Summary of Contents for Schaerer Flavour Point FP4-UC
- Page 1 Flavour Point FP4-UC Operating instructions Original operating instructions 02.2024en Doc. no.: 020738...
- Page 2 The contents of the document are based on the most current data available at the time of printing. Schaerer AG reserves the right to make changes at any time without further notice. All images, figures and dis- play messages in this manual are only shown by way of example. Due to the wide variety of possible options, each individual machine may differ from the devices depicted herein.
-
Page 3: Table Of Contents
Switching on the Flavour Point........................14 Filling the Flavour Point..........................15 5 Cleaning................................16 HACCP cleaning concept..........................16 Cleaning intervals............................16 Cleaning the Flavour Point...........................17 6 Troubleshooting..............................18 7 Disassembly............................... 19 8 Disposal................................20 Doc. no.: 020738 02.2024 Operating instructions Flavour Point FP4-UC... -
Page 4: Safety
Warning of hot steam Warning of dangerous electrical voltage Warning of poisonous substances Warning of hand injuries Prohibition symbols used Charac- Significance Charac- Significance ters ters Read documentation! Wear safety gloves! Operating instructions Flavour Point FP4-UC 02.2024 Doc. no.: 020738... -
Page 5: Intended Use
Use of this equipment is subject to the General Terms and Conditions of Schaerer AG and these oper- ating instructions. In legal terms, any other use is not an intended use. The manufacturer accepts no liability for damage resulting from unintended use. -
Page 6: Foreseeable Misuse
Only use the Flavour Point optional accessory if it is working properly and is not damaged. Residual risks Maximum safety is one of the most important features of Schaerer AG products. The effectiveness of the safety devices is only ensured if the following instructions are observed to prevent injuries and health hazards. -
Page 7: Operator Responsibilities
Schaerer AG service partner, a representative thereof, or other authorised persons. Schaerer AG must be notified in writing of any defects within 30 days! For hidden defects, this period is extended to 12 months from the date of installation (work report, handover report), but no later than 18 months after the product leaves the factory in Zuchwil. -
Page 8: Danger Of Property Damage
In the event of malfunctions, observe the “Troubleshooting” chapter and call in a qualified service technician if necessary. Only use original Schaerer AG spare parts. Report any noticeable damage or leaks immediately to an authorised service partner and have any affected parts replaced or repaired. -
Page 9: Technical Data
Mains connection on site Mains Connection values On-site fuse Connecting cable, conductor cross-sec- tion 1/N/PE 220 – 240 V 50/60 Hz 20 W Max. 16 A Min. 3 x 0.75 mm Doc. no.: 020738 02.2024 Operating instructions Flavour Point FP4-UC... -
Page 10: Serial Plate
The aforementioned manufacturer declares herewith that this machine complies with all relevant stipulations of the specified directives. In case of any modifications of the units that have not been approved by Schaerer, this dec- laration is rendered invalid. The following harmonised standards have been applied. A quality management system certified in accordance with DNV GL –... - Page 11 European approval guidelines for radio equipment and receivers (radio communication) RoHS Restriction of hazardous materials WEEE Waste of Electrical and Electronic Equipment National Sanitary Foundation. Product testing, inspection and certification organisation Underwriters Laboratories. Product safety standards for the US market. Doc. no.: 020738 02.2024 Operating instructions Flavour Point FP4-UC...
-
Page 12: Manufacturer's Address
P.O. Box 336 Product care & management system Niedermattstrasse 3b P.O. Box 336 CH-4528 Zuchwil Niedermattstrasse 3b T +41 32 681 62 00 CH-4528 Zuchwil F +41 32 681 64 04 Operating instructions Flavour Point FP4-UC 02.2024 Doc. no.: 020738... -
Page 13: Product Description
Abb.: CAN bus connection No. Name Explanation CAN bus 1 Communication interface between coffee machine and syrup station CAN bus 2 Communication interface between coffee machine and other optional accessories (e.g. milk system) Doc. no.: 020738 02.2024 Operating instructions Flavour Point FP4-UC... -
Page 14: Installation And Commissioning
P The Flavour Point will now connect to the coffee machine. 9. Start the coffee machine commissioning routine. Details of the commissioning routine can be found in the operating instructions of the respective coffee machine. Operating instructions Flavour Point FP4-UC 02.2024 Doc. no.: 020738... -
Page 15: Filling The Flavour Point
4. Insert the hose adapter (Plug&Clean adapter) [3] into the Flavour Point and lock the bayonet lock by turning it to the right. 5. Repeat the steps listed above for all syrup bottles. Doc. no.: 020738 02.2024 Operating instructions Flavour Point FP4-UC... -
Page 16: Cleaning
The HACCP cleaning concept is designed to ensure safe food. Hazards related to the processing of food or emanating from finished products are considered and the risks are assessed. The risks are mitigated by appropriate measures. When installation, maintenance, care and cleaning are performed properly, Schaerer AG optional accessories sat- isfy the HACCP requirements. -
Page 17: Cleaning The Flavour Point
The following is required before the cleaning programme: Cleaning container Clean and damp cloth (cleaning rag) Cleaning is done by the connected Schaerer coffee machine. A cleaning programme is started from the touch screen of the coffee machine. 1. Follow the displayed instructions. -
Page 18: Troubleshooting
Check: Is the device plugged in? Flavour Point. Check: Is the fuse at the installation site faulty? Check: CAN node connection to coffee machine Check: CAN node connection to coffee machine Empty message does not report. Operating instructions Flavour Point FP4-UC 02.2024 Doc. no.: 020738... -
Page 19: Disassembly
Disassembly Disassembly After end of service life After the device has reached the end of its service life, disassemble the device and dispose of it in an environmentally friendly manner. Doc. no.: 020738 02.2024 Operating instructions Flavour Point FP4-UC... -
Page 20: Disposal
If no return or disposal agreement has been made, disassembled components must be recycled. Scrap metal parts. Recycle plastic elements. Dispose of the remaining components after sorting them according to material properties. Operating instructions Flavour Point FP4-UC 02.2024 Doc. no.: 020738...
