INSTRUCTION MANUAL
SERIES: TRUNK TINA
Read these instructions completely and carefully.
• Read the instruction carefully before installation，non-observance of this instruction may cause damage
to the product or hurt to human body. The installation must be carried out by a qualified electrician in
accordance with local or national codes.
• Cut off the power supply before installation and maintenance !
• Regularly check the light source , the LED power supply, the cord and other accessories. If any part is
damaged, the product should not be used.
• The product is only for indoor and dry location. Clean the product with a damped cloth (no dripping
water), preferably anti-static.
• Do not stare into LED beam.
• product for Class Ⅰ, the input line must have a ground wire.
Dimensions: (mm)
14
85
75
14
85
75
85
75
19
Specifications：
Model
TRUNK TINA-L90-220V
TRUNK TINA-L140-220V
TRUNK TINA-L90-220V-1
TRUNK TINA-L140-220V-1
1244
1244
12
1244
Rated input
Freuquency
220~240VAC
50/60Hz
220~240VAC
50/60Hz
220~240VAC
50/60Hz
220~240VAC
50/60Hz
ATTENTIONS
TRUNK TINA-L90-220V
TRUNK TINA-L140-220V
TRUNK TINA-L90-220V-1
TRUNK TINA-L140-220V-1
TRUNK TINA-L90-220V
TRUNK TINA-L140-220V
Power Facotor
Power
0.95
32W
0.95
52W
0.95
32W
0.95
52W
Length
ta
Max.Linkable(PCS)
1244mm ﹣30~40℃
1244mm ﹣30~40℃
1244mm ﹣30~40℃
1244mm ﹣30~40℃
-
-
8
8
