x1 Mirror
x1 Miroir
x1 Espejo
E
∅
x8 Flat Washer
1/4"x19mm
∅
x8 Rondelle plate
1/4"x19mm
∅
x8 Arandela plana
1/4"x19mm
Page 1 of 3
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
PRODUCT NAME / NUMBER(S) : P306DJ110
Description if Available / Needed : Mirror / Miroir / Espejo
B
x2 Mirror Support
x2 Supporte de miroir
x2 Soporte del espejo
F
x1 Allen Key 5mm
x1 Clé hexagonale 5mm
x1 Llave Allen 5mm
A
B
C
∅
x8 Bolt
1/4"x45mm
∅
x8 Boulon
1/4"x45mm
∅
x8 Perno
1/4"x45mm
Assembly Instructions-Instructions d'assemblage-Instrucciones para el ensamblaje
Made in VietNam / Fabrique en VietNam / Hecho en VietNam.
D
∅
x8 Lock washer
1/4"
∅
x8 Rondelle de blocage
x8 Arandela de Seguridad
*
Replaceable part
1/4"
∅
1/4"
