TMG-AGT20
PRODUCT MANUAL
v2023.01.06
4400-LB ADJUSTABALE
PUSH TROLLEY
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Advertisement
Table of Contents
Related Manuals for TMG TMG-AGT20
Summary of Contents for TMG TMG-AGT20
- Page 1 TMG-AGT20 PRODUCT MANUAL v2023.01.06 4400-LB ADJUSTABALE PUSH TROLLEY Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT INFORMATION AND WARNINGS......................3 IMPORTANT SAFETY INSTRUCTIONS........................3 WARNINGS AND PRECAUTIONS...........................4 PRODUCTS SPECIFICATIONS..........................5 INSTALLATION..............................6 OPERATION................................7 INSPECTION................................8 MAINTENANCE..............................10 TROUBLESHOOTING............................10 PARTS LIST AND EXPLOSION VIEW........................11 Conventions used in this manual WARNING This indicates a hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION This indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury. -
Page 3: Important Information And Warnings
• Remove all grease, oil, dirt, corrosion and mill scale from the supporting beam at the point where the trolley is to be attached. • Never modify the beam trolley. Never weld on or drill through any beam trolley parts. Approval from TMG INDUSTRIAL is required for all nonstandard maintenance. -
Page 4: Warnings And Precautions
2. Record your beam trolley’s model, purchasing date and Serial Number on the front cover of this manual for identification and future reference to avoid referring to the wrong manual for information or instructions on installation, operation, inspection, maintenance, or parts. 3. Use only TMG INDUSTRIAL authorized replacement parts in the service and maintenance of this hoist PROD... -
Page 5: Products Specifications
PRODUCT SPECIFICATIONS MODEL CAPACITY TMG-AGT20 2 TON 11” 10-3/4” 9-3/16” 1-3/4” 1-3/8” 1-7/8” 5-1/8” 2-3/4” 1/8” MODEL CAPACITY FLANGE WIDTH MINIMUM CURVE RADIUS SHIPPING WEIGHT TMG-AGT20 2TON 3” - 6-1/2” 43” 30 LBS... -
Page 6: Installation
Inspect carefully for any damage that may have occurred during shipping. Check for loose, missing, or damaged parts.Do not install or use a damaged product. Contact TMG INDUSTRIAL if there are any problems. 2. Mounting Location Prior to mounting the trolley (and hoist) ensures that the trolley beam and its supporting structure are adequate to support the trolley, hoist, and its loads. -
Page 7: Operation
OPERATION INSTRUCTIONS 1. Operator Requirements • Read and fully comprehend this entire manual before operation. Operator must be trained in proper trolley operation and dealing with potential malfunctions. Should not operate trolley while under influence of alcohol, medications, or drugs. Should not operate the trolley while tired or distracted. -
Page 8: Inspection
ASME/ANSI/OSHA INSPECTION PROCEDURES 1. General There are two types of inspection: the frequent inspection performed by the operator and periodic inspections performed by personnel trained in inspection and maintenance of the trolley. Careful inspection on a regular basis will reveal potentially dangerous conditions while still in the early stages, allowing corrective action to be taken before the condition becomes dangerous. - Page 9 2. Records and Reports • Some form of inspection record should be maintained for each trolley, listing all points requiring periodic inspection. A written report should be made quarterly on the condition of the critical parts (e.g. wheels, bearings, side plates and hoist hanger shaft) of each trolley.
-
Page 10: Maintenance
MAINTENANCE INSTRUCTION 1. Maintenance & Handling Proper use, inspections and maintenance will increase the life and usefulness of your equipment. During assembly lubricate gears, nuts, bolts and all machined threads with applicable lubricants. Use of anti-seize compound and/or thread lubricant on cap-screw and nut threaded areas prevents corrosion and allows for ease of disassembly of component. -
Page 11: Parts List And Explosion View
PARTS LIST AND EXPLOSIVE VIEW Assembly Diagram Parts List PART NO. DESCRIPTION PART NO. DESCRIPTION Wheel Side plate Bearing 6204 Name plate Snap ring ø20 Split Pin ø4x50 Shield Nut M24 Adjusting washer Snap ring ø47 Shaft Hanger plate...
