4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
SIGNAL/POWER
GROUND
A
4
3
M12x1 - 6g
TEMPERATURE OUTPUT
N/C
3
2
2X  .672 [
.030 [.76]
.97 [24.6]
1.73 [43.9]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
DECIMALS XX ±.03 DECIMALS X ± 0.8
XXX ±.010 XX ± 0.25
ANGLES  2 DEGREES ANGLES  2 DEGREES
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
REVISIONS
REV DESCRIPTION
NR RELEASED TO DRAFTING
1/4-28 UNF - 2B  .20 [5.1]
 17.07]
.687 [17.45] HEX
DRAWN CHECKED ENGINEER
JDM 6/11/20 JDM 6/11/20 GCD 6/11/20
3425 WALDEN AVE. DEPEW, NY 14043
TITLE
(716) 684-0001 E-MAIL: sales@pcb.com
OUTLINE DRAWING
TEMPERATURE OUTPUT
CODE
IDENT. NO.
ACCELEROMETER
52681
WITH 4-PIN M12 CONNECTOR
SCALE:
1
DIN
50771
B
A
DWG. NO.
73434
2.5X SHEET 1 OF 1
1
