COMPONENT PARTS

1 Switch
2 Handle
3 Top cover
4 Middle cover
5 Motor
6 Base cover
7 HEPA filter
8 Cover
9 Safety valve
10 Water valve unit
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
11 Detergent inlet tube 21
12 Clip
13 Detergent tank
14 Wheel support
15 Rear wheel
16 Castor
17 Base
18 SS tank
19 Paper bag
20 Sponge filter
16
Crevice nozzle
22 Detergent tube
23 Water pump
24 Hose
25 Spray control
26 Sofa spray brush
27 Carpet brush
28 Plastic tube
29 Airflow control
30 Wet/dry floor brush
