Giacomini R595 Series Manual

R595, R595P, R595P
Cassetta in plastica con
coperchio
Plastic cabinet with cover
R595
Cassetta in plastica con coperchio.
Fissaggio del coperchio con viti.
Plastic cabinet with cover.
Fixing the cover with screws.
Versioni e codici

CODICE
SERIE
PRODUCT CODE
R595AY001
R595 R595BY001
R595CY001
R595T R585TY001
R595PY001
R595P R595PY002
R595PY003
DIMENSIONI (L x A x P)
DIMENSIONS (L x H x D) CONNECTIONS CENTER DISTANCE
[mm]
370 x 300 x 90
520 x 300 x 90
670 x 300 x 90
357÷657 x 287 x 18
(Nicchia - Recess)
370 x 300
520 x 300
670 x 300
R595T
Telaio metallico regolabile per
copertura nicchie collettori.
Da utilizzare in abbinamento ai
coperchi in plastica R595P.
Adjustable metal
covering manifolds recesses.
To be used in combination with
R595P plastic cover.
Versions and product codes

INTERASSE AGGANCI
[mm]
R580CY063, R580CY064, R585CY062, R585CY063, R585CY064
35
DN25 modular manifolds, R580CY062, R580CY063, R580CY064,
-
-
Coperchio in plastica per cassetta
R595 o copri nicchia per telaio
metallico R595T.
Completo di viti di fissaggio.
frame for Plastic cover for R595 cabinet or
recess cover for R595T metal frame.
Equipped with fixing screws.
UTILIZZO
USE
Per collettori in barra da 3/4" o 1" (interasse 35 mm),
collettori modulari DN25, collettori componibili R580CY062,
For 3/4" or 1" bar manifolds (center distance 35 mm),
R585CY062, R585CY063, R585CY064 modular manifolds
Da utilizzare in abbinamento ai coperchi in plastica R595P.
To be used in combination with R595P plastic covers
Da utilizzare in abbinamento al telaio metallico R595T
o come ricambio per le cassette R595.
To be used in combination with R595T metal frame
or as a spare part for R595 cabinets.
Giacomini S.p.A.
Via per Alzo 39, 28017 San Maurizio d'Opaglio (NO) Italia
 consulenza.prodotti@giacomini.com
 +39 0322 923372 - giacomini.com
Scheda tecnica/Istruzione
Datasheet/Instruction
0201ML  02/2024
R595P
