Riverside Furniture 37276 Assembly Instructions

email: info@riverside-furniture.com
Warning :
- Be sure to check all packing material carefully for small parts,which may have come loose inside the carton during shipment.
- To prevent possible scratches and damage, this furniture MUST BE ASSEMBLED BY TWO PEOPLE on a soft surface such as a
blanket or carpet.
Louver Headboard 37276
H-A
1 pc.
∅
5/16''-18 x 1-1/2"
Allen Head Bolt
H-E
2 pcs.
Louver Footboard 37277
F-A
1 pc.
∅
Bed Rails 37272
5/16-18 x 3-1/2"
All-Thread Bolt
R-A R-B
2 pcs.
5/0 Queen Bed
37276 -- 4/6-5/0 Louver Headboard
37277 -- 5/0 Louver Footboard
37272 -- 5/0-6/6 Panel Bed Rails
Assembly Instructions
Hardware and Parts packed with the Headboard
Headboard Post Left
H-B
∅
5/16''-18 x 1-3/4"
Allen Head Bolt
H-F
8 pcs.
Hardware and Parts packed with the Footboard
Wood Slats 61-1/4" long
F-B
Hardware and Parts packed with the Bed Rail
∅
5/16"
Curved Washer
R-C
8 pcs.
8 pcs.
Cora
Bedroom
Headboard Post Right
H-C
1 pc.
∅
5/16"
Spring Washer
H-G
8 pcs.
Support Leg
(D) 7-1/2" x (W)1- 1/4"(H) 1- 1/4"
F-C
1 Set.
∅
5/16" x 16*2mm
Spring Washer
Flat Washer
R-D R-E
8 pcs.
Made in Viet Nam
Queen Louver Bed
Headboard stretcher
H-D
1 pc.
∅
5/16" x 19*2mm
Flat Washer
H-H
8 pcs.
#8 x 1" Wood Screw
F-D
5 pcs.
∅
∅
5/16"
5/16 x L17 Nut
R-F
8 pcs. 8 pcs.
Page 1 of 5
1 pc.
5mm Allen Key
H-I
1 pc.
10 pcs.
Open Wrench
12mm
R-G
1 pc.
