- Page 1 WET/DRY CARPET & UPHOLSTERY CLEANER MODEL NO: CVAC20CCSS PART NO: 6471098 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC09/23...
-
Page 2: Specification
4.43 m Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 3: Safety Precautions
3. NEVER use this machine if any part is damaged. Have it inspected and repaired by your CLARKE dealer. Do not use if the electric cable, plug, or the machine itself, is in poor condition. 4. NEVER abuse the power cable. Never pull on the cable when removing the plug from the socket or lift the machine by the power cable. -
Page 4: Care And Storage
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal facility. GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for its intended purpose. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 6 INVENTORY OF COMPONENTS No Description No Description Tank unit Washing Brush (for carpet) Flexible hose & detergent spraygun 10 Wet & Dry Floor Brush 2 x Connecting Tubes Crevice Nozzle HEPA Filter Detergent tank Sponge Filter (optional) Rear wheels Paper Filter Front wheels Cloth Bag (for dry use) Screws for rear wheels...
-
Page 7: Preparation For Use
PREPARATION FOR USE WARNING: BEFORE USING THE CVAC, MAKE SURE THAT YOU HAVE READ AND UNDERSTOOD THE SAFETY INSTRUCTIONS UNPACKING & ASSEMBLY With the CVAC removed from the packaging, undo the two clamps securing the head and remove the components from within the tank. Lay them out and check for shortages and that no damage was suffered in transit. -
Page 8: Fitting The Filters
FITTING THE FILTERS Filters are essential to ensure that dust or foreign matter does not enter the motor compartment which would reduce motor efficiency and eventually cause serious damage. 1. Fit the HEPA filter or the alternative sponge filter into the top of the water valve housing. - Page 9 HOSE, TUBE, BRUSH & DETERGENT PIPE 1. Check the security and tightness of the following connections in case of suction or residue leakage. 2. Connect the hose, tubes and brushes together as shown. Different brushes should be connected with the detergent spray gun to tubes. To connect, twist the hose end clockwise.
- Page 10 DETERGENT PIPES 4. Fill the detergent tank with detergent (max volume 3L) using the visual scale on the side of the tank. • Thick detergent should be diluted if there is a possibility of clogging the pipe. • The detergent level indicator should always be under the opening of the detergent tank or it will be hard to pump the detergent out.
-
Page 11: Operation
OPERATION SWITCH Using the (-) symbol the unit works as a common wet/dry vacuum cleaner Using the SPRAY symbol, the detergent pump and spray gun works. CARPET AND SOFA WASHING Choose the corresponding brush for your cleaning tasks. Ensure there is enough detergent in the tank for best performance. -
Page 12: Floor Cleaning
FLOOR CLEANING Use the wet & dry floor brush for cleaning the floor of dust, debris or spillage. • Use the dust bag for dry use only • Use either the fine sponge or HEPA filter for dry dust only •... - Page 13 Before use, open the machine and check that the appropriate filters are securely in place and in good condition. If the paper bag is full, replace it. Spare bags are available from your CLARKE stockist. Switch on and start work. The machine should be positioned on a firm, level surface.
-
Page 14: Troubleshooting
TROUBLESHOOTING Symptom Possible Cause Corrective action Leaks from hose/tubes/ Accessories are not Follow assembly instructions pipes installed correctly and check the tightness of Rubber seal ring on the all joints. detergent pipe is broken For repairs, contact your or loose. dealer. -
Page 15: Maintenance
Inspect all other components periodically and replace damaged castors or accessories when necessary. Contact your CLARKE dealer for replacements. Regular inspection and the correct maintenance of the filters will ensure efficient running and prolong the life of your machine. -
Page 16: Component Parts
COMPONENT PARTS Switch Detergent inlet tube 21 Crevice nozzle Handle Clip Detergent tube Top cover Detergent tank Water pump Middle cover Wheel support Hose Motor Rear wheel Spray control Base cover Castor Sofa spray brush HEPA filter Base Carpet brush Cover SS tank Plastic tube... - Page 17 DECLARATION OF CONFORMITY-UK Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 18: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY-CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 19 NOTES ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ ____________________________________________________________________________ Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
