- Page 1 PSA-631 Power Distributor...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 19.02.2024, ID: 258281 (V3)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Installation and starting up........................ 11 Connections and controls........................12 Technical specifications........................14 Protecting the environment......................16 PSA-631 Power Distributor... - Page 4 PSA-631 Power Distributor...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Warning signs Type of danger Warning – high-voltage. Warning – danger zone. PSA-631 Power Distributor...
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is used to distribute electrical power to several connected consumers. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 8 Safety instructions DANGER! Risk of death from electrical current! A short circuit can cause fires and loss of life. Always use a properly insulated CEE cable to connect the unit to the 400 V mains grid. Do not modify the CEE cable or the CEE plug. If the insulation is damaged, immediately switch off the power supply and have it repaired.
- Page 9 Safety instructions NOTICE! Possible staining due to plasticiser in rubber feet! The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. PSA-631 Power Distributor...
-
Page 10: Features
Features Features Power distributor 63 A Digital voltage (‘V’) and current (‘A’) display for each output Input – Cable with CEE plug Outputs – 4 × 5-pin CEE built-in socket with hinged lid Circuit breaker with trigger switch for each output Four-pole residual current device (RCD, residual current circuit breaker) for the input PSA-631 Power Distributor... -
Page 11: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 12: Connections And Controls
Connections and controls Connections and controls Front panel ö # ® 0-OFF RESIDUAL CURRENT CIRCUIT BREAKER PSA-631 1 Residual current device (RCD). This protective device, also known as “Fehlerstrom-Schutzschalter” or “FI-Schalter” in German- speaking countries, is designed to protect persons. As soon as it detects differential current / fault current, it automatically disconnects the device from the mains. - Page 13 Connections and controls Rear panel ö POWER INPUT: 400A~50Hz,63A/Phase OUTPUT: 3x32A OUTPUT: 3x32A OUTPUT: 3x32A OUTPUT: 3x32A 1 4 × 5-pin CEE panel socket with hinged lid 2 Power cable with CEE plug PSA-631 Power Distributor...
-
Page 14: Technical Specifications
Technical specifications Technical specifications Input connections Power supply Power cable with CEE plug Power cord: H07RN-F 5G16 mm² Output connections 4 × CEE chassis socket 32 A, three-phase, 5-pin Safety Residual current device Trigger characteristic Type C (RCD) / input Rated current 63 A Rated differential current... - Page 15 Technical specifications Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20 %…80 % (non-condensing) PSA-631 Power Distributor...
-
Page 16: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 17 Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it.
- Page 18 Notes PSA-631 Power Distributor...
- Page 20 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
