. -
Page 10: Grounding Instructions
4.2 GROUNDING INSTRUCTIONS This product must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment grounding conductor and a grounding plug. -
Page 11: Adjustable Maximum Current Output
5. ADJUSTABLE MAXIMUM CURRENT OUTPUT The Grizzl-E Ultimate EVSE features the ability to adjust the maximum current output to support 100A, 60A, 50A, 40A, 30A, or 20A Dedicated Circuit ratings as follows: Circuit Rating Maximum Charging Station Output 100A 80A (19.2 kW) 48A (11.56 kW) 40A (9.6 kW) 32A (7.68 kW) - Page 12 2. Place the front cover to the side. Locate the DIP switch on the charging station circuit board. The DIP switch is a 4-position switch on the top circuit board, located on the right side of the charger. WARNING: Do not touch live electrical parts. Disconnect the power supply to the charging station before adjusting the DIP Switches.
- Page 13 3. Adjust the Maximum Current Output to either 80A, 48A, 40A, 32A, 24A or 16A, using the following combination of DIP switch settings: Maximum Current Switch 1 Switch 2 Switch 3 Switch 4 Diagram 80A Maximum Current Output 48A Maximum Current Output 40A Maximum Current Output 32A Maximum Current Output 24A Maximum Current Output...
-
Page 14: Installation
6. INSTALLATION 6.1 INSTALL THE CHARGING STATION Prior to mounting, determine the location of an acceptable mounting support. All charging station products must be anchored into a mounting support such as a 2” x 4” stud or a solid concrete wall. DO NOT mount this unit directly to a stucco/drywall. 1. - Page 15 3. Secure the back piece of the mounting bracket to the wall or other suitable structure using the Robertson-head screws. The back piece of the mounting bracket has 3 holes to support attachment to various surfaces. Use the top two holes to attach the mounting bracket to a wall stud. Mounting Screw Recommendations: •...
- Page 16 4. Mount the charger on the wall by securing the front piece of the mounting bracket to the back piece of the mounting bracket. 5. Secure the charger in place by inserting either the security pin or the outdoor security lock into the mounting bracket.
-
Page 17: Hardwire Connection
7. HARDWIRE CONNECTION WARNING: Wiring connection must be done by a licensed contractor, licensed electrician, or trained installation expert Follow all applicable electrical codes and safety standards. Ensure all parts and tools meet regulations. Failure to wire station correctly may lead to risk of electrocution, personal injury, or fire. -
Page 18: Hardwire Charger
7.2 HARDWIRE CHARGER 1. Remove the front cover of the charging station by removing the 4 screws at each corner of the charging station. Use 5/32” (M4) hex key to remove screws. 2. Release the screw from the Terminal Lugs using a flat screwdriver. 3. - Page 19 6. Feed the input wires (L1, L2, G) through the conduit into the charger. 7. Feed L1 and L2 wire through the transformer. 8. Place heat shrink tube over the terminal lugs. 9. Insert G, L1, and L2 wires to the corresponding Terminal Lug.
-
Page 20: Easyevplug Holster
8. EASYEVPLUG HOLSTER The EasyEvPlug Holster is used to protect the charging plug and manage the cable when the EVSE is not in use. The Plug Holster can be installed at any location near the charging station. To install the EasyEvPlug Holster: E A S Y E V P L G 1. -
Page 21: Warranty
The cumulative liability of United Chargers for warranty claims will not exceed the original price of the charging station. United Chargers shall make the final decision, in fairness to all concerned, as to the legitimacy of any such claim on this warranty. - Page 22 The most up to date User Manual is available online: https://grizzl-e.com/user-manuals/ Visit our Technical Support page: https://autochargers.zendesk.com/hc/en-ca View the full terms and conditions: https://grizzl-e.com/returns/ Phone: +1-833-971-8118 E-mail: info@unitedchargers.com Website: https://grizzl-e.com/ United Chargers Inc. 25 Pollard St, Richmond Hill, ON, Canada, L4B 1A8...
