EdgeSeil Davit™
Operating Manual
1 |
Page
Date of Issue: 01/02/2023
Revision: 02

Advertisement

loading
Need help?

Need help?

Do you have a question about the EdgeSeil Davit and is the answer not in the manual?

Questions and answers

Related Manuals for SAYFA EdgeSeil Davit

Summary of Contents for SAYFA EdgeSeil Davit

  • Page 1 EdgeSeil Davit™ Operating Manual Page Date of Issue: 01/02/2023 Revision: 02...

  • Page 2: Table Of Contents

    Table of contents Product Overview Operation Safe Use & Maintenance Quick Assembly Guide Set Up and Assembly Maintenance Technical Specification EdgeSeil DavitTM Supplied Options Davit Base Mounting Supplied Options Page Date of Issue: 01/02/2023 Revision: 02...

  • Page 3: Product Overview

    The Working at Height 2005 Act necessitates a safe system of work at height for maintenance of all buildings. Davit systems are now an essential solution for Cleaning & range of Davit based solutions. Sayfa EdgeSeil Davit™ is designed for lifting and lowering personnel and materials and complies with EN795:2012, PD CEN/TS 16415 and BS8610:2017.

  • Page 4: Operation

    ● Ensure that operation instructions have been read and fully understood prior to commencing work with the Davit arm. ● EdgeSeil Davit™ is designed for 1 or 2 users, depending on the Arm with a safe working limit of 600Kg.
  • Page 5 first aid. For single user Davits, 2 Davit arms will be required so that one may be used for rescue, along with a reach and grab system. ● Do not tamper with, modify or remove any part of this system unless authorised by Sayfa Group. Page Date of Issue: 01/02/2023...

  • Page 6: Safe Use & Maintenance

    Safe Use & Maintenance ● EdgeSeil Davit™ is designed for 1 or 2 users, depending on the arm with a safe working limit of 600Kg. ● EdgeSeil Davit™ is not to be used during severe weather conditions. It must not be used when wind conditions are greater than 23mph.

  • Page 7: Quick Assembly Guide

    Quick Assembly Guide Step 1 Drop component 1 into the davit base. Step 2 Drop component 2 onto component 1 and secure both components by inserting 1 Mx16 quick release pin through the rear of the davit arm and 2 Mx16 quick release pins through the sides.
  • Page 8 Step 3 Slot component 3 onto component 2 and ensure security by inserting 2 Mx16 quick release pins in the side and 1 Mx16 quick release pin through the top. Rotate the davit back into position if required and insert an Mx12 quick release pin through the davit base and component one if using DBS-0300-0200 or DBS-0400-0300 to fix the davit arm in place and prevent rotation during use.

  • Page 9: Set Up And Assembly

    Set Up and Assembly Step 1 Drop component 1 into the davit base. Step 2 Drop component 2 onto component 1 and secure both components by inserting 1 Mx16 quick release pin through the rear of the davit arm and 2 Mx16 quick release pins through the sides.
  • Page 10 Step 3 Slot component 3 onto component 2 and ensure security by inserting 2 Mx16 quick release pins in the side and 1 Mx16 quick release pin through the top. Rotate the davit back into position if required and insert an Mx12 quick release pin through the davit base and component one if using DBS-0300-0200 or DBS-0400-0300 to fix the davit arm in place and prevent rotation during use.

  • Page 11: Maintenance

    Maintenance EdgeSeil™ must be assessed and recertified by a competent person as defined under the Lifting Operations and Lifting Equipment Regulations 1998 and at intervals of 6 months or less if specified by the manufacturer. EdgeSeil™ must be cleaned using a damp or dry cloth. Chemicals which can damage its components must never be used.
  • Page 12 Davit mast Inspect the mast to ensure that there is no damage and it is not deformed due to overloading. Inspect pin holes to ensure that there is no deformation or elongation due to overloading of the davit system. Inspect the quick release pins to ensure that they are not deformed.
  • Page 13 Davit boom Inspect the boom to ensure that there is no damage and it is not deformed. Inspect the rollers and roller supporting plates to ensure that there is no deformation or deterioration of the plates. The rollers must freely roll. Davit shoulder Inspect the plates and ensure that there is no...
  • Page 14 Davit base Inspect the davit base and ensure that there is no deterioration. Ensure that there is no deformation of the tube, tie-off points, gussets and tube. Ensure that there is no elongation of the quick release pin hole. Fixings are required to be pulled to 21kN and maintained for 3 minutes.

  • Page 15: Technical Specification

    Locking pin- Facilitates rapid assembly and disassembly whilst providing a secure connection. EdgeSeil Davit™ Exterior Body - A flexible aluminium body supporting the anchor. In the event of a fall, it would provide a dampening effect. Anchor Plates - In combination with a shaft, provides an attachment point for rigging workers and equipment.

