- Page 1 GRIZZL E™ ULTIMATE EV CHARGER OPERATION MANUAL...
- Page 2 GRIZZL-E ULTIMATE OPERATION MANUAL This manual is for the use and operation of the Grizzl-E Ultimate 80A Level 2 EVSE. This manual includes information on the safety, operation, indicator lights, and smart features of the EVSE. This document provides instructions for the listed model numbers and should not be used for any other product.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. IMPORTANT SAFETY INSTRUCTIONS ..............1 1.1 INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR ELECTRIC SHOCK ..1 1.2 USER MAINTENANCE INSTRUCTIONS .............2 1.3 MOVING, TRANSPORTING, AND STORAGE INSTRUCTIONS ......2 2. OPERATION INSTRUCTIONS ................3 2.1 INSERT CONNECTOR ..................3 2.2 DISCONNECT CONNECTOR ................3 3. -
Page 4: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS This document contains instructions and warnings that must be followed when operating the Grizzl-E Ultimate 80A Level 2 Electric Vehicle Supply Equipment (EVSE). Before using the EVSE, read this document including any WARNING and CAUTION symbols. The Symbols Used Have the Following Meanings WARNING: risk of personal injury WARNING: risk of fire... -
Page 5: User Maintenance Instructions
1.2 USER MAINTENANCE INSTRUCTIONS The EVSE does not require routine maintenance. Check before each charging session to ensure that cables and enclosure remain in good working order and no damage exists. The exterior of the charging station is designed to be waterproof and dust proof (UL Type 4 Indoor/Outdoor Rating). -
Page 6: Operation Instructions
2. OPERATION INSTRUCTIONS 2.1 INSERT CONNECTOR J1772 1. Press down on the latch release button. Ensure latch release button is fully compressed. 2. Insert the charging connector into the EV and ensure the connector is fully seated/locked in place. 3. Release the latch release button. NACS 1. -
Page 7: Charging Status Indicators And Buzzers
3. CHARGING STATUS INDICATORS AND BUZZERS 3.1 INDICATOR LIGHTS The following indicator lights are used to display the charger status: LED Indicator Buzzer Description Definition Charging station No buzzer White Steady Booting Up or Processing Software Charger Ready No buzzer Blue Steady Not connected to server Charger Ready... -
Page 8: Led Fault Indicator
3.2 LED FAULT INDICATOR When the charger experiences an error, the red light will flash, and the buzzer will beep a specific number of times. The cycle will pause for 1 second and repeat. The number of red flashes and beeps indicates the type of fault: LED Indicator # of Flashes Error Description... -
Page 9: Ocpp Through Grizzl-E Connect
4. OCPP THROUGH GRIZZL-E CONNECT 4.1 CONNECT TO OCPP THROUGH GRIZZL-E CONNECT APP Connect charger to local Wi-Fi network to use OCPP and the Grizzl-E Connect Application for iOS or Android. OCPP Grizzl-E Connect settings will override local smart features described in 5. - Page 10 5. Select the Search button to show the list of available networks. 6. Select your network from the list of available networks. Click directly on the network name. The network name will populate the Wi-Fi name field. Ensure network is 2.4 GHz and has a signal strength greater than -67 RSSI (optimal range -40 to -60 dbm).
-
Page 11: Local Smart Features
5. LOCAL SMART FEATURES Local Smart features are available when connected to the charger’s Wi-Fi network. Follow the instructions in this section to access and use Local Smart Features: • Local Wi-Fi Smart features can be accessed by any device that connects to WI-Fi (Smart Phone, Laptop, Computer). - Page 12 Adjustments Current limit, A: Set the maximum current by using the slider: Note: Only Maximum Current settings equal to or less than the DIP switch settings will display. See the Installation Manual for information on how to change the Maximum Current settings through the DIP switches.
-
Page 13: Timer
5.2 TIMER Charge Now Suspend Limits: Enable the Suspend Limits button to bypass all limits and schedules and begin the charging session. All set Limitations will disable. One charge: Enable the One Charge button to bypass all limits and schedules and begin the charging session. - Page 14 Rates Set the Rates per kWh to calculate the cost of the charging session. Rates are set to $ per kWh. Primary Rate: Type the primary rate into the text box. Example: 0.12 = 12¢/kWh. This rate will apply unless Rate 2 or Rate 3 are activated.
- Page 15 System Time 1. Set the system Time for all schedules and rates: 2. Enter the time in the Current Time field. 3. Enter the Time Zone. Follow the chart below to enter the correct Time Zone: Time Zone UTC - Standard Time UTC - Day Light Savings Time Eastern Central...
-
Page 16: Setup
5.3 SETUP WiFi AP Configuration Use this setting to configure the charger’s Wi-Fi network. AP Name: Name of the Charger network. The default is the serial number. Change to any network name. AP Password: The password for the charger’s Wi-Fi network. The default is no password. Set a password for the Charger network to prevent others from accessing the network. - Page 17 5. Select the MAC Address from the closest available access point. Multiple MAC Addresses will display if the network has more than one access point. Click directly on the MAC Address to populate the to populate the Mac of router field. 6.
-
Page 18: Advanced
5.4 ADVANCED Session History Session History displays statistics from the 4 most recent charging sessions. Session History will display the following fields: • Date • Energy (kWh) • Time • Cost Data from previous charging sessions beyond the 4 most recent is not saved. Adaptive Mode Adaptive Mode automatically adjusts the current to the charger if there is an unexpected drop in voltage threshold from your electric provider. - Page 19 Other Timer Type There are two different Timer Types: • noPWM • The Timer Type is the algorithm for a delayed charge (for example, a scheduled charge). The type of algorithm used depends on the vehicle. If a scheduled charge does not work as expected, try using a different Timer Type for better results.
-
Page 20: Charger Wi-Fi Features
6. CHARGER WI-FI FEATURES 6.1 DISABLE SMART FEATURES Disabling the Smart Features will turn off any smart settings described in 4. OCPP Through Grizzl-E Connect 5. Local Smart Features on page 8 . The charger will enter ‘dumb mode’ in which all charging controls are directed by the vehicle. The Wi-Fi network and Smart Settings page remains visible but will not control the charging station. -
Page 21: Wi-Fi Connection Reset
6.2 WI-FI CONNECTION RESET Use the Wi-Fi Connection Reset to clear the following Wi-Fi credentials from the charger: • “WiFi AP Configuration” AP Name and AP Password will reset to the default. Wi-Fi Name and Password will be cleared. • “Wi-Fi Connect Configuration”... -
Page 22: Warranty
The cumulative liability of United Chargers for warranty claims will not exceed the original price of the charging station. United Chargers shall make the final decision, in fairness to all concerned, as to the legitimacy of any such claim on this warranty. - Page 23 The most up to date User Manual is available online: https://grizzl-e.com/user-manuals/ Visit our Technical Support page: https://autochargers.zendesk.com/hc/en-ca View the full terms and conditions: https://grizzl-e.com/returns/ Phone: +1-833-971-8118 E-mail: info@unitedchargers.com Website: https://grizzl-e.com/ United Chargers Inc. 25 Pollard St, Richmond Hill, ON, Canada, L4B 1A8...
