  • Page 1 KTE-300 Camera Housing...
  • Page 2 © 2002 Kalatel, a GE Interlogix company All Rights Reserved. Any GE Interlogix, Kalatel division, software This equipment has been tested and supplied with GE Interlogix, Kalatel division, found to comply with the limits for a products is proprietary and furnished under...

  • Page 3: Table Of Contents

    KTE-300 Camera Housing Table of Contents ABLE OF ONTENTS ..............4 EFORE EGIN ..........5 OUNTING THE RACKET ..........6 PENING THE OVER ......7 TTACHING THE OUSING AND AMERA ........10 AKING ABLE ONNECTIONS 4.1 C ........10 ONNECTING TO AMERAS ...........11 LOSING THE OUSING...

  • Page 4: Before You Begin

    Before You Begin KTE-300 Camera Housing EFORE EGIN Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: •...

  • Page 5: Mounting Theb

    KTE-300 Camera Housing Mounting the Bracket OUNTING THE RACKET Ensure that cables are accessible at the chosen mounting location prior to the installation of the bracket. There should be at least 28 inches (71 cm) of free cable to run through the housing and make connections.

  • Page 6: Cover

    Opening the Housing KTE-300 Camera Housing PENING THE OVER To open the back cover, see Figure 2 and perform the following. Slide the sunshield forward at least 4 inches (10 cm). Use a screwdriver to loosen and remove the screw in the back cover of the housing.

  • Page 7: Ousing And Amera

    KTE-300 Camera Housing Attaching the Housing and Camera TTACHING THE OUSING AND AMERA To attach the housing to the bracket, see Figure 3 and perform the following. Cables passing through the swivel head on the housing Cable opening Attachment screw Figure 3.
  • Page 8 Attaching the Housing and Camera KTE-300 Camera Housing When you feed the cables through the swivel head, leave enough slack to allow for adjustments in the position of the housing. (See Figure 4) Figure 4. Slack should be left in the cables inside the swivel head To open the housing, see Figure 5 and perform the following.
  • Page 9 KTE-300 Camera Housing Attaching the Housing and Camera To feed the cables into the housing see Figure 6 and perform the following. Loosen the ring nuts on the cable glands and remove the plugs. Feed the cables through the cable glands, leaving some slack between the cable glands and swivel head.

  • Page 10: Onnections

    Heater 24 VAC in (connected at factory) (Heater requires 24 VAC 13W) (Blower requires 24 VAC 4W) Figure 7. Cable connections to the KTE-300 housing panel ONNECTING TO AMERAS To make cable connections to the camera see Figure 8. Video Figure 8.
  • Page 11 KTE-300 Camera Housing Closing the Housing LOSING THE OUSING To close the housing, see Figure 9 and perform the following. Body screws Body Runners Outer slide Outer Inner screw slide slide Figure 9. Closing the housing Lift the body so that it extends directly out from the end of the outer slide.
  • Page 12 Closing the Housing KTE-300 Camera Housing To secure the back cover and sunshield, see Figure 10 and perform the following. Back cover screw Back cover Sun shield Runners on housing Figure 10. Securing the back cover and sunshield Swing the back cover down until it fits over the swivel head.

  • Page 13: Closing The Housing Appendix A: Using The Adapter Mount

    NIVERSAL DAPTER OUNT Use the universal adapter mount to attach the KTE-300 housing to the KTA-25 Corner-Mount Adapter, KTA-27 Roof-Mount Adapter, KTA-29 Parapet Capping Brackets, or KTA-26 Pole-Mount Adapter. The KTA adapters and brackets come with the connection bolts required to attach them to the universal adapter.
  • Page 14 Appendix A KTE-300 Camera Housing Pass the bolts and washer through the front access holes and seat them in the rear mounting holes. Secure the bolts. Feed the cables through the pass-through holes on both adapters. Attach the adapters to the mounting surface.

  • Page 15: Appendix B: Using The Adapter

    KTA-26 Pole Mount Adapter. The KTA-26 uses adjustable metal straps to connect to the pole. Figure 13. Attaching the KTE-300 bracket to one side of the pole-mount adapter. If you are using cables that are external to the mounting pole, remove one of the slot covers on the KTE-300 mounting bracket (Figure 1).
  • Page 16 If the cables are external to the pole, feed them into the hole opened by the removal of the slot cover (Figure 1) and through the housing bracket. Figure 14. Attaching the KTE-300 and pole-mount adapter to a pole with internal cables. To complete the housing installation, return to Section 2.

  • Page 17: Information

    • Fewer than 45 days from purchase, GE Interlogix, Kalatel division, will replace the product with new equipment. • From 45 days to 1 year from purchase, GE Interlogix, Kalatel division, will replace the product with refurbished equipment. • From 1 year to 3 years from purchase, the product must be sent in for repair.