  • Page 16: Edgeseil Davittm Supplied Options

    EdgeSeil Davit Supplied Options Dimensions 1500mm reach, 1500mm height Single User Code: ESD.1500.1500.1U Reach: 1000mm Height: 1500mm Rating: 21kN Operating angle: 0 - 180 Safe working load: 6kN Unit Weight Shoulder joint – 36 Kg Mast – 24 Kg Boom – 14 Kg...
  • Page 17 Boom – 14 Kg Dimensions 2000mm reach, 1500mm height Code: ESD.2000.1500.2U Reach: 2000mm Height: 1500mm Rating: 21kN Operating angle: 0 - 180 Safe working load: 6kN Unit Weight Shoulder joint – 49 Kg Mast – 24 Kg Boom – 19 Kg Dimensions 2500mm reach, 1500mm height Code: ESD.2500.1500.1U...
  • Page 18 Dimensions 2500mm reach, 1500mm height Code: ESD.2500.1500.2U Reach: 2500mm Height: 1500mm Rating: 21kN Operating angle: 0 - 180 Safe working load: 6kN Unit Weight Shoulder joint – 52 Kg Mast – 25 Kg Boom – 42 Kg Dimensions 1500mm reach, 2000mm height Code: ESD.1500.2000.2U Reach: 1500mm Height: 2000mm...
  • Page 19 Dimensions 2000mm reach, 2000mm height Code: ES2000.2000.2U Reach: 2000mm Height: 2000mm Rating: 21kN Operating angle: 0 - 180 Safe working load: 6kN Unit Weight Shoulder joint – 50 Kg Mast – 38 Kg Boom – 19 Kg Dimensions 2500mm reach, 2000mm height Code: ESD.2500.2000.1U Reach: 2500mm Height: 2000mm...
  • Page 20 Dimensions 2500mm reach, 2000mm height Code: ESD.2500.2000.2U Reach: 2500mm Height: 2000mm Rating: 21kN Operating angle: 0 - 180 Safe working load: 6kN Unit Weight Shoulder joint – 52 Kg Mast – 38 Kg Boom – 42 Kg Dimensions 1500mm reach, 2500mm height Code: ESD.1500.2500.2U Reach: 1500mm Height: 2500mm...
  • Page 21 Dimensions 2000mm reach, 2500mm height Code: ESD.2000.2500.2U Reach: 2000mm Height: 2500mm Rating: 21kN Operating angle: 0 - 180 Safe working load: 6kN Unit Weight Shoulder joint – 50 Kg Mast – 47 Kg Boom – 19 Kg Dimensions 2500mm reach, 2500mm height Code: ESD.2500.2500.1U Reach: 2500mm Height: 2500mm...
  • Page 22 Dimensions 2500mm reach, 2500mm height Code: ESD.2500.2500.2U Reach: 2500mm Height: 2500mm Rating: 21kN Operating angle: 0 - 180 Safe working load: 6kN Unit Weight Shoulder joint – 52 Kg Mast – 47 Kg Boom – 42 Kg 22 | Page Date of Issue: 01/02/2023 Revision: 02...
  • Page 23 Davit Base Mounting Options EdgeSeil™ 200mm tall stainless steel davit base, floor mounting Code: DBS-0300-0200-SS Details A floor mounted base, utilising resin for fixing. Natural Stainless steel finish. Comprises multiple attachment points for anchoring. Comprises locking pin holes which ensures a 2 step removal process of a davit arm when utilised.
  • Page 24 EdgeSeil™ 300mm tall stainless steel davit base, floor mounting Code: DBS-0400-0300-SS Details A floor mounted base, utilising resin for fixing. Natural Stainless steel finish. Comprises multiple attachment points for anchoring. Comprises locking pin holes which ensures a 2 step removal process of a davit arm when utilised 300mm tube height.
  • Page 25 EdgeSeil™ 450mm tall stainless steel davit base, floor mounting Code: DBS-0400-0450-SS Details A floor mounted base, utilising resin for fixing. Natural Stainless steel finish. Comprises multiple attachment points for anchoring. Comprises locking pin holes which ensures a 2 step removal process of a davit arm when utilised.
  • Page 26 EdgeSeil™ 300mm tall stainless steel low profile davit base, floor mounting Code: DBL-0400-0300-SS Details A low profile floor mounted base, utilising resin for fixing. Comprises a detachable base plate. Used in applications where aesthetics are of paramount importance. The tube can be removed and placed in storage.
  • Page 27 300mm tube height. Unit Weight Base plate: 15.6KG Tube: 4.4KG EdgeSeil™ Stainless steel parapet base, wall mounting, 120mm distance from wall Code: DBW-0300-0120-SS Details A wall mounted base, utilising resin for fixing. Stainless steel finish. Comprises multiple attachment points for anchoring. Comprises locking pin holes which ensures a 2 step removal process of a davit arm when utilised.
  • Page 28 Unit Weight 14.4KG EdgeSeil™ Stainless steel parapet base, wall mounting, 200mm distance from wall Code: DBW-0300-0200-SS Details A wall mounted base, utilising resin for fixing. Stainless steel finish. Comprises multiple attachment points for anchoring. Comprises locking pin holes which ensures a 2 step removal process of a davit arm when utilised.
  • Page 29 EdgeSeil™ Stainless steel parapet base, wall mounting, 300mm distance from wall Code: DBW-0300-0300-SS Details A wall mounted base, utilising resin for fixing. Stainless steel finish. Comprises multiple attachment points for anchoring. Comprises locking pin holes which ensures a 2 step removal process of a davit arm when utilised.
  • Page 30 EdgeSeil™ Stainless steel Cast-in base, 185mm tube Code: DBC-0400-0200-SS Details A cast-in davit base, cast in concrete slabs during construction. Used in applications which require the base to be flush with the surface. Stainless steel finish. Comprises multiple attachment points for anchoring. Unit Weight 19KG EdgeSeil™...
  • Page 31 24.5KG Materials Specification S275 Mild Steel Base Plate Hot Dip Galvanised C4. S355 Mild Steel Upper & Lower Anchor Points Hot Dip Galvanised C4. S355 Mild Steel RHS Hot Dip Galvanised C4. 304 grade stainless steel. A4/1.4401 A70 Grade M16 Bolts. A4/1.4401 A70 Grade M16 Pins.
  • Page 32 BS 8610 Personal fall protection equipment. Dynamic testing: 9 KN Static testing: 21 KN Product Warranty 10 Years Standard Warranty 30 Years SAYFA+ Warranty Please refer to the Warranty Application available on www.sayfagroup.co.uk. 32 | Page Date of Issue: 01/02/2023...
