- Page 1 Edgeseil™ Ladder & Platforms Operating Manual...
-
Page 2: Table Of Contents
Table of contents Product overview Operation Safe Use & Maintenance Maintenance Technical Specification EdgeSeil DavitTM Supplied extras Page Date of Issue: 30/06/2022 Revision: 00... -
Page 3: Product Overview
Product overview The Working at Height 2005 Act necessitates a safe system of work at height for maintenance of all buildings. Davit systems are now an essential solution for Cleaning & range of Davit based solutions. EdgeSeil Davit is designed for lifting and lowering personnel and materials and complies with EN795:2012, PD CEN/TS 16415 and BS8610:2017. -
Page 4: Operation
first aid. For single user Davits, 2 Davit arms will be required so that one may be used for rescue, along with a reach and grab system. ● Do not tamper with, modify or remove any part of this system unless authorised by Sayfa Group. Page Date of Issue: 30/06/2022... -
Page 5: Safe Use & Maintenance
Safe Use & Maintenance ● The EdgeSeil Davit™ ladder and platform is designed for one user at a time with a maximum weight of 125kg. This load must not be exceeded. ● The user should be rigged to the Davit base or attached to another appropriate EN795:2012 / BS8610:2017 anchor before erecting or using this equipment. -
Page 6: Maintenance
Maintenance Edgeseil™ davit and its components must be assessed and recertified by a competent engineer at intervals of 12 months for corrosive and harsh environments. If more frequent assessments, then it may be done at intervals of 6 months. Edgeseil™ davit and its components must be cleaned using a damp or dry cloth. Chemicals which can damage its components must never be used. - Page 7 Edgeseil spine ladder Inspect the spine ladder and ensure that there is no deterioration or deformation due to weathering or overloading of the system. Ensure that there is no deformation and elongation of the fixing holes. Non slip soled shoes should be worn for climbing.
-
Page 8: Technical Specification
Technical Specification The ladder is manufactured to BS4211:2005+A1:2008. All ladder and platform material is aluminium. Aluminium extrusion is 6082-T6 grade Aluminium tread plate is 5754-H114 grade Aluminium sheet is 5251-H22 grade All fixings for the ladder and platform are A2 grade stainless steel. Page Date of Issue: 30/06/2022 Revision: 00... -
Page 9: Edgeseil Davittm Supplied Extras
EdgeSeil Davit Supplied extras Ladders 1.5m mast height Dimensions Height: 480mm Weight: 1.4kg 2.0m mast height Dimensions Height: 980mm Weight: 2.8kg Page Date of Issue: 30/06/2022 Revision: 00... - Page 10 2.5m mast height Dimensions Height: 1362mm Weight: 3.9kg Platforms 1.5m boom outreach Dimensions Outreach: 1021mm Weight: 14kg 10 | Page Date of Issue: 30/06/2022 Revision: 00...
- Page 11 Outreach: 1546mm Weight: 21.2kg 2.5m boom outreach Dimensions Outreach: 2047mm Weight: 28.3kg Product warranty 10 Years Standard Warranty 30 Years SAYFA+ Warranty Please refer to the Warranty Application available on www.sayfagroup.co.uk. 11 | Page Date of Issue: 30/06/2022 Revision: 00...
- Page 12 12 | Page Date of Issue: 30/06/2022 Revision: 00...
